Model |
SF300 |
Size (L x W x H cm) |
105 x 105 x 34mm |
Weight (kg) |
0.3 |
Color |
Black |
The SF300 is an IP based fingerprint terminal, which operate in both network mode and standalone mode. it can connect with ZKAccess3.5 software for access control and time attendance management. Wiegand output makes SF300 flexible to connect with ZK or any 3rd party controllers as a slave reader. Additionally, wiegand input allows two units of SF300 to configure with each other and utilize Master & Slave solution, which requires user verification at both entrance and exit.
Key Features
Model: SF300
LCD: 2.8 inch capacitive touch screen
Fingerprint Sensor: ZK Optical Sensor (500DPI)
Algorithm Version: ZKFinger VX10.0
Communication: TCP/IP, USB Host
Fingerprint Capacity: 1,500
Card Capacity (Optional): 5,000 (EM/Mifare)
Records Capacity: 80,000
Access Control Interface: Electric lock, Door sensor, Alarm, Exit button, Door Bell
Functions: DST, Automatic Status Switch, Record query, T9 input, 9 digit user ID, Anti-pass back, Scheduled-Bell, Printer(Optional), ADMS(Optional) ,webserver(Optional)
Wiegand Signal: Wiegand input & output
Aux. Input: 1ea for linkage function
Power Supply: DC 12V/3A
Operating Temperature: 0 ~ 45°C (32°~113°F)
Operating Humidity: 20 ~ 80%
Dimension(L x W x H): 105 x 105 x 34mm
