800W DPX800S Booster Module DC-DC NC CV CC Step Up Converter 12V-120V 0-15A Adjustable MPPT
800W DPX800S DC-DC NC CV CC Booster Module Boost 12V-120V 0-15A Adjustable MPPT Product Description: 1: Small size, high power, high efficiency, stable work, can be constant voltage and constant current transmiion 2: Comes with a fan to diipate heat, and the temperature rise is small 3: With boost MPPT function, suitable for solar panel boost charging to capture the maximum output power of the solar panel 4: The use of high-quality power devices, with the CV and CC loops formed by the peripheral precision operational amplifiers, greatly improves the performance of the module 5: With communication function, it is convenient for secondary development 1. Product introduction DPX800S adopts LCD1602 LCD numerical control constant voltage power supply, small size, high power, high efficiency, stable work, can output constant voltage and current, and the module comes with a constant voltage algorithm boost MPPT function, which can grab solar panels Maximum output power. Using advanced microproceor control, the can be adjusted quickly and conveniently through ons and encoders. And using LCD1602 liquid crystal display, it can display output voltage, current, power, output capacity and input voltage, working status and other information in real time. With communication function, it can communicate with a computer or a single- computer to read or set the of the instrument. Second, the characteristics of the instrument LCD1602 is used to display information, ons and encoders are used to adjust , which makes human-computer interaction more convenient; The use of high-quality power devices and the CV and CC loops formed by peripheral precision op amps greatly improve the performance of the module; Comes with a fan to diipate heat, and the temperature rise is small; Full digital display, convenient and easy to use; It can output with constant voltage and constant current; Using advanced microproceor, the on can accurately adjust the output voltage and current; Can be set to automatically output ar power on; With input under-voltage protection (LVP), output over-voltage protection (OVP), output over-current protection (OCP); With communication function, it is convenient for secondary development; With the boost MPPT function, it is suitable for solar panel boost charging to capture the maximum output power of the solar panel; The output can be turned off to 0, which is safer and more convenient than traditional Boost boosters; Parameter: Parameter display mode: LCD1602 display Input voltage: 10v~65v (800w) Input current: 15A (Max) Output voltage: 12v~120v (800W) Output current: 0~12.0A Output power: 800W (Max) Input protection mode: under voltage protection (LVP) Output protection mode: over voltage protection (OVP), over current protection (0CP) Voltage adjustment resolution: 0.1V Current adjustment resolution: 0.1A Voltage display resolution: 0.1V Current display resolution: 0.01A Fan start condition: output current is greater than 1.5A or power is greater than 40W Short circuit protection: 15A car fuse Wiring mode: 8500 terminal block Product size (length × width × height): 130 × 86 × 60 (mm) (without packaging) Net weight: 268.4g Six, use matters needing attention 1. This module is a boost module, VOUT≥VIN. Ar powering on the module, when the output is not turned on, the output terminal voltage is 0V. There is no disadvantage that the input is equal to the output. If the set output voltage is lower than the input voltage, the output voltage ar the output is also equal to the input voltage, which is normal. , When in use, the input voltage must be lower than the output voltage or the rated voltage of the electronic and electrical equipment. 2. Description of the constant current function. Due to the limitation of the BOOST boost circuit structure, the minimum voltage value output by the BOOST boost circuit is equal to the input voltage, so the instrument cannot short-circuit constant current, but as long as it reaches the condition of constant current state, it can achieve constant current. Function, this function is particularly suitable for boosting battery charging. Auming that the output set current value is I, the impedance of the output load is R, and the input voltage is Uin, when I*R>Uin, the constant current function can be realized, otherwise it cannot be realized. Stream function. 3. The module has input under-voltage protection function (LVP) and recovery output value (STR). If the input under-voltage protection value (LVP) is set, and theP function is turned on; and the recovery output value (STR) is also set , And then turn on the STR function, so that when the input voltage is lower thanP, the boost function will be turned off to stop the output, and when the input voltage is higher than the (STR) value, the module will restart the output. When setting STR>LVP; this function is especially suitable for the battery boost power supply function, which can protect the input battery from damage due to undervoltage, and automatically turn on the boost function when the charging reaches a suitable voltage, which is very intelligent. 4. DPX800S is based on the MPPT function of constant voltage algorithm, which is to change the charging current by adjusting the output voltage to ensure that the output voltage of the solar panel is always near the voltage point corresponding to the maximum power. Generally, the maximum power point of the solar panel corresponds to the voltage It is 0.78 times of the open circuit voltage. When using the MPPT function of the product, in order to ensure that the product can better capture the maximum power of solar energy and ensure the safety of battery charging, some parameter settings must be set first: MOD,P, OVP, OCP, STR, For specific setting instructions, refer to the instructions for use. Package: 1*Boost power module About shippingShipping and Packaging All it will be double checked and well packed before sending.It will be dispatched within 2 business days ar buyers pay for the order. It usually takes about 14 to 18 working days for delivering the package to the destination(for remote areas,it may take a little longer). Special Announcement:Please fill in the correct and detailed consignee, address and phone number in the order. For fast and correct delivery.If you do not receive order within 30 working days,please feel free to contact Customer Service before leaving Negative and Neutral Feedback, we will do our best to help you resolve the problem.TaxNo, you will only pay what is quoted as total cost at checkout, no more. You are not expected to pay any additional duties ores. If you are asked by Customs or our logistic partner to pay duties, please contact our Customer Service .Your 100% satisfaction is very ant to usIf the product is not on good condition, You can return this product within 14 working days, please contact customer service center before returning.FeedbackYour satisfaction is our first priorityIf you receive the order and it is in good condition,we would be grateful if you would leave us 5 star Positive Feedback for the transaction.Key FeaturesType:DC/DC ConvertersCertification:CEOrigin:Mainland ChinaSize:Booster ModuleModel Number:DC-DC Step Up ConverterOutput Frequency:12V-120V 0-15AOutput Type:SingleOutput Power:500 - 1000WWeight:295gis_customized:NoneOutput Current:15A MAXWhat's In the Box1X 800W DPX800S Booster Module DC-DC NC CV CC Step Up Converter 12V-120V 0-15A Adjustable MPPT
