4G / 3G / 2G / GSM / GPRS / GNSS HAT For Raspberry Pi

₦ 261,911.86 ₦ 275,696.69 -5%

0 No Reviews

Product SKU: RENG377645

Brand: Generic

Quantity

In Stock

100% Secure Payments

TrustPay

Pay Online Delivered T&C^*

Delivery Information

Shipped from overseas and normally delivered between 20-35 days

Have one to sell? Sell on rehmie

Product Specifications
Description

Model	B15345NHD=ZY15601963
Production Country	China
Size (L x W x H cm)	15 x 8 x 3cm
Weight (kg)	0.26
Color	Multicolor
Main Material	Multi-Material

4G / 3G / 2G / GSM / GPRS / GNSS HAT for Raspberry Pi
4G/3G/GNSS HAT for Raspberry Pi, Based on SIM7600E-H

Applicable Region
1. SIM7600A-H is mainly applicable in North America (US, CA, MX), SIM7600E-H is mainly applicable in Southeast Asia, West Asia, Europe, Africa, SIM7600CE-T is mainly applicable in China.
2. Please check the supported bands according to your local service provider, select the proper one when placing order.

Overview
1. The SIM7600A-H 4G HAT is a 4G communication and GNSS ing module, which supports LTE CAT4 up to 150Mbps for downlink data transfer. it is pretty low power consumption.
2. You can connect this 4G module with computer to surf the Internet, or attach it onto Raspberry Pi to enable functions like 4G high speed connection, wireless communication, making telephone call, sending SMS, global ing, etc.

Features
1. Raspberry Pi connectivity, compatible with Raspberry Pi Zero/Zero W/Zero WH/2B/3B/3B+
2. Support dial-up, telephone call, SMS, MMS, mail, TCP, UDP, DTMF, HTTP, FTP, etc.
3. Support G P S, BeiDou, Glonass, LBS base station ing
4. Onboard USB interface, to test AT Commands, get G P S ing data, and so on
5. Onboard CP2102 USB to UART converter, for serial debugging
6. Breakout UART control pins, to connect with host boards like Arduino/STM32
7. SIM card slot, supports 1.8V/3V SIM card
8. Onboard audio jack and audio Decod er for making telephone call
9. 2x LED indicators, easy to monitor the working status
10. Onboard voltage translator, operating voltage can be configured to 3.3V or 5V via jumper
11. Baudrate: 300bps ~ 4Mbps (default: 115200bps)
12. Autobauding baudrate: 9600bps ~ 115200bps
13. Control via AT commands (3GPP TS 27.007, 27.005, and V.25TER command set)
14. Support SIM application toolkit: SAT Class 3, USAT
15. Come with development resources and manual (examples for Raspberry Pi/Arduino/STM32)

Communications Specifications
1. Band:
- LTE
-- SIM7600A-

Key Features

4G / 3G / 2G / GSM / GPRS / GNSS HAT for Raspberry Pi
4G / 3G / 2G / GSM / GPRS / GNSS HAT for Raspberry Pi
4G / 3G / 2G / GSM / GPRS / GNSS HAT for Raspberry Pi
4G / 3G / 2G / GSM / GPRS / GNSS HAT for Raspberry Pi
4G / 3G / 2G / GSM / GPRS / GNSS HAT for Raspberry Pi

What's In the Box

1 x package
