Scope of application
This unit is suitable for measuring materials that are good ultrasonic conductor such as metal, plastic, ceramic, glass etc., as long as the measured part in two parallel surfaces for measurement of thickness. Measuring Range: 1.2 To 220mm (steel)
This unit is not suitable for cast iron due to its big crystall- oid composition.
Specification
Display: 4-digital LCD display
Minimum display unit: 0.1 mm
Working frequency: 5MHz
Measuring range: 1.2 to 225.0mm (steel)
Minimum limit for tube measuring: 20*3mm (steel)
Accuracy: +/- (1%H+0.1)mm H denotes the measured
thickness. Sound velocity range: 1000 to 9999 m/s
Measuring sound velocity with a given thickness:
measuring range:1000 to 9999 m/s.
When the given thickness over 20mm, the accuracyis +/-1%; when the given thickness less than 20mm, the accuracy is+/-5%. Operation temperature: 0 to 40
Power supply: 3*1.5V AAA alkaline batteries
Operation current: Normal operation current 50mA
With Backlight turn on current 120mA
Stand-by current: 20uA
Size: 72*146*29mm
Weight: 202g
Features & details
Accuracy: ±(1%H+0.1); Resolution: 0.1mm;
Sound velocity range: 1000 to 9999m/s;
Coupling Agent/Oil is not Included, since air shipping limitation, it can be replaced by water or cooling oil.
Power supply: 3*1.5V AAA alkaline batteries(Not Included)
Product information
Item Weight 2.31 pounds
Manufacturer Benetech
ASIN B074QKPWZJ
