Model |
CW200 |
Size (L x W x H cm) |
17 x 6 x 9 |
Weight (kg) |
0.35 |
Color |
black |
Main Material |
Plastic |
- 【3-in-1 Connection Design】:Barcode scanner can support USB wired connection and wireless connection(2.4G wireless or Bluetooth connection). You can easily connect with your laptop, PC, mobile phone, tablet.Work with Windows XP/7/8/10, Mac OS, Windows Mobile, Android OS, iOS.
- 【Support screen scan】: Wireless BarCode Reader features the function of collecting digital image, which makes it capable of reading barcodes on your phone and laptop screen.has an instant upload mode and a storage mode. The offline storage mode can be used in an environment far away from the wireless receiver. It can store up to 1500,000 bar code information.
- 【Super Decoding Ability】:Easily capture all common bar codes (2D and 1D) on labels as well as on mobile phone displays. Even blurring, incomplete barcodes can be decoded and uploaded at superfast speeds. 2D: QR Code、 Data Matrix、PDF417、Aztec code、Maxicode. 1D:JAN/EAN-13、JAN/EAN-8、UPC-A、UPC-E、Code11、Code32、Code39、Code 39 Full ASCII、Code93、Code128、Codabar(NW-7)、Interleaved 2 of 5 、Matrix 2 of 5、Industrial 2 of 5、Standard 2 of 5、PLESSEY、MSI、ITF14、ISBN、ISSN、GS1 Databar、GS1-128 (UCC/EAN128)、ISBT-128.
- 【Wide Application】: Supermarkets, Warehouses, Logistics, Libraries, Restaurants, Retail Stores, Banks, Postal Service, Industrial and Manufacturing Process Management, etc.
- 【Charging base & Working Time】:2200mAh The battery can work continuously for 16 hours, and the standby time can grow up to 15 days. When the scanner is inserted into the base and connected to the USB cable, charging can begin. The auto-sensing mode can be turned on to scan during charging,Allows scanning and charging to progress together.
Key Features
Image (pixels): 640 pixels (H) * 480 pixels (v)
Light source: Aiming: 617 nm LED; illumination: 6500K LED
Code reading ability: 2D: QR Code, Data Matrix, PDF417, Aztec, Maxicode.1D: UPC / EAN / JAN, UPC-A & UPC-E, EAN-8 & EAN-13, JAN-8 & JAN-13, ISBN / ISSN, Code 39 (with full ASCII), Codabar (NW7), Code 128 & EAN 128, Code 93, ect.
Scanning distance: 40-200mm @ UPC / EAN 13mil PCS = 90%; 20-250mm @ QR 20mil PCS = 100%
Scanning angle: 65 ° elevation / 30 ° / 55 °
Reading accuracy: ≥4mil
Physical parameter
Size: 173mm * 67mm * 94mm (length * width * height)
Packing box size: 220mm * 70mm * 95mm (length * width * height)
Weight: 210 grams
Charging cable length: straight 1 meter
Battery parameters
Capacity: 2200mAh
Charging method: line charger
Charging time: 5h
Working time: 9h
What's In the Box
- Barcode Scanner*1
- Charging base*1
- USB cable*1
- Product manual*1
