Size (L x W x H cm) |
26.20X13.20X2.20 |
Weight (kg) |
0.305KG |
Color |
Yellow |
Description:
Using probe pen design, thishas fast and high-precision detection. Featured LCD display, thisis easy to read.
Thissupports measurement of DC current, AC/DC voltage, resistance and HFE, which is multifunctional and practical.
It is constructed of ABS material.
The length of this product is 122.9mm, the width is 68mm and the height is 24.4mm.
Thisis suitable for electrical measurement.
Item Name:
Material: ABS
Power Supply: 9V 6F22 Battery (Not Included)
Liquid Crystal Display: 31/2 Bits
Maximum Reading: 1999
DC Voltage: 200mV/2000mV/20V/200V/1000V
AC Voltage: 200V/750V
DC Current: 200uA/2000uA/20mA/200mA/10A
Resistance: 200Ω/2kΩ/20kΩ/200kΩ/2000kΩ
Transistor: NPN,
Features: Wide Voltage, Portable, Precise
Size Details:
L: 122.9mm/4.84", W: 68mm/2.68", H: 24.4mm/0.96"(Approx.)
Notes:Due to the light and screen setting difference, the item's color may be slightly different from the pictures.
Please allow slight dimension difference due to different manual measurement.
Package Includes:1 x
2 x Probe Pens
1 x English User Manual
What's In the Box
1 x
