| Model |
EZ9R34240 - Residual Current Circuit Breaker - 2P - 40A - 30 mA - AC type - 230 V |
| Production Country |
France, China |
| Size (L x W x H cm) |
7.2 X 3.6 X 8.2 |
| Weight (kg) |
0.1 |
| Certifications |
Eco Friendly |
| Color |
Grey |
| Main Material |
Plastic |
| From the Manufacturer |
NA |
| Care Label |
NA |
Easy9 RCCB
Residual Current Circuit-Breakers
Part of Easy Series
The residual current circuit breakers have been designed with improving protection levels in mind, providing enhanced leakage current protection to ensure all users avoid any electric shocks. Dependable, secured and designed to be easy to use, they are a must-have protection measure.
Features
Affordable switchgear you can depend on
Offering leakage current protection, the residual current circuit breakers make no compromises when it comes to reliability. Complete with a user-friendly design, the circuit breakers are easy to install and can be used in homes as well as small buildings.
- High quality design providing ease-of-use.
- User-friendly to allow for quick and simple installation.
- Availability when and where you look for it.
- High levels of reliability.
- Cost-effective to ensure you get a highly reliable product for an affordable price.
- Enhanced protection against electric shocks.
Benefits
Working to improve protection and reduce installation times, the robust residual current circuit breakers provide you with much needed leakage current protection, vastly reducing the chance of electric shocks.
· Simple and quick to install thanks to the accessible design.
· Provides enhanced protection to the areas you need it.
· Protection from leaks as well as electric shocks.
Applications
The residual current circuit breakers can be used at the Head of Group in your panel and are ideally suited to homes and small buildings.
Key Features
Range of product - Easy9
Product or component type - Residual current circuit breaker (RCCB)
Device short name - Easy9 RCCB
Poles - 2P
Neutral position - Left
[In] rated current - 40 A
Network type - AC
Earth-leakage sensitivity - 30 mA
Earth-leakage protection time delay - Instantaneous
Earth-leakage protection class - Type AC
Rated breaking and making capacity - 500 A
Rated conditional short-circuit current - Easy9 MCB: 4500 A 40 A
Device location in system - Outgoer
Network frequency - 50 Hz
[Ue] rated operational voltage - 230 V AC 50 Hz
Residual current tripping technology - Voltage independent
[Ui] rated insulation voltage - 440 V AC
[Uimp] rated impulse withstand voltage - 4 kV
Surge current - 250 A
Contact position indicator - Yes
Control type - Toggle
Mounting mode - Clip-on
Mounting support - DIN rail
Comb busbar and distribution block compatibility - Top: YES
9 mm pitches - 4
Colour - Grey (RAL 7035)
Mechanical durability - 5000 cycles
Electrical durability - AC: 2000 cycles 400 V AC 50 Hz
Connections - terminals - Tunnel type terminal (top or bottom) 1…35 mm² rigid, Tunnel type terminal (top or bottom) 1…25 mm² flexible
Tightening torque - 2.5 N.m top or bottom
Market segment - Residential, Small commercial
Standards - IEC 61008-1
Product certifications - EAC, GOST-R, CE
IP degree of protection - IP20
pollution degree - 2 conforming to IEC 61008-1
Tropicalisation - 2
Relative humidity - 95 % at 55 °C
Ambient air temperature for operation - -25…60 °C
Ambient air temperature for storage - -40…85 °C
What's In the Box
1 Easy9 RCCB - 2P - 40A - 30 mA - AC type - 230 V
