Felicity 3kva-24v Solar System Inverter With 80a Built-in Mppt Charge Controller
The Felicity Solar IVEM3024 is a versatile inverter/charger that combines the functions of an inverter, MPPT solar charger, and battery charger. It features easy-to-use button operations for adjusting settings such as battery charging current and solar charger priority. This compact device provides reliable uninterruptible power support and comes equipped with a comprehensive LCD display that allows users to configure settings based on various applications and voltage requirements..
Specifications
- Nominal DC Input Voltage: 24V - Rated Output Power: 3000VA / 3000W - Max Efficiency: 95% - Peak Efficiency: 93% - Type: Pure sine wave inverter - Built-in Charge Controller: 80A MPPT solar charge controller
Features:
- Configurable input voltage range for home appliances and personal computers via LCD settings. - Configurable battery charging current based on applications, adjustable via LCD settings. - Configurable AC/Solar charger priority through LCD settings. - Compatible with mains voltage or generator power. - Auto restart function when AC power is restored. - Inverter can operate without a battery. - Lithium battery activation feature. - Cold start capability. - Supports energy storage from diesel generators. - Charging protection integrated. - Maximum PV Voltage: 500V - AC coupling is available for retrofitting existing solar systems. - Can operate with a maximum of 12 units in parallel.
This information is designed to clarify the specifications and features of the inverter.
5kva 48v Must Hybrid Inverter - PV18-5048 VHM with 80A MPPT Charge Controller
MUST 5KVA 48V Hybrid Solar Inverter with 80A MPPT Charge Controller
features
Pure sine wave inverter
built-in 80A MPPT Solar charger Controller
Compatible to main voltage or generator power
Auto restart while AC or Solar is recovering
Wide range of AC input voltage
lntelligent protection with higher class of security
Rated output power(VA)= 5000VA
Rated output power(W) = 5000W
Built in MPPT : 80A
Norminal DC input voltage= 48V
Maximum Solar Voltage= 145v
Output voltage waveform= Pure sine wave
Solar inverter, or converter, or PV inverter converts the variable DC output of a photovoltaic (PV) solar panel into a utility frequency alternating current (AC) that can be off-grid electrical network. It is a critical balance of system & ndash;component in a solar power system, allowing the use of ordinary AC-powered equipment
Introducing the 5kva 48v Must Inverter: a high-performance power backup solution designed to meet the demands of your energy needs. With its robust 48V system, this inverter offers exceptional power output and compatibility with a wide range of appliances and equipment.
The 5kva 48v Must Solar Inverter ensures uninterrupted power supply, making it ideal for both residential and commercial applications. Whether you need to power essential appliances in your home or run critical machinery in your workplace, this inverter delivers reliable and efficient performance.
Must Solar is a trusted brand known for its innovative and reliable power solutions. The 5kva 48v Must Solar Inverter incorporates advanced features such as intelligent charging, comprehensive protection mechanisms, and a user-friendly interface, ensuring a hassle-free experience.
With its sleek design and durable construction, this inverter is built to last. It is easy to install and operate, making it suitable for both professionals and homeowners alike.
This is a multi-functional inverter/charger, combining the functions of Inverter, MPPT Solar Charge Controller and battery charger to offer uninterruptible power supply. This inverter comes with a whopping 80A inbuilt Mppt solar charge controller with a capacity of 145V max input voltage. Its comprehensive display offers User-friendly configuration and easy-accessible button operation such as battery charging current, AC/Solar charger priority, and acceptable input voltage based on different applications.
3KW/24V Hybrid/Heavy Inverter (2500W-MPPT) Product Description
Introducing the 3KW/24V Hybrid/Heavy Inverter (2500W-MPPT), your go-to solution for efficient energy management. This powerful inverter is designed to meet your specific needs, making it ideal for both homes and businesses.
Efficient Charging and Power Management This inverter features 3 Steps charging, ensuring your batteries receive the right charge every time. The integrated 80A MPPT Solar Charge Controller maximizes energy from your solar panels. You can adjust the charging voltage and current to match your battery type, giving you full control over the process.
Robust Safety Features Safety is a priority with the 3KW/24V Hybrid/Heavy Inverter. It provides overload and short-circuit protection to safeguard your devices from power surges. You can also set the battery low voltage shutdown point to prevent battery damage, prolonging battery life and maintaining consistent power.
Customizable and Flexible Settings This inverter offers adjustable inverter voltage and frequency settings, allowing easy integration with various systems. You can choose between wide and narrow utility input voltage ranges based on your needs. The power-save mode helps conserve energy when demand is low.
Utility and Battery Priority Control The inverter lets you set utility or battery priority, ensuring your preferred power source is always used first. Whether you prioritize grid power or battery backup, this feature offers the flexibility you need. You can also control when your batteries charge from the grid with the utility charging switch.
Smart Monitoring and Connectivity Optional WIFI connectivity allows remote monitoring of your inverter. Manage your power system from anywhere. The inverter also supports BMS lithium battery communication through a CAN port, making it compatible with modern lithium battery systems.
Versatile Battery Compatibility This inverter works with both acid and lithium batteries, adapting to different setups. The acid or lithium select feature ensures optimal performance regardless of your battery type.
Conclusion The 3KW/24V Hybrid/Heavy Inverter (2500W-MPPT) is powerful, versatile, and efficient. With customizable settings, robust safety features, and smart connectivity options, it & rsquo;s the perfect choice for optimizing your power system.
3.6kw Hybrid Inverter with 2 MPPT ChargerSmart Load Management Via Dry ContactUPS Function & lt; 10MS Transition 1.5 DC/AC RATIOSingle PhaseMax. recommended PV power 7500WGrid Side Parallel
Specs
Max. Recommended PV Power
7500W
Max. DC Voltage
550V
AC Nominal Power
3680W
Rated Output Current
16A
Max efficiency
97.2%
DC Switch
Yes
AC/DC Surge Protection
Yes
Dimensions (W/H/D)
565/456/188mmm
Weight
27KG
SMS-6.2KVA 48V Hybrid Inverter: Get the Best out of Solar EnergyExperience the ultimate combination of reliable backup power and clean energy generation with the SMS-6.2KVA 48V Hybrid Inverter! This powerhouse delivers a robust 6200W of continuous output, ensuring your essential appliances remain operational during outages. Plus, the built-in solar charger allows you to harness the sun & rsquo;s energy to reduce your dependence on the grid and potentially slash your electricity bills.
Constant Power (6200W): Say goodbye to power cuts! The SMS-6.2KVA seamlessly switches on during outages, providing uninterrupted power for your critical devices.48V Battery Compatibility: Integrates seamlessly with a 48V battery system (sold separately) to store excess solar energy and provide backup power when needed.Embrace Solar Energy: Connect solar panels (sold separately) to the inverter and utilize the sun & rsquo;s power to recharge your batteries and offset your electricity consumption.MPPT Solar Charging Technology: Maximizes solar energy harvest from your panels by operating at their ideal voltage output for optimal efficiency.Wide MPPT Voltage Range (60-450Vdc): Accommodates various solar panel configurations by accepting a broad MPPT voltage range.High Conversion Efficiency (up to 97%) : Minimal energy loss during operation translates to cost savings.
Technical Specifications:General Spec:Model Name: SMS-6.2KW-48VModel Number: SMS-6.2KW-48VColor: Golden and BlackOperating Temperature Range: -10 & deg;C to +50 & deg;CCertifications: RoHS Compliant, CEManufacturer: Made in ChinaDimensions and Weight: Not specifiedPV Input (Solar Input):Nominal Operating Voltage: 240VdcMaximum PV Voltage (Vmax PV): 500VdcPV Input Voltage Range: 60Vdc to 450VdcMaximum Input Current (Imax PV): 27AFull Load MPPT Range: 240Vdc to 450VdcRated Power: 6500WMaximum Solar Charging Current: 120AGrid/AC Output (Utility Output):Nominal Output Voltage: Selectable 220Vac, 230Vac, or 240VacFeed-in Grid Voltage Range: 195Vac to 253VacFeed-in Grid Frequency Range: 49Hz to 51Hz & plusmn; 1HzNominal Output Current: 27.0APower Factor Range: Greater than 0.99Maximum Conversion Efficiency (DC/AC): 97%Nominal Operating Frequency: 50/60Hz (selectable)Two Load Output Power:Full Load: 6200WMaximum Main Load: 6200WMaximum Second Load: 2066WMain Load Cut Off Voltage: 44VdcMain Load Return Voltage: 52VdcAC Input (Grid Charging):Nominal Operating Voltage: 230VacMaximum Input Current: 40ANominal Operating Frequency: 50/60Hz (selectable)Surge Power: 12400VAMaximum AC Charging Current: 100ABattery:Battery Voltage Range: 40Vdc to 63VdcMaximum Battery Current: 125A
The Huawei Power Module Comes with 2 batteries (5kWh each) is an advanced, high-performance solution designed for efficient energy management in residential, commercial, and industrial applications. Engineered with versatility, reliability, and durability in mind, this energy storage system integrates seamlessly with renewable energy sources, offering robust energy storage, backup power, and grid independence. Its modular design and flexible installation options ensure adaptability to diverse needs while maintaining optimal performance.
Basic Parameters
Dimensions (W * H * D)
Single power module: 700 mm x 246 mm x 152 mm
Single battery module: 700mm x 390 mm x 158 mm
Base (mandatory for floor installation): 700 mm x 65 mm x 147 mm
Base (mandatory for wall-mounted installation): 643 mm x 110 mm x 176 mm
Weight Approx. 17 kg for a single power module
Approx.50 kg for a single energy storage module
Installation Mode Wall-mounted/ground-mounted
Degree of protection IP66
AC input
Input voltage 200/208/220/230/240V AC
Input current Max. 30 A
Frequency 50/60Hz
Maximum bypass input power 6kW
Lightning protection Differential mode: 3KA; common mode (two-wire pair PE): 5KA; 8/20
The Huawei 6kva Power Module Comes with 3 batteries (5kWh each) is an advanced, high-performance solution designed for efficient energy management in residential, commercial, and industrial applications. Engineered with versatility, reliability, and durability in mind, this energy storage system integrates seamlessly with renewable energy sources, offering robust energy storage, backup power, and grid independence. Its modular design and flexible installation options ensure adaptability to diverse needs while maintaining optimal performance.
Basic Parameters
Dimensions (W * H * D)
Single power module: 700 mm x 246 mm x 152 mm
Single battery module: 700mm x 390 mm x 158 mm
Base (mandatory for floor installation): 700 mm x 65 mm x 147 mm
Base (mandatory for wall-mounted installation): 643 mm x 110 mm x 176 mm
Weight Approx. 17 kg for a single power module
Approx.50 kg for a single energy storage module
Installation Mode Wall-mounted/ground-mounted
Degree of protection IP66
AC input
Input voltage 200/208/220/230/240V AC
Input current Max. 30 A
Frequency 50/60Hz
Maximum bypass input power 6kW
Lightning protection Differential mode: 3KA; common mode (two-wire pair PE): 5KA; 8/20
DYNAMBYTE Hthium Heroe-e1 Power Supply Inverter - 200w - 1kwh
This 200W Hybrid Inverter with 1kWh Lithium Battery is a compact and efficient solar energy solution designed to provide reliable off-grid power. The inverter is capable of converting DC power generated from solar panels or stored in batteries into AC power for household appliances. Its hybrid functionality allows it to seamlessly integrate both solar and grid power, optimizing energy usage based on availability. The included 1kWh lithium battery offers fast charging, long lifespan, and a stable energy supply for low power consumption applications, such as lighting, small appliances, or backup power. Ideal for homes, RVs, or cabins.
This Inverter Ensures Energy Independence While Reducing Reliance On Conventional Power Sources. Its Lightweight Design Makes It A Convenient Choice For Those Looking To Reduce Energy Costs Or Maintain Power During Outages.
10kw Hybrid Inverter With 2 MPPT ChargerSmart Load Management Via Dry ContactUPS Function & lt; 10MS Transition1.5 DC/AC RATIOThree PhaseMax. recommended PV power 15000WGrid Side ParallelWide battery voltage 100-550V
Max recommended PV Power 15000W Max
DC Voltage1000
AC Nominal Power10000WMax.
output current15.2AMax
charging and discharging current 25A
Type of battery lithium/lead-acid
Max efficiency98.2%
Dimensions (W/H/D)505/453/198mm
Weight30KG
The 3KW/24V Hybrid Inverter (3000W-MPPT) delivers reliable and efficient power management for a variety of applications. With its pure sine wave output, it ensures smooth and stable operation of all your electronic devices and appliances. Designed for both residential and commercial use, this inverter integrates seamlessly with your power setup, combining solar energy, AC utility, and battery power to provide a continuous and uninterrupted power supply.
Key Features:
Pure Sine Wave Output: Benefit from high-quality power that closely mimics the utility grid. This ensures your sensitive electronics and appliances operate efficiently and without interference.
Smart LCD Setting: Easily monitor and adjust working modes, charge current, and voltage through the intuitive LCD interface. This feature simplifies system management and provides real-time insights.
Built-in MPPT Solar Charge Controller: Maximize your solar power generation with the MPPT controller. It efficiently tracks the maximum power point to optimize the use of available solar energy.
High PV Array Open Circuit Voltage: The inverter supports a broad range of solar panels with a maximum PV Array Open Circuit Voltage of 450V. This flexibility allows for easy integration with your existing solar setup.
Protection Features: The inverter includes comprehensive protection mechanisms, including overload, short circuit, and deep discharge protection. These safeguards help maintain the longevity of your system and protect your appliances.
Cold Start Function: Enjoy uninterrupted power even when grid power is unavailable. The cold start function ensures your inverter can start up and supply power in any situation.
Monitoring and Connectivity: Track and manage your power system easily with USB and RS485 monitoring functions. Additionally, the optional WiFi remote monitoring feature allows you to manage your system from anywhere.
Parallel Operation Capability: Increase your system & rsquo;s power capacity by connecting up to 9 units in parallel. This scalability ensures your power solution can grow with your needs.
8kva 48v Felicity Hybrid Inverter With Inbuilt 10000w Mppt Controller
This is a multi-functional inverter/charger, combining the functions of an Inverter, MPPT Solar Charge Controller, and battery charger to offer an uninterruptible power supply.
This inverter comes with a whopping 150A inbuilt Mppt solar charge controller with a capacity of 450V PV input.
Its comprehensive LCD display offers a User-friendly configuration and easy-accessible button operations such as battery charging current, AC/Solar charger priority, and acceptable input voltage based on different applications.
This inverter has a Cold Start Function: The ability to supply load on Panel alone without connecting the battery, and has the capacity to receive up to 450V Panel Voltage input.
Features:
Pure Sine Wave Inverter
150A built-in MPPT solar charge controller
Configurable input voltage range for home appliances and personal computers via LCD setting
Configurable battery charging current based on applications via LCD setting
Configurable AC/Solar Charger priority via LCD setting
Compatible with mains voltage or generator power
Compatible with all types of batteries including Lithium Ion battery
Auto restart while AC is recovering
Overload/Over Temperature/ Short Circuit protection
Inverter running without battery
Lithium battery activation function
Cold start function
Ability to take in high amounts of solar panels up to 450V
When batteries are full, this inverter supply loads directly thereby conserving the battery for night use.
This is the best inverter for clients that want to run a pumping machine on their inverter. ( Note: Clients should use the pumping machine during the peak period I.e 12 pm to 3pm normal sunny day)
3KW/24V Hybrid Inverter (3000W-MPPT). Designed for both flexibility and reliability, this inverter seamlessly operates with or without a battery, ensuring uninterrupted power supply in diverse conditions.
Key Features:
450V/3000W MPPT Technology: Maximize solar energy utilization with our advanced Maximum Power Point Tracking (MPPT) feature, delivering optimal performance and efficiency.
High Charging Current: Enjoy faster battery charging with a high charging current capability, enhancing energy storage and reliability.
Wide PV Input Voltage Range: Accommodate a broad range of solar panel configurations with a high input voltage range.
Cost-Effective Solution: Achieve superior performance at an affordable price, making it a smart investment for your energy needs.
Pure Sine Wave Output: Benefit from clean and stable power for sensitive electronic devices, ensuring reliable operation and longevity.
Cold Start Function: Power up even in low-light conditions with the cold start feature, making it ideal for diverse environments.
Optional Anti-Dusk Kit: Enhance durability and performance with an optional anti-dusk kit, protecting against dust and debris.
Comprehensive LCD Display: Easily monitor and configure settings with a clear and user-friendly LCD display.
Smart Battery Charger Design: Optimize battery performance with a sophisticated charger design, ensuring efficient energy use and extended battery life.
Auto Restart Function: Experience automatic recovery and uninterrupted power when AC power is restored.
Overload and Short Circuit Protection: Safeguard your system with built-in protection features against overloads and short circuits.
Compatible with Mains Voltage or Generator Power: Enjoy flexibility in power sources, compatible with both mains electricity and generator power.
Configurable AC/Solar Input Priority: Customize your energy priorities via LCD settings to suit your specific needs.
Selectable Input Voltage Range: Adapt to various home appliances and personal computers with adjustable input voltage settings.
Whether you & rsquo;re upgrading your home energy system or seeking a reliable power solution, the 3KW/24V Hybrid Inverter offers unmatched efficiency, flexibility, and performance.
3KW/24V Hybrid Inverter (3000W-MPPT) Features
Operates with or without battery
450V/3000W MPPT
High Charging Current
High PV input voltage range
Cost effective Inverter
Output power factor 1
Wide DC input range
Cold start function
Optional anti-dusk kit
Inbuilt MPPT Solar Charger
Pure Sine wave Solar Inverter
Selectable high charging current
Auto restart while AC is recovering
Overload and short circuit protection
Compatible to mains voltage or generator power
Configurable AC/Solar input priority via LCD setting
Smart battery charger design for optimized battery performance
Comprehensive LCD Display: For monitoring and configuration
Selectable input voltage range for home appliances and personal computers
