Digital Display Adjustable DC 480W Switching Power Supply 0-5-12-24-36-48-60-80-120-160-220V
The DC output voltage ranges from (0-5V60A) (0-12V40A) (0-24V20A) (0-36V15A) (0-48V10A) (0-60V8A) (0-80V6A) (0-120V4A) (0-160V3A) ( 0-220V2.2A) Continuously adjustable, high adjustment accuracy, 0-5V signal control voltage, power 0-480W1. Technical performance indicators1. Output voltage range: 0-5V continuously adjustable, output current: 60A, (adjustable to 8V) Digits of digital display meter: 3 digits Output voltage range: 0-12V continuously adjustable, output current: 40A, (adjustable to 15V) Digits of digital display meter: 3 digits Output voltage range: 0-24V continuously adjustable, output current: 20A, (adjustable to 27V) Digits of digital display meter: 3 digits Output voltage range: 0-36V continuously adjustable, output current: 15A, (adjustable to 38V) Digits of digital display meter: 3 digits Output voltage range: 0-48V continuously adjustable, output current: 10A, (adjustable to 50V) Digits of digital display meter: 3 digits Output voltage range: 0-60V continuously adjustable, output current: 8A, (adjustable to 62V) Digits of digital display meter: 3 digits Output voltage range: 0-80V continuously adjustable, output current: 6A, (adjustable to 82V) Digit display meter: 3 digits Output voltage range: 0-120V continuously adjustable, output current: 4A, (adjustable to 122V) Digits of digital display meter: 4 digits Output voltage range: 0-160V continuously adjustable, output current: 3A, (adjustable to 162V) Digit display meter: 4 digits Output voltage range: 0-220V continuously adjustable, output current: 2.2A, (adjustable to 222V) number of digital display meter: 4 digits2. Ripple voltage; not more than 100mV3. Equivalent internal resistance of voltage stabilization: no more than 0.5 & Omega;4. Voltage adjustment rate:5. With short circuit, overload protection, and automatic recovery functionsInput voltage: AC110V/220V±15%Rated power: 480WProduct size: 21.5CM (length) * 11.5CM (width) * 5CM (height),Instructions for use:Uses: Mainly used in various DC equipment, DC motor stepless speed regulation, LED stepless dimming, chemical electrolytic plating speed regulation, scientific research and testing, student experiments, etc., and has a wide range of uses.Special attention: When using inductive loads such as motors, fans, etc., please pay attention to the motor starting current parameter. This parameter should not be higher than the power supply current, otherwise the power supply may be damaged. You should choose a larger current power supply or equip the motor with soft start protection The circuit absorbs inrush current.Terminal description and wiring methodL, N AC input terminal FG ground mark V+ DC output positive terminalV-DC output negative terminal ADJ adjustable potentiometer to fine-tune the output DC voltage●Full voltage input●Miniaturization●Protection function short circuit/overload/overvoltage●Full load burn-in testInput voltage & frequency range----------110/220VAC/47～63HzStarting impulse current ---------------20A@120VAC (cold start)Output adjustment range ---------------± (rated output voltage)Overload protection -------------------105%～200% (rated load), self-recoveryOvervoltage protection -------------------115%～135% (rated output voltage)Short circuit protection-------------------self-recoveryOutput start time---------------≤2S@120VAC ≤1.0S@230VACOutput hold time-------------≥10mS@120VAC,≥20mS@230VACInsulation strength -------------------input-output: AC1500V, 1min Input--chassis: AC1500V, 1min Output--chassis: DC500V, 1minWorking environment ------------------ —10℃～50℃; 20%～90%RH (no condensation)Safety standard-------------------Design reference EN/UL60950Electromagnetic compatibility standard---------------design refer to EN55022 Class B; EN61000-4-2/-3/-4/-5/-6/-11Key FeaturesCertificering: CEUitvoerspanning: 0-50Ais_aangepast: JaUitvoervermogen: 480WWhat's In the Box1 * item
