Dvr 4ch 1080p Lite Xvr Z8304xe-s
could deliver up to excellent 1080P Lite resolution excellent image over advanced H.264+ compression.
It & rsquo;s the ideal consideration for the balance of quality, performance and budget.
The friendly GUI provides intuitive shortcut operations, remote control and management, flexible storage, smart search and playback.
It & rsquo;s widely used for the government, banking sectors, manufacturers, educational or commercial projects.
Powered by the strong interoperability and Onvif Profile S, it & rsquo;s compatible with a variety of 3rd party crossing platform VMS.
Model
Z8304XE-S
System
Processor
Multi-core Embedded Processor
Operation System
Embedded Linux
I/O port and Storage
Network Interface
1 RJ-45 port (10/100Mbps)
USB
3*USB 2.0
HDMI
1*1080P
VGA
1*VGA
Alarm Input
N/A
Alarm Output
N/A
RS-485
N/A
HDD
1 SATA, up to 8TB capacity for each
e-SATA
N/A
Playback and Backup
Playback Channel
4
Search Mode
Time/Date, MD and Exact Search
Playback Function
Play, Pause, Stop, Rewind, Fast Play, Slow Play, Next Camera, Previous Camera, Full Screen, Shue, Backup Selection, Digital Zoom
Backup Mode
USB device/Network
Network
Network Protocol
HTTPs, HTTP, TCP/IP, IPv4, UPnP, Onvif 2.6, RTSP, RTCP, UDP, SMTP, SNMP, Multicast, IGMP, NTP, DHCP, DNS, DDNS, FTP, P2P
Max. Online User
5
Mobile App
Antarview Pro (iOS & Android)
Interoperability
Onvif Profile S, SDK
Audio and Video
Audio Compression
G.711a
Audio Bit Rate
64Kbps
Video Input
4ch BNC interface(1.0Vp-p, 75 & Omega;)
AHD Input
1080P, 720P
TVI Input
1080P 720P
CVI Input
1080P, 720P
IP Camera Input
Up to 4ch 2MP
Hybrid Mode
2ch(AHD/TVI/CVI/CVBS)+2ch(IP)
Two-way Talk
1-Channel Input, 1-Channel Output, RCA
Recording
Video Compression
H.264/H.264+
Record Resolution
4ch 1080P Lite@25fps
Frame Rate
1fps-25fps
Incoming Bandwidth
32Mbps
Bitrate
11Kbps-2291Kbps
Record Mode
Timing and alarm record, Timing Record, Alarm Record
Power
Power supply
DC 12V2A
Consumption
& le;10W without HDD
General
Working Temperature
0 & deg;C~+55 & deg;C
Working Humidity
10~90%
Dimensions
233mm254mm42mm
Net Weight
0.91KG
