Description: Dominant Frequency: 240MHZ; Flash: 32M-Bits
Processor: Tensilica LX6 Dual Core; Master chip: ESP32
LoRa chip: SX1276 SX1278; Support frequency band: 868-915MHZ/433MHz
Open communication distance: 2.8KM; Computing capacity: up to 600DMIPS
Dual-mode Bluetooth: traditional Bluetooth and BLE low-power Bluetooth; Development environment: perfect support for Arduino
Operating voltage: 3.3-7V
Operating temperature range: -40-90 °
Receiver sensitivity: -139dBm (SF12, 125KHZ)
UDP continuous throughput: 135Mbps
USB adapter chip: CP2102
Support mode: Sniffer, Station, softAP and Wi-Fi Direct
Transmit power: 19.5dBm@11b, 16.5dBm@11g, 15.5dBm@11n
Data rate: 150Mbps @ 11n HT40, 72Mbps @ 11n HT20,
54Mbps @ 11g, 11Mbps @ 11b
Color: As Shown
Material: PC+metal
Package Contents:
1 x OLED Display Bluetooth WIFI Kit
Only the above package content, other products are not included.
Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
Key Features
Durable and good quality
SX1276
SX1278
ESP32 LoRa 868MHz
32 Development Board
OLED Display Bluetooth WIFI Kit
The details are as described above
What's In the Box
1 x OLED Display Bluetooth WIFI Kit
