H4/H4W/H4BModel: H4 wired/H4W wireless/H4B bluetoothTransmission method: wired/wireless/BluetoothScanning mode: CMOS image scanningCommunication distance: open distance wireless 80M, Bluetooth 10MResolution: 752×480 pixelsBattery alarm: the buzzer sounds five times in a rowLight source: 265LUX (130NM)Scanning width: 30MM@scanner window, 220MM@200MMLight source type: LED (650NM)Scanning angle: rotate 30°, tilt ± 65°, deflection ± 55°Scanning speed: 200 times/secondPrompt mode: buzzer, LED indicatorAccuracy: ≥4milTimes of use: 63000 timesPrinting contrast: ≥30%Weight: 128G (without cable)Maximum power: 1.33WDimensions: 160x66x90mm (LxWxH)Voltage: (3.3V5V)±5%Wire: 1.5MMaximum current: 330mAColor: blackSleep current: 50μAShell material: ABS+PCStandby time: 30 seconds into standbyWorking temperature: 0℃~50℃(32℉~122F)LED Indication: Connection Indicator: GreenStorage temperature: -40℃~60℃(-40℉~140F)Scanning light: greenRelative humidity: 5% 95% (non-condensing)Data interface: support USB/RS232 interface, drive-freeAmbient lighting: 0-100000lxOperating system: WINDOWS/LINUXElectrostatic protection: ±8KV (contact discharge); ±15KV (air discharge)Reading distance:
Key Features
【Support Screen Scanning】: The wireless barcode reader has the function of collecting digital images and can read barcodes on the screen of mobile phones and laptops. Has instant upload mode and storage mode. Offline storage mode can be used in environments away from the wireless receiver. It can store up to 1500,000 barcode information.
【Super Decoding Ability】: Easily capture all common barcodes on labels and mobile phone displays. Even vague, incomplete barcodes can be decoded and uploaded super fast. 2D: QR Code, Data Matrix, PDF417, Aztec Code, Maxicode. 1D: JAN/EAN-13, JAN/EAN-8, UPC-A, UPC-E, Code11, Code32, Code39, Code 39 Full ASCII, Code93, Code128, Codabar (NW-7), Interleaved 2 of 5, Matrix 2 of 5, Industry 2 of 5, Standard 2 of 5, PLESSEY, MSI, ITF14, ISBN, ISSN, GS1 Databar, GS1-128 (UCC/EAN128), ISBT-128.
【Wide application】: Supermarkets, warehouses, logistics, libraries, restaurants, retail stores, banks, postal services, industrial and manufacturing process management, etc.
【Charging Dock and Working Time】: Once the scanner is docked and connected to the USB cable, charging can begin. When charging, the automatic induction mode can be turned on to scan, so that the scanning and charging can be synchronized.
What's In the Box
Wired version: H4 scanner, USB cable, product manual
