| Production Country |
UK |
| Weight (kg) |
0.1 |
| From the Manufacturer |
Minimum requirements (correct as of June 2022)<br />3GHz x64 processor.8GB RAM.Microsoft Windows 7.Recommended requirements<br />High performance x64 processor with at least 4 cores.Dedicated ATI or NVIDIA graphics card supporting OpenGL and Direct3D.16GB or more of RAM.Microsoft supported 64 bit Windows operating system.<br />In particular, note that if your graphics card does not satisfy the above requirements the software will run in Windows GDI mode. This means that display of the screen is handled by Windows and not your graphics hardware and therefore that some features of the software will not be available and the performance could be adversely affected. As a general rule, discrete graphics cards such as those from AMD (ATI) and NVIDIA will satisfy these requirements whilst chipset graphics such as those supplied by Intel will not. |
Name: Proteus 8 ProfessionalLicense: Already activated (No license registration needed)License validity: 5years.Users: 10Customer support: YesDelivery mode: Through rehmie
Proteus is a software package for computer-aided design of electronic circuits. The package is a system of circuit simulation based on models of electronic components adopted in PSpice. A distinctive feature of the Proteus Professional package is the ability to simulate the operation of programmable devices: microcontrollers, microprocessors, DSP, and more. Additionally, the Proteus package includes a PCB design system. Proteus Professional can simulate the following microcontrollers: 8051, ARM7,AVR,Motorola, PIC, Basic Stamp. The component library contains reference data.
Key Features
Library Parts. 15 million library parts integrated and on demand.
Assembly Variants. Easily create and manage product variants.
Report Generation. Dedicated reporting module for project documentation.
Design Rules.
High Speed Design.
Power Planes.
