Omega -20°C to 250°C Temperature Handheld Thermal Imager
Batteries Included Yes
Battery Life 2 hours
Battery Run Time 2 hours
Battery Type AA
Display Area Height 71 mm (2. in)
Display Type Color LCD
Emissivity 0.95 default
Frame Rate 9 Hz
Focus Method Focus free
Image Capacity Stores up to 60
Measurement Type Thermal Image
Memory Type micro SD card
Memory Capacity 8 GB
Number of Batteries Included 4
Temperature Accuracy ( Tamb 20 26 ° C) 2% of reading
Thermal Resolution 32 x 31
Temperature Resolution 32 x 31
Viewing Area 40 x 40°
Omega’s OSXL-TIM3 thermal imaging camera measures from 20 to 250°C (4 to 482°F) and displays the thermal image and teDescriptionmperature. Plus, the OSXL-TIM3 can save the thermal images to a micro SD card (included). Software that transfers images to a PC is also included for image review and reporting of the details on the saved images.
Modern IR thermal imaging technology
2.4 "LCD color display and graphic menu navigation
Thermal image resolution of 160 x 120 pixels
High temperature measuring range up to + 550 °C
High quality thermal image sensor with high temperature sensitivity
Fast thermal imaging with 25 Hz
Four color palettes (Iron, Rainbow, White, Black)
Crosshairs, as well as cold and hot spot display
Minimum and maximum value display
Photo record with internal memory
Records with time and date documentation
