Gsm Burglar Alarm Security Unit 4 Wired + 8 Wireless Zone Guard Alarm Controller
Overview:GSM burglar alarm controller is a kind of intelligent burglary alarm equipment which use GSM communication network to send alarm message. 4 wired arm zones and 8 wireless arm zones can be indicated independently. It can connect with various fireproof and theftproof detectors, wired or wireless detectors and local alarm equipments. It can store multiple groups alarm telephone numbers which can use independently or form network alarm. Support to report arm/disarm to the center freely. With various functionality, flexible to install and easy to operate. Which is an ideal choice for family, shop ,financial system , enterprise and public institution and network alarm center to alarm.Features & Functions:4 wired + 8 wireless zones with microcomputer control,the panel features comprehensive functions of burglarproof, fireproof and hold-up alarmsPanel is equipped with integrative programmable keypad,LCD ,and memory of 5 groups of alarming telephone numbersTransmission through GSM wireless network and alarm signal receipt via fixed telephone, mobile phone and manual/networked alarm receiving centerCompatibility with Contract ID,4+2 and SHIKE communication protocolsShort message report alarm location,subsection record each alarm positionRemote control the arming/disarming with remote control unit,the keyboard and messagesRemote talk-back function,the on-site people can call and talk-backAlternatives of internal connecting and external connecting alarming outputBuilt-in electronic clock makes it possible to arm/disarm different zones in fixed time,set up timer clock and report the self-check status of the panel in fixed timeZonal arm/disarm and doorbell available for all wired or wireless zones,with zone bypass function.With arm Linkage output control port,available external arm/disarm instructionsWireless detector and remote control unit capable of auto-learning of code checkingBuilt-in relay output linkage can link image monitorInternal 12V maintenance-free rechargeable battery with intelligent charging/disarming for different wire/wireless zones and monitoring of onsite soundAuto-reporting of AC power failure,power and low voltage of battery and to the receiving center workstationName of Main Parts and Purpose Descriptions: 1 Antenna: To receive signals transmitted by the wireless sensors and the remote control.2 Panel casing3 Zone identification card: Used to record the locations of sensors of wired/wireless zones4 Keypad: To set up phone numbers, panel features and also for arming/disarming operations.Bypass: No defence for a certain zone. If a certain zone has problem or user temporarily don & rsquo;t use the zone , user can set the zone as bypass before arm , then the zone is in the state of normal disarm.Programming: For functions except setting and searching phone numbers. In programming settings mode, this key functions as group operation key & ldquo; & darr; & rdquo;; in phone settings mode, this key functions as group operation key & ldquo; & uarr; & rdquo;.Password: The function key for password operation. Enter a 4-digit password and press & ldquo;OK & rdquo; to finish password operation.OK: To confirm and process the data input of function keys such as Phone, Function, and Password.Record/Play: To record/play audio. When in Programming mode, press this key to record audio; when the programming mode is quitted, press this key to play audio.Reset: To quit all function key operation.Semi-arming: To perform arming operation on the common security zones listed with instruction 15.All-arming: To perform arming operation on all the zones listed.5 Speaker: To give out alarm sound when there is an alarm, to give out prompt sound for an operation, to sound (clink) when the doorphone feature is activated, and to play recorded audio.6 Wireless zone indicators: LED indicators 1 to 8, for alarming or arming prompts of wireless zones 1 to 8.7 Wired zone indicators: LED indicators 1 to 4, for alarming or arming prompts of wired zones 1 to 4.8 LCD display: To display the status and content of programming.9 Function indicators:Operation indicator: After the power is turned on, this indicator works alternately by lighting up for 1 second and blacking out for 4 seconds, which means the system is under normal operation.Power indicator: This indicator lights up when the system is connected with AC power (mains), and blacks out when there is no AC power (mains).Dialing indicator: When the system is processing an alarm message and dialing an emergency number automatically, this indicator lights up.Arming indicator: This indicator lights up when any security zones are armed.10 MIC: A. Used for recording when programming;B. Used for on-spot audio monitoring when there is an alarm.11 Reception board: Radio signal reception module12 Motherboard: The main circuit board of the user panel.13 DC fuse holder: Automatic recovery14 TAMP ON jumper socket: When plunger cut down , close the tamper-resistant switch. And when plunger plug into, open the tamper-resistant switch and start wired B4 arm zone, you should set this zone as 24 hours arm zone.15 Anti-dismantlement switch: When the cover is prized off the panel, this switch functions to produce an alarm.16 AC power socket: To connect 220V AC power(mains).17 Battery leads: Red for positive(+), and black for negative(-).18 Battery: 12V 1.3Ah(User Matching)19 Programming switch: When this switch is at Authorized position(SET), programming is available via the keypad. When the switch is at & ldquo;RUN & rdquo;, the keypad programming feature is disabled, in which case you can only press the keypad & rsquo;s Password and numeric keys to arm or disarm a zone.20 Panel circuit connection socket: Pull out this socket before installation to facilitate installation.21 Wired zone interface:Terminals B1 and GND: Connect with the detector signal and negative lead of security zone 1.Terminals B2 and GND: Connect with the detector signal and negative lead of security zone 2.Terminals B3 and GND: Connect with the detector signal and negative lead of security zone 3.Terminals B4 and GND: Connect with the detector signal and negative lead of security zone 4.Terminals AUX and GND: Provide +12V power supply for security zones 1 to 4. AUX means positive, while GND means negative.22 Linkage output: NO means always on, COM means common, while NC means always off.23 Arm linkage output port: When the host disarm, this port cut down. And when the host arm, thisport close24 GSM antenna pedestal: Connect outer GSM antenna.25 GSM module signal indicator: Display the signal strength of GSM module, the more the indicator light , the stronger the signal is . Remote control26 For arming/disarming.27 For emergency alarm. Press this key and the user panel will automatically dial an emergency number.28 For arming operations.29 Not defined.
