- Support ONVIF protocol.
- Support 7 kinds of split mode
- IR led, POE, WIFI optional
Lens 1/3" Fisheye lens, f=1.16mm, F=2.0
Field of Vision Horizontal 182°/Vertical 166°
Iris Fixed F2.0
Sensor 1/3.2" Progressive Scan CMOS
Sensibility 0.3Lux@F2.0(Color)/0.03Lux@F2.0(B/W)
Day/Night Auto switch IR cut
IR Illumination Omni-directional 3W@850nm, 10m effective distance
Image Flip Horizontal/Vertical
Image Adjustment Brightness, Saturation, Sharpness, Contrast, Tone
Max. Resolution 1.0 to 3.0 Megapixels(2048×1536)
Video Coding Dual Stream H.264
Bit Rate 300Kbps~8192Kbps
Max. Frame Rate 20fps
Audio
Microphone Internal
Audio Coding NO
Pickup Distance 6 Meters
Audio Output NO
Panoramic Function Enabled by software
Panoramic Display Support kinds of unwrap function based on ceiling, wall and floor mount; Support multiple virtual camera display
DPTZ Digital PTZ,Pan/Tilt/Zoom
Intelligent Function
Motion Detection 4×3Regional detecting, Sensibility 1~6 adjustable
Alarm Function
Alarm Trigger Motion Detection/Video Tampering/Abnormal procedure/Alarm Input/Storage Error/
Storage Full/IP Conflict/Network Disconnection
Alarm Action Alarm Record/Image Snap, Alarm Video/Image Upload(FTP/Email)
Network
Protocol TCP/IP,HTTP,DHCP,DNS,RTP/RTSP,FTP,PPPOE,SMTP,NTP
Compatibility ONVIF2.0
WiFi(Optional) IEEE802.11b/g/n
Interface
Network Port RJ45 10M/100M/1000M Ethernet
Alarm Input 1CH
Power Interface ø5.5-2.1mm round DC socket
Local Storage Up to 128G SD Card
Reset One button reset
General
Power Supply DC12V±10%
POE(optional) DC48V±10%
Power Consumption <9W
Working condition -15?~+50?@Humidity 10%~ 95%
Storage Condition -40?~+75?@Humidity 10%~ 95%
EMC CE,FCC
Colour White & Black
Protection Grade IP50
Product Size Φ148.5×57.5mm
Package 186×186×78mm
Weight(kg) N.W.:0.5 / G.W.:0.65
Optional Function -P:POE
