30A 40A 60A 100A Wind Solar Hybrid Controller MPPT LCD Dual USB 12V 24V 36V 48V 60V Battery Charging Regulator
Description:
The BL4600 wind solar hybrid charge controller is the strongest current focus tracking MPPT charging and boosted MPPT charging.
The first group of batteries is to track the current and focus on the highest power point of the MPPT to adjust the internal charging method to maximize the conversion of light energy into electrical energy. The second set of batteries is MPPT charging with low-voltage boost and high-voltage constant voltage tracking. Please recognize the technical characteristics when purchasing, so as to avoid misunderstanding.
PRODUCT FEATURES:
1. Industrial-grade main control , 16-level AD sampling accuracy, accurate real-time display of temperature, charging current, and discharging current, and theulative power generation is clear at a glance
2. Auto-focus MPPT tracking charging, high charging efficiency, non-stop detection during the charging process two-way focus tracking. Input 15V to 40V boost MPPT for efficient charging.
3. Large-screen LCD display, adjustable charging and discharging parameters UItra-wide charge and discharge can be adjusted. As long as you understand the characteristics of the battery and set its corresponding charging parameters, you can charge any battery. The output power off minute and hour can be adjusted, which is more convenient (the market only has no minute adjustment)
4. Complete 3-stage charge management, effectively protect the battery, and the battery is more durable.This controller is suitable for all kinds of lead-acid batteries (including open, sealed, and colloida. Lithium batteries require user-defined parameters).
5.To charge the 12V/24V/36V/48V/60V battery, the voltage value of the solar panel is 1.5 times the voltage value of the battery to be recharged.
6. Built-in overheating, overcurrent, short circuit, open circuit protection, reverse connection protection, when the fault is eliminated, the controller will automatically recover without damaging the equipment. It is strictly forbidden to short-circuit the boost output power port!
7. Two-way MOS tube anti-backflow circuit, high-power charging mode, ultra-low heat generation.
8. Both charging and discharging are combined with multiple MOS, high-power charging and discharging, and the Phoenix wing aluminum alloy has good heat dissipation performance
9.No battery is needed to supply power to the load, it is a real sunshine application.
Notice:
Regarding wind and solar input power, strictly follow the recommendations below.
1.The maximum wind input is 200W.
2.Maximum input power of solar panel:
30A=300W
40A=400W
60A=600W
100A=700W
SYSTEM CONNECTION:
1. Connect the positive electrode of the battery to the controller as shown in the figure, and the controller will automatically detect the battery voltage.
2. Connect the positive and negative poles of the load to the controller as shown in the figure, and be careful not to reverse them.
3. Connect the solar panel to the controller as shown in the figure.
4. Connect the wind generator to the controller as shown in the figure.
5. Rise Charging function, Or for power output,short circuit is strictly prohibited at any time!
Charging connection mode:
Wind input 15V-50V, solar panel 18~90V input, charge the battery ①12V, 24V, 36V, 48V, 60V, the output load corresponds to the battery voltage value. Connect the battery first, then the solar panel or wind motor, and finally the load. Connect the battery, first set the voltage value corresponding to the , set the relevant charging parameters, with memory function.
Dual battery charging connection mode：
Wind input 15V-50V, solar panel 18V input, charge ① battery 12V, ② battery 24V, 36V, 48V, 60V battery; solar panel 36 volt input ① battery 24V ② battery 36V, 48V, 60V battery charge. The output load corresponds to the battery voltage value. Connect the battery first, then the solar panel or wind motor, and finally the load. Connect the battery, first set the corresponding voltage value of the ①battery, ②battery, set the relevant charging parameters, with memory function.
Boost charging connection mode:
Wind input 15V-50V, solar panel 18V input, ①not connected to the battery, connected to the negative pole ②Battery 24V, 36V, 48V, 60V battery charging; solar panel 18V--36V input ①not connected to the battery, connected to the negative pole ②Battery 24V ( PV18V), 36V, 48V, 60V (PV36V) battery charging. The output load corresponds to the battery voltage value. Connect the battery first, then the solar panel or wind motor, and finally the load. Connect the battery, first set the voltage value corresponding to the charging ② battery, set the relevant charging parameters, with memory function.
No battery working mode:
Wind input 15V-50V, solar panel 18V input, ①Do not connect the battery., connect to the negative pole ②Load 24V, 36V, 48V, 60V drive work. The boost output voltage value is consistent with the load voltage value, and the load is finally connected. Connect the wind or hydraulic motor or solar panel with 18 volt solar panel, first set the voltage value corresponding to
About shippingShipping and Packaging All itwill be double checked and well packed before sending.Itwill be dispatched within 2 business days after buyers pay for the order. It usually takes about 14 to 18 working days for delivering the package to the destination(for remote areas,it may take a little longer).
Special Announcement:Please fill in the correct and detailed consignee, address and phone number in the order. For fast and correct delivery.If you do not receive order within 30 working days,please feel free to contact Customer Service before leaving Negative and Neutral Feedback, we will do our best to help you resolve the problem.TaxNo, you will only pay what is quoted as total cost at checkout, no more. You are not expected to pay any additional duties ores. If you are asked by Customs or our logistic partner to pay duties, please contact our Customer Service .
Your 100% satisfaction is very ant to usIf the product is not on good condition, You can return this product within 14 working days, please contact customer service center before returning.FeedbackYour satisfaction is our first priorityIf you receive the order and it is in good condition,we would be grateful if you would leave us 5 star Positive Feedback for the transaction.
Key Features
Brand Name:Y&H
Origin:CN(Origin)
Certification:CE
Model Number:BL4600-30A/40A/60A/100A
Is Smart Device:Yes
Application:Charger Controller
Application:Voltage Controller
Application:Lighting Controller
Application:Solar System Controller
Application:Solar Working Station
Maximum Current:30A/40A/60A/100A
is_customized:Yes
Charge method:mppt
Max pv input voltage:30A/40A/60A/100A
USB Output:5V/2A Max
Max Solar Input:60V battery is charged with 90V solar panel, voltage is less than 100V
Siez/Weight:268*138*66mm/650g
What's In the Box
1X 30A 40A 60A 100A Wind Solar Hybrid Charge Controller Dual USB Charge Wind Solar hybrid system controller MPPT charge regulator-12V 24V 36V 48V 60V--
