Model WP-TV5024D WP-TV5024M WP-TV5024T
Image Sensor AR0141 AR0130 IMX322
DSP 8060 8060 2421
Image Resolution 720P 960P 1080P
Effective Pixels 1MP,1280(H)*720(V) 1.3MP,1280(H)*960(V) 2MP,1920(H)*1080(V)
TV System PAL/NTSC PAL/NTSC PAL/NTSC
Electronic Shutter 1/25s~1/50,000s , 1/30s~1/60,000s
Sync System Internal
Usable Illumination 0.01Lux 0.01Lux 0.001Lux
S/N Ratio ≥50dB
Scanning System Progressive Scan
Video Output Mode TVI(BNC)
Focus Length 3.6/6/8mm
Pixels 2M Pixels
Auto Iris Support NO NO NO
IR Status Under 10 Lux by CDS
IR Power On CDS Auto Control
Day/Night Auto (ICR) / Color / B&W
OSD Menu Language No
White Balance Auto
Gain Control Auto
Noise Reduction 3D NR 2D NR 2D NR
Picture Adjustment No
OSD Support No
Weatherproof Housing YES, IP66
Anti-cut Bracket YES, 3-Axis
Dual Voltage NO
IR Cut Filter YES
Heater NO
Operation Temperature -10? ~ +50? RH95% Max
Storage Temperature -20? ~ +60? RH95% Max
Power Source DC12V±10%, 700mA
