SmartSolar Charge Controller MPPT 150/60
Battery voltage 12 / 24 / 48V Auto Select (software tool needed to select 36V) Rated charge current 85A 100A Maximum PV power, 12V 1a,b) 1200W 1450W Maximum PV power, 24V 1a,b) 2400W 2900W Maximum PV power, 48V 1a,b) 4900W 5800W Max. PV short circuit current 2) 70A 70A Maximum PV open circuit voltage 150V absolute maximum coldest conditions 145V start-up and operating maximum Maximum efficiency 98% Self-consumption Less than 35mA @ 12V / 20mA @ 48V Charge voltage 'absorption'
Default setting: 14,4 / 28,8 / 43,2 / 57,6V (adjustable with: rotary switch, display, VE.Direct or Bluetooth) Charge voltage 'float' Default setting: 13,8 / 27,6 / 41,4 / 55,2V (adjustable: rotary switch, display, VE.Direct or Bluetooth) Charge algorithm multi-stage adaptive Temperature compensation -16 mV / -32 mV / -68 mV / °C Protection Battery reverse polarity (fuse, not user accessible) PV reverse polarity / Output short circuit / Over temperature Operating temperature -30 to +60°C (full rated output up to 40°C) Humidity 95%, non-condensing Data communication port VE.Direct or Bluetooth Remote on/off Yes (2 pole connector) Programmable relay DPST AC rating: 240VAC / 4A
DC rating: 4A up to 35VDC, 1A up to 60VDC Parallel operation Yes (not synchronized) ENCLOSURE Colour Blue (RAL 5012) PV terminals 3) 35 mm² / AWG2 (Tr models) Three sets of MC4 connectors (MC4 models
