Design Mini Converter Sdi To Hdmi
Blackmagic Design Mini Converter SDI To HDMI ConnectionsSDI Video Input Switchable between SD, HD and 3 Gb/s SDI. NoneSDI Video Output Automatically matches the SD, HD and 3 Gb/s SDI video input. Automatically matches the SD and HD video input.Analog Video None Component SD/HD, NTSC, PAL and S-Video.Analog Audio 2 channels of professional balanced analog audio with standard 1/4 inch jack connections. 2 channels of professional balanced analog audio with standard 1/4 inch jack connections.AES/EBU Digital Audio 2 channels of professional balanced digital with standard 1/4 inch jack connections. 2 channels of professional balanced digital with standard 1/4 inch jack connections.HDMI HDMI type A out NoneSDI Redundant Input Automatically switches over if main SDI input is lost. NoneMulti Rate Support Auto detection of HD or standard definition SDI inputs. Auto detection of HD or standard definition SDI inputs.Updates and Configuration Via USB 2.0 high speed. (480 Mb/s) Via USB 2.0 high speed. (480 Mb/s)Reclocking Yes YesStandardsSDI Compliance SMPTE 292M, SMPTE 259M, SMPTE 296M, ITU-R BT.656 and ITU-R BT.601. SMPTE 292M, SMPTE 259M, SMPTE 296M, ITU-R BT.656 and ITU-R BT.601.SDI Video Rates SDI video connections are switchable between standard definition and high definition. SDI video connections are switchable between standard definition and high definition.SDI Video Sampling 4:2:2 4:2:2SDI Audio Sampling Television standard sample rate of 48 kHz and 24 bit. Television standard sample rate of 48 kHz and 24 bit.SDI Color Precision 4:2:2 4:2:2SDI Color Space YUV YUVSDI Auto Switching Automatically selects between SD SDI, HD-SDI and 3 Gb/s SDI. Automatically selects between SD SDI, HD-SDI and 3 Gb/s SDI.SDI Format Support 625/25 PAL, 525/29.97 NTSC, 1080PsF23.98, 1080PsF24, 1080PsF25, 1080i50, 1080i59.94, 1080i60, 720p50, 720p59.94 and 720p60. 625/25 PAL, 525/29.97 NTSC, 1080PsF23.98, 1080PsF24, 1080PsF25, 1080i50, 1080i59.94, 1080i60, 720p50, 720p59.94 and 720p60.Analog Format Support None 625/25 PAL, 525/29.97 NTSC, 1080PsF23.98, 1080PsF24, 1080i50, 1080i59.94, 1080i60, 720p50, 720p59.94 and 720p60.Analog Color Space None YUVAnalog Color Precision None 4:2:2HDMI Format Support 625/25 PAL, 525/29.97 NTSC, 625/50p PAL, 525/59.94p NTSC, 1080p23.98/24, 1080i50, 1080i59.94/60, 720p50 and 720p59.94/60. NoneHDMI Color Space YUV NoneHDMI Color Precision 4:2:2 NoneExtrasSoftware Control Mac OS X & trade; and Windows & trade; software upgrade via USB. Mac OS X & trade; and Windows & trade; software upgrade via USB.Internal Software Upgrade Via included updater application. Via included updater application.Settings Control Mini Switches or USB software. Mini Switches or USB software.Power Supply +12V universal power supply included with international socket adapters for all countries. Cable tie point. +12V universal power supply included with international socket adapters for all countries. Cable tie point.Power Consumption 5.76 Watts 6.50 WattsOperational Voltage Range 12V 12 - 31 Vdc
