PRODUCT DESCRIPTION
Zillion Automatic pump pressure control switch is used in surface water pump systems, it examines the water pressure automatically, stop the pump in the case of water shortage, protect the pump from damage caused by dry- running.
Completely replaced traditional pump control system composed of pressure switch, pressure tank and check valve etc. We do not recommend this controller to be used with submersible pump.
Its major use is to boost pressure with maximium water output in surface water pumping systems.
SPECIFICATION
Maintains Pressure
Maintains Flow
Easy To Operate , Touch Buttons
Lights Indication for Operations
Automatic Cut Off
Automatic Turns On
Frequency : 60 Hz
Max Current : 10 Amp
Max. Working Bar Pressure : 10 Bar
Connection : 1 Inch
Input Voltage 110V / 220V
Comes With 2 Black Cables For Safe Hard Wiring to be inserted into the pumping and power source.
Pressure Adjustable- YES
Pressure Guage- NO
Protection Grade : Highest IP65 for outdoor use
Used for Jet Pump - Garden Pump - Self-Priming Pumps.
Maximum Operating Temperature 60 Degree
Warranty- 1 Year
Insist on ZILLION quality brand of automatic pressure control switches
