Aembled DSO150 Oscilloscope Digital Multimeter with Latest Firmware BNC Probe Included Data oscilloscope meter Output
Features:
Adopt ARM Cortex-M3 proceor (STM32F103C8), and include a 2.4-inch color TFT display screen.
Used for secondary development on the basis of this kit, for example, it can be changed to Millivoltmeter, data loers.
Come with instructions, easy to install and operate.
With Auto/Normal/Single trier modes, easy to capture the moment waveform.
Available rising or falling edge trier.
Observable previous waveform before trier(negative delay).
Can freeze waveform display at any time(HOLD function).
With waveform parameter digital display, including frequency, period, duty ratio, MAX./MIN./AVG./Peak-Peak/virtual values.
Short-circuit and open-circuit detection: can help the user find out the soldering error.
TFT controller recognition function.
The SMD has been soldered, more suitable for electronic beginner.
Specifications:
Maximum Real-time Sampling Rate: 1MSa/s
Analog : 0-200KHz
Sensitivity Range: 5mV/div-20mV/idv
Maximum Input Voltage: 50Vpk (1X probe)
Input Impedance: 1Ms/20pF
Accuracy: 12 Bits
Record Length: 1024 points
Coupling Modes: DC / AC / GND
Time Base Range: 500s/Div - 10us / Div
Trier Modes: Auto, Normal, and Single
Trier Position: Center of Buffer
Supply Voltage: DC 9V(8-10V)
Current Consumption:~120mA @ 9V
Main Board Size: 94 * 65mm / 3.7 * 2.56in
Analog Board Size: 65 * 47mm / 2.56 * 1.85in
Screen Size: 52 * 40mm / 2 * 1.57in
About shippingShipping and Packaging All it will be double checked and well packed before sending.It will be dispatched within 2 business days ar buyers pay for the order. It usually takes about 14 to 18 working days for delivering the package to the destination(for remote areas,it may take a little longer).
Special Announcement:Please fill in the correct and detailed consignee, address and phone number in the order. For fast and correct delivery.If you do not receive order within 30 working days,please feel free to contact Customer Service before leaving Negative and Neutral Feedback, we will do our best to help you resolve the problem.TaxNo, you will only pay what is quoted as total cost at checkout, no more. You are not expected to pay any additional duties ores. If you are asked by Customs or our logistic partner to pay duties, please contact our Customer Service .
Your 100% satisfaction is very ant to usIf the product is not on good condition, You can return this product within 14 working days, please contact customer service center before returning.FeedbackYour satisfaction is our first priorityIf you receive the order and it is in good condition,we would be grateful if you would leave us 5 star Positive Feedback for the transaction.
Key Features
Origin:Mainland China
DIY Supplies:ELECTRICAL
Display resolution:320*240 Pixels
Digital Channels:1
Model Number:DSO150 Digital Oscilloscope
Record Length:1024 points
IS Battery Demountable:Yes
Display Size:2.9 Inches & Under
Certification:CE
Real Time Sampling Rate:1GSa/S
Max Waveform Capture Rate:60,000wfm/s
Band Width:100-349MHz
Sensitivity range:mv / div-20mV / idv
Coupling modes:DC / AC / GND
Accuracy:12 bits
Trier position:center of buffer
Trier modes:Auto, Normal, and Single
Supply voltage:DC 9V (8-10V)
What's In the Box
1Xembled DSO150 Oscilloscope Digital Multimeter with Latest Firmware BNC Probe Included Data oscilloscope meter Output
