Monocrystalline cells are notable for there dark blue/black color; they have cut edged boundaries because of the method of production. In normal conditions the conversion efficiency of sunlight to electricity in monocrystalline cells is much the same as for polycrystalline cells – however the advantage is that monocrystalline technology has the highest power to area ratio out of monocrystalline, polycrystalline and amorphous solar cells.
Monocrystalline panels are fantastic option for homes, offices, caravans and vehicle mounting due to the all rounded efficiency with all levels of light, working extremely well in areas of high light and even maintaining a fantastic output in low light or overcast conditions. They perform very well in hot and cool climates.
AREAS OF APPLICATIONS:
1. Telecomms
2. Solar power stations
3. Rural electrification, Small home power systems
4. Power supply for traffic, security, gas industry
5. 12V and 24V battery charging systems
6. Other industrial and commercial applications
ELECTRICAL PERFORMANCE
Electrical parameters at Standard Test Conditions (STC)
Nominal Maximum Power (Pmax): 250W
Optimum Operating Voltage (Vmp): 30.1V
Optimum Operating Current (Imp): 8.3A
Open Circuit Voltage (Voc): 37.2V
Short Circuit Current (Isc): 8.87A
Operating Temperature: -40?~+85?
Maximum System Voltage: 1000V (IEC) / 1000V (UL) / 600V (UL)
Maximum Series Fuse Rating: 15A
Power Tolerance: 0 ~ +5W
GENERAL CHARACTERISTICS
Dimensions (L/W/H): 1638 x 982 x 40mm (64.5 x 38.7 x 1.57in)
Weight 18.5kg (40.8 lbs)
