The TINSE Simplicity 3KVA 24V Hybrid MPPT Inverter by Right Click Technologies Ltd. is a robust and efficient power solution designed for both personal computers and home appliances. With a capacity of 3000W/3000VA, it offers a pure sinewave output with nominal voltages of 220/230VAC±5% and a frequency of 50Hz. It features a highly efficient Maximum Power Point Tracking (MPPT) solar charge controller with a max PV array power of 3000W and a wide MPPT voltage range of 30-450VDC, ensuring optimal solar energy utilization. The inverter supports a battery voltage of 24VDC with advanced charging methods, including CC/CV. It boasts a durable design with dimensions of 348 x 270 x 95 mm and a weight of 6 kg, making it compact and portable. The device includes overload protection, high-efficiency rates (97% PV to INV, 90%-93% battery to INV), and versatile input voltage ranges for different applications, all while operating within a temperature range of -10°C to 50°C. With an RS232 communication interface, this inverter ensures seamless integration and monitoring, making it an ideal choice for reliable and efficient power management.
SPECIFICATIONS
BATTERY |
|
Battery Voltage |
24VDC |
Floating Charge Voltage |
27VDC |
Over Charge Protection |
31VDC |
Charging Method |
CC/CV |
Solar Charge & AC Charger |
|
Solar Charge TYPE |
MPPT |
Max. PV Array Power |
3000W |
Max. PV Array Open Circuit Voltage |
450VDC |
PV Array MPPT Voltage Range |
30-450VDC |
Max. Solar Input Current |
15A |
Max. Solar Charge Current |
80A |
Max. AC Charge Current |
60A |
PHYSICAL |
|
Dimensions D x W x H (mm) |
348 x270 x95 |
Net Weight (Kg) |
6 |
Communication Interface |
RS232 |
ENVIRONMENT |
|
Operating Temperature Range |
-10C to 50 C |
Storage Temperature |
MODEL |
Simplicity TS3000M |
Capacity |
3000W/3000VA |
Parallel Capability |
NO |
INPUT |
|
Nominal Voltage |
230V AC |
Acceptable Voltage Range |
170-280VAC (For personal computer); 90-280vac (For home appliances) |
Frequency |
50/60 Hz (Auto sensing) |
OUTPUT |
|
Nominal Voltage |
220/230VAC±5% |
Surge Power |
6400VA |
Frequency |
50Hz (Auto sensing) |
Waveform |
Pure sinewave |
Transfer Time |
10ms(For personal computer); 20ms (For home appliances) |
Peak Efficiency (PV to INV) |
97% |
Peak Efficiency (Batter to INV) |
90%-93% |
Overload Protection |
5s@>=150% load; 10s@110%-150% load |
Crest Factor |
3:01 |
Admissible Power Factor |
1.0 |
