Buy Circuit Breakers Products online in Nigeria

Schneider 2-pole 10a-250a Dc Circuit Breaker

Original Schneider 2-Pole 10A-250A DC Circuit Breaker delivered physically through rehmie.com.ng. A circuit breaker MCB is an automatically operated electrical switch intended to prevent damage to an electrical circuit due to excess current. they are designed to trip during an overload or short circuit to protect against electrical faults and equipment failure.The circuit breaker here provides overload protection, short circuit protection, and isolation. It is widely used in building power distribution, industrial power distribution, as well as control and security for a variety of equipment PROPERTIES:Rated current: 10A. 20A. 32A. 63A. 80A. 100A. 125A. 140A. 160A. 180A. 200A. 225A. 250A.Type: MCBCurrent Range 1-250ANumber of Pole: 1Warranty: 1-YearHigh-speed trippingFor any amperages lower than your order. Example: Name: Olivia WoodsOrder No: F74908477LAAmps: 125A

Modulated Case 10a-250a Dc Circuit Breaker - 1 Phase

Original Modulated Case Schneider 10A-250A DC Circuit Breaker 1Phase: Delivered through rehmie.com.ng. A circuit breaker MCB is an automatically operated electrical switch intended to prevent damage to an electrical circuit due to excess current. they are designed to trip during an overload or short circuit to protect against electrical faults and equipment failure.The circuit breaker here provides overload protection, short circuit protection, and isolation. It is widely used in building power distribution, industrial power distribution, as well as control and security for a variety of equipment PROPERTIES:Rated current: 10A. 20A. 32A. 63A. 80A. 100A. 125A. 140A. 160A. 180A. 200A. 225A. 250A.Type: MCBCurrent Range 1-250ANumber of Pole: 1Warranty: 1-YearHigh-speed trippingReliable Customer support: +2347035010090, +2348140695076 or visit //elitabtechnology.com For any amperages lower than your order, please send us a message confirming your order number and the desired amperage.Example: Name: Olivia WoodsOrder No: F74908477LAAmps: 125A

1-pole + N Mcb 160a Dc Circuit Breaker

1-pole+ N Mcb 160A Dc Circuit Breaker delivered physically through rehmie.com.ng. A circuit breaker MCB is an automatically operated electrical switch intended to prevent damage to an electrical circuit due to excess current. they are designed to trip during an overload or short circuit to protect against electrical faults and equipment failure.The circuit breaker here provides overload protection, short circuit protection, and isolation. It is widely used in building power distribution, industrial power distribution, as well as control and security for a variety of equipment PROPERTIES:Rated current: 10A. 20A. 32A. 63A. 80A. 100A. 125A. 140A. 160A.Type: MCBCurrent Range 1-160ANumber of Pole: 1Warranty: 1-YearHigh-speed trippingFor any amperages lower than your order, Example: Name: Olivia WoodsOrder No: F74908477LAAmps: 160A

1- Pole + n Mcb 63a Dc Circuit Breaker

1-Pole 63A DC circuit breaker: Delivered physically through rehmie.com.ng. A circuit breaker MCB is an automatically operated electrical switch intended to prevent damage to an electrical circuit due to excess current. they are designed to trip during an overload or short circuit to protect against electrical faults and equipment failure.The circuit breaker here provides overload protection, short circuit protection, and isolation. It is widely used in building power distribution, industrial power distribution, as well as control and security for a variety of equipment PROPERTIES:Rated current: 10A. 20A. 32A. 63A.Type: MCBCurrent Range 1-63ANumber of Pole: 1Warranty: 1-YearHigh-speed trippingFor any amperages lower than your order, Example: Name: Olivia WoodsOrder No: F74908477LAAmps: 25A

2-pole + N Mcb 125a Dc Circuit Breaker Chint

2-pole + N Mcb 125A Dc Circuit Breaker delivered physically through rehmie.com.ng. A circuit breaker MCB is an automatically operated electrical switch intended to prevent damage to an electrical circuit due to excess current. they are designed to trip during an overload or short circuit to protect against electrical faults and equipment failure.The circuit breaker here provides overload protection, short circuit protection, and isolation. It is widely used in building power distribution, industrial power distribution, as well as control and security for a variety of equipment PROPERTIES:Rated current: 10A. 20A. 32A. 63A. 80A. 100A.Type: MCBCurrent Range 1-125ANumber of Pole: 1Warranty: 1-YearHigh-speed trippingFor any amperages lower than your order, Example: Name: Olivia WoodsOrder No: F74908477LAAmps: 25A

Feeo Surge Protector Device 3p Dc

FSP-D40 Surge protective device, protect against lightning surge voltages in solar system (photovoltaic power supply system). These units must be installed in parallel on the DC networks to be protected and provide common and different modes protection. Its installed location are recommended at both ends of the DC power supply line (solar panel side and inverter/converter side), especially if the line routing is external and long.High energy Mo Vs equipped with specific thermal dis connectors and related failure indicators.Surge Protector Device Features:1. Indicator window is obvious (green is OK, red indicates failure)2. Fully enclosed terminal3. The shell is made of PC flame retardant material, fire insulation4. Replaceable module Item Surge Arrester Code FSP-D40 Pole 3P Voltage 1000VDC In(8/20)us(KA) 20KA Imax(8/20)us(KA) 40KA Standard IEC/EN50539-11 Type II Characteristic Curve B,C,D Working Temperature -5 to +40 Protection Degree IP20 Electrical life More than 8000times Mechanical life More than 2000times Dimension(W)X(H)X(D) 35x90x49

Feeo - Surge Protector Devicee - 40kva - 4p

Fsp-a series ac surge protection device (spd) is suitable for tn-s, tn-c-s, tt, it etc, power supply system of ac 50/60hz, & lt;380v, installed on the joint of lpz1 or lpz2 and lpz3. it's designed according to iec61643-1, gb18802.1, it adopts 35mm standard rail, there is a failure release mounted on the module of surge protection device, when the spd fails in breakdown for over heat and over-current, the failure release will help electric equipment separate from the power supply system and give the indication signal, green means normal, red means abnormal. FSP-A 4P AC SPD series surge protection device (in short SPD,alias:surge suppressor surge arrester)is suitable for TN-S, TN-C-S, TT, IT etc, power supply system of AC 50/60Hz, & lt;380V, installed on the joint of LPZ1 or LPZ2 and LPZ3. It's designed according to IEC61643-1, GB18802.1, it adopts 35mm standard rail, there is a failure release mounted on the module of surge protection device, When the SPD fails in breakdown for over heat and over-current, the failure rlease will help electric equipments separate from the power supply system and give the indication signal, green means normal, red means abnormal, it also could be replaced for the module when has operating voltage

Knife Change Over Switch - 200a

Knife Change Over Switch: 100% CopperAdoption of open with pull clasp type terminal, easy to use and very strong.The handle use the nylon material, using the screw connect.The contact with pure materials, point of contact is planar contact, electrical conductivity is always efficient.Floor adopts electrical fiber reinforced polyester DMC, drop resistance, pressure resistance, high temperature resistance performance.The rivet is made of stainless steel materials.Model: 2P200ARated Voltage: 380/220VRated Current: 200AFrequency: 50HZ

4p 160a Mccb Dc Circuit Breakers

DC MCCB Parameters:FEEO FPVM series of DC Moulded Case Circuit Breaker(DC MCCB) is designed for solar system with bigger current and higher breaking capacity. Rated current of 4Poles contains 125A,250A,400A,630A,800A. Rated voltage of 4Poles is 1000VDC,even can be customized to 1200VDC Model FPVM-125 FPVM-250 FPVM-400 FPVM-630 FPVM-800 FPVM-1250 Rated Current ln (A) 16, 20, 25, 32, 40, 50, 63, 80, 100, 125 100, 125, 140, 160, 180, 200, 225, 250 250, 315, 350, 400 400, 500, 630 630, 700, 800 800, 1000, 1250 Rated Operating Voltage Ue (V) DC 500V, 550V, 750V, 1000V Rated Insulation Voltage Ui (V) 1000V 1000V 1500V 1500V 1500V 1500V Uimp (kV) 8kV Breaking Capacity (kA) Icu (1cs=75% Icu) 250V 35 50 50 50 65 65 500V 25 35 35 35 50 50 750V 15 25 25 25 35 35 1000V 10 15 15 15 20 20 Mechanical Life Times 7000 7000 4000 4000 2500 2000 Breaking Times (ms) 20

Himel Miniature Circuit Breaker - 18mm Ac - C - 2p - 6ka - 63A|| HDB3WHN2C63

Product Description: The Himel HDB3wH series Miniature Circuit Breaker (MCB) is an advanced and reliable electrical safety device designed to provide effective isolation control. This compact 18mm AC MCB is engineered for both commercial and residential applications, ensuring protection against electrical hazards such as short circuits and overload faults. With its thermal-magnetic trip unit technology, this device guarantees robust performance and high durability. Product Features: Main Characteristics: Range of Product: HDB3wH Product or Component Type: Miniature Circuit Breaker (MCB) Device Application: Isolation Control Trip Unit Technology: Thermal-magnetic Suitability for Isolation: Yes Mechanical Durability: 20,000 cycles Electrical Durability: 7,000 cycles Complementary Characteristics: Poles Description: 2P (Two Poles) Rated Current [In]: 63 A Rated Operational Voltage [Ue]: 415 V AC, 50/60 Hz Curve Code: C Magnetic Tripping Limit: 5 to 10 times the rated current Breaking Capacity: 6.0 kA Rated Insulation Voltage [Ui]: 250.0 V between phase and ground 500.0 V between phases Rated Impulse Withstand Voltage [Uimp]: 4.0 kV Cable Entry: Top and Bottom Mounting Support: 35 mm DIN rail Protection Type: Overload protection, Short-circuit protection Overvoltage Category: II Connections & ndash; Terminals: Forked type tag connectors Clamping Connection Capacity: Up to 25 mm & sup2; Tightening Torque: 2.5 N.m Dimensions: Height: 80 mm Width: 35.4 mm Depth: 78.5 mm Embedding Depth: 69.0 mm Environmental Characteristics: Dielectric Test Voltage: 2.0 kV, 50/60 Hz for 1 minute Shock Resistance: 30 gn (duration of 11.0 ms) for 3 shocks Standards Compliance: EN/IEC 60898-1 IP Degree of Protection: IP20 Pollution Degree: 2 This Himel Miniature Circuit Breaker is built with high-quality materials and precision engineering to ensure reliable performance and long-term durability. It is ideal for use in diverse settings, providing essential protection and control for electrical systems.

Himel Miniature Circuit Breaker Hdb9 - 18mm Ac 10ka - 1p C Curve - 40 A|| HDB9H63A1C40

Product Description: The Himel HDB9 Miniature Circuit Breaker (MCB) is a compact and reliable solution designed to protect electrical circuits from overloads and short circuits. With a power rating of 40A and a breaking capacity of 10kA, this single-pole (1P) MCB features a C Curve tripping characteristic, making it ideal for residential, commercial, and industrial applications. Its slim 18mm width ensures easy installation in any electrical distribution board, providing effective circuit protection without occupying excessive space. Product Features: Product Type & ndash; The HDB9 is a single-pole (1P) miniature circuit breaker with an 18mm width from the Himel range, designed for robust circuit protection. Power Characteristics & ndash; This MCB supports a 40A current rating and offers a high breaking capacity of 10kA, ensuring reliable protection against overloads and short circuits. Tripping Curve & ndash; Features a C Curve tripping characteristic, making it suitable for general-purpose use where moderate inrush currents are expected. Application & ndash; Ideal for a wide range of applications, including residential homes, commercial buildings, and industrial facilities, ensuring safety and protection of electrical systems. Compact Design & ndash; The 18mm slim profile allows for efficient use of space in electrical distribution boards, making it easy to install and integrate into existing systems. Durable & Safe & ndash; Manufactured to international standards, the HDB9 MCB ensures long-lasting performance, safety, and reliability in various environments. Characteristics: Main Range of product HDB9 Product or component type Miniature circuit-breaker Device application Isolation Control Poles description 1P Limitation class 3 conforming to EN 60898-1 Screw type M5 Complementary: [In] rated current 40 A [Ue] rated operational voltage 230 V AC Curve code C Magnetic tripping limit 5...10 x In Breaking capacity 10.0 kA [Ui] rated insulation voltage 500 V Mechanical durability 20000 cycles Electrical durability 10000 cycles Protection type Overload protection Short-circuit protection Mounting support 35 mm DIN rail 9 mm pitches 2.0 Clamping connection capacity = 25 mm & sup2; Tightening torque 2 & hellip;2.5 N.m Height 86 mm Width 18.0 mm Depth 73.5 mm Environment: Standards EN/IEC 60898-1 Product certifications KEMA CB CE Pollution degree 2 Ambient air temperature for operation -30 & hellip;70 & deg;C

Himel Miniature circuit breaker, HDB3w-125, 27mm, AC, 10kA, 2P, C curve, 125 A|| HDB3W125H2C125

Product Description: The Himel HDB3W-125 is a 27mm AC Miniature Circuit Breaker (MCB) with a 2-pole design, offering a breaking capacity of 10kA and a C curve tripping characteristic. Built for both commercial and residential use, this high-performance circuit breaker provides reliable protection against overloads and short circuits, ensuring safety and durability. With a rated current of 125A and operational voltage of 230V AC, it is designed for superior isolation and enhanced electrical safety. Product Features: Main Characteristics: Range of Product: HDB3W-125 Product or Component Type: Miniature Circuit Breaker Device Application: Isolation Trip Unit Technology: Thermal-magnetic Suitability for Isolation: Yes Mechanical Durability: 8,500 cycles Electrical Durability: 1,500 cycles Complementary Characteristics: Poles Description: 2P Rated Current ([In]): 125A Rated Operational Voltage ([Ue]): 230V AC 50/60 Hz Curve Code: C Magnetic Tripping Limit: 8.5 x In Breaking Capacity: 10kA Rated Insulation Voltage ([Ui]): 250V between phase and ground Rated Impulse Withstand Voltage ([Uimp]): 4kV Cable Entry: Top and Bottom Mounting Support: 35mm DIN rail Protection Type: Overload and Short-circuit protection Connections - Terminals: Forked type tag connectors Clamping Connection Capacity: 50mm & sup2; Tightening Torque: 3.5 N.m Dimensions: Height - 86.4mm, Width - 27.0mm, Depth - 74.5mm, Embedding Depth - 44.0mm Environmental Characteristics: Dielectric Test Voltage: 2kV 50/60 Hz for 1 min Shock Resistance: 30g (duration = 11ms) for 3 shocks Standards: IEC 60947-2 IP Degree of Protection: IP20 Pollution Degree: 2 Ambient Air Temperature for Operation: -20 to 60 & deg;C Ambient Air Temperature for Storage: -40 to 70 & deg;C

Himel Miniature Circuit Breaker - 18mm Ac - C - 4p - 6ka - 20 A - HDB3WHN4C20

Product Description: The HDB3WHC406N20 is a 20A, 18mm AC Miniature Circuit Breaker (MCB) with a C curve, designed to provide protection and control for electrical systems. This MCB is part of the Himel HDB3wH series and is crafted for use in commercial and residential buildings. It offers robust protection against short circuits and overload faults, ensuring the safety of power systems and users. The circuit breaker can be connected via top or bottom line incoming types and supports a maximum wiring capacity of 25mm & sup2;. Product Features: Product Type: HDB3WHC406N20 is an AC Miniature Circuit Breaker (MCB) from the Himel HDB3wH series. Component Features: The 18mm AC circuit breaker provides a red and green indication display for tripping status. Application: Designed to protect power systems and people from electrical short circuits and overload faults. Mechanical Characteristics: Protection class is IP20, with a mechanical durability of 20,000 cycles and electrical durability of 7,000 cycles. It has 4 poles and mechanical shock resistance of 30g for 3 shocks, each lasting 11ms. Electrical Characteristics: Rated Current: 20A Rated Operational Voltage [Ue]: 415V AC 50/60 Hz Rated Insulation Voltage [Ui]: 250V between phase and ground, 500V between phases Rated Impulse Withstand Voltage [Uimp]: 4kV Tripping Curve: C (magnetic tripping limit 5...10 x In) Breaking Capacity: 6kA Dielectric Test Voltage: 2kV at 50/60 Hz for 1 min Complementary: Poles Description: 4P Cable Entry: Top and Bottom Mounting Support: 35mm DIN rail Protection Type: Overload protection, Short-circuit protection Overvoltage Category: II Connections & ndash; Terminals: Forked type tag connectors Clamping Connection Capacity: Up to 25mm & sup2; Tightening Torque: 2.5 N.m Dimensions: Height: 80mm Width: 70.8mm Depth: 78.5mm Embedding Depth: 69.0mm Environment: Shock Resistance: 30g (duration = 11.0 ms) for 3 shocks Standards: EN/IEC 60898-1 IP Degree of Protection: IP20 Pollution Degree: 2

Ac Mini Circuit Breaker Overload Protection Switch 1p 10a

Scope of application:Miniature Circuit Breaker is a safety switch. DZ47-63 series miniature circuit breakers are mainly used in circuits with AC 50Hz/60Hz, rated working voltage of 230V/400V and below, and rated current of 10A to 63A. The circuit breaker is mainly used for overloading electrical circuits and equipment in modern buildings. Short circuit protection is also suitable for infrequent isolation of lines.The overcurrent in an electrical circuit may result from a short circuit/overload or faulty design. In order to restart the flow of current the MCB is manually turned on. Package Contain 1 x Ac Mini Circuit Breaker Overload Protection Switch 1P 10A

La1 Dn 22 Auxiliary Contact Block La1dn22 2no+2nc Telemecanique

The load contactor usually is used as the main contactor. It handles loads of about 600 A / AC1. Auxiliary contactors, on the other hand, are designed for switching currents of only up to 6 A. Among the auxiliary contactors count e.g. timer relays and safety relays. Basically, an auxiliary contactor is a regular (low-power) relay - but built like a "regular" contactor and when used together with another contactor it is called auxiliary contactor to clarify that it is not used for switching loads but has an activation/deactivation or control function instead - used to connect/disconnect a circuit (in a nutshell: to control load contactors). Therefore, auxiliary contactors usually only have auxiliary contacts and no main contacts. Features: 1. 100%new and high quality. 2. This product is an industrial electric appliance that uses a coil to flow through the current to generate a magnetic field that closes the contact to achieve the control load of the electrical installation 3. The Auxillary contact is sensitive and has a greater carrying capacity. 4. Stable connection contact is of strong conductivity. 5. Usually used in power, distribution and power applications. Auxiliary Contactor Description Electricity Type: AC Model name: LA1-DN22 Number of Pole: 1-4 (2NC, 2NO) Phase : 1-3 Main Circuit Rating Voltage: 24 & ndash; 660V Main Circuit Rating Current: 6 - 620A PACKAGING:1X AUXILLARY CONTACT

100a 4p0le(3p&n) Residual Current Circuit Breaker(rccb)

A residual current circuit breaker (RCCB) detects earth leakage in a circuit. It monitors the difference between the current flowing through the phase and neutral wires. When there is an imbalance, it trips to protect against electrical hazards. What is earth leakage? Earth leakage occurs when an electrical current leaks from an electrical appliance or circuit to an unintended path. This leakage can be unintentional (e.g., loose wires) or intentional, such as electrical equipment with small amounts of earth leakage during regular operation. In either case, it's vital to protect against shock. Improper or a lack of protection can lead to electrical accidents, fire, or damage to the equipment. Residual current circuit breaker working principle When there is no fault in the circuit, the current flowing through the phase wire equals the current flowing through the neutral wire. Both wires coil around the core an equal amount, creating opposing magnetic fields. In this instance, no current flows through the sensing coil. When there is earth leakage, current flows from the phase wire to earth. This creates an imbalance between the phase and neutral. Therefore, the two currents' magnetic fields are not in balance. The flux between the two fields creates an electromotive force that acts on the sensing coil. This creates a current flow through the sensing coil and relay. The relay forces the breaker contacts to open, halting current flow through the circuit breaker.

4pole 3p&n 100a Minature Circuit Breaker

A circuit breaker is an automatically operated electrical switch designed to protect an electrical circuit from damage caused by excess current from an overload or short circuit. Its basic function is to interrupt current flow after a fault is detected. Unlike a fuse, which operates once and then must be replaced, a circuit breaker can be reset (either manually or automatically) to resume normal operation.ABB offers Air Circuit Breakers, the best solution for restoring the service condition rapidly in case of fault, providing at the same time optimum protection of the electrical installation.

Himel Miniature Circuit Breaker - 18 Mm Ac - C - 1p - 6 Ka - 6 A||HDB3WHN1C6

Product Description: The Himel HDB3wH18C1P6K6A is a 1-pole, 18mm AC miniature circuit breaker (MCB) from the Himel HDB3wH range, designed for isolation and control applications. This MCB features thermal-magnetic trip unit technology and offers reliable protection against overloads and short circuits, making it suitable for both residential and commercial installations. With high mechanical and electrical durability, this MCB ensures long-term performance and safety. Product Features: Product Type: The HDB3wH18C1P6K6A is a 1-pole, 18mm AC Miniature Circuit Breaker (MCB) from the Himel HDB3wH range. Component Features: This MCB features a C-curve trip characteristic and provides reliable isolation and control for electrical circuits. Application: Designed to protect power systems and ensure safety by preventing electrical overloads and short circuits. Mechanical Characteristics: Boasts a mechanical durability of 20,000 cycles and an electrical durability of 7,000 cycles, ensuring long-lasting performance. Electrical Characteristics: Rated current of 6 A, with a rated operational voltage of 240 V AC 50/60 Hz, and a breaking capacity of 6.0 kA. Environmental Durability: Built to withstand harsh conditions with a dielectric test voltage of 2.0 kV and a shock resistance of 30 gn.\ Environmental Characteristics Dielectric Test Voltage: 2.0 kV 50/60 Hz for 1 min Shock Resistance: 30 gn (duration = 11.0 ms) for 3 shocks Standards: EN/IEC 60898-1 IP Degree of Protection: IP20 Pollution Degree: 2 Main Characteristics Range of Product: HDB3wH Product or Component Type: Miniature circuit-breaker Device Application: Isolation Control Trip Unit Technology: Thermal-magnetic Suitability for Isolation: Yes Mechanical Durability: 20,000 cycles Electrical Durability: 7,000 cycles Complementary Characteristics Poles Description: 1P Rated Current ([In]): 6 A Rated Operational Voltage ([Ue]): 240 V AC 50/60 Hz Curve Code: C Magnetic Tripping Limit: 5...10 x In Breaking Capacity: 6.0 kA Rated Insulation Voltage ([Ui]): 250 V between phase and ground Rated Impulse Withstand Voltage ([Uimp]): 4.0 kV Cable Entry: Top and Bottom Mounting Support: 35 mm DIN rail Protection Type: Overload and Short-circuit protection Overvoltage Category: II Connections & ndash; Terminals: Forked type tag connectors Clamping Connection Capacity: Up to 25 mm & sup2; Tightening Torque: 2.5 N.m Dimensions: Height: 80 mm Width: 17.7 mm Depth: 78.5 mm Embedding Depth: 69.0 mm

Himel Miniature Circuit Breaker - 18 Mm Ac - C - 1p - 6 Ka - 16a|| Hdb3whn1c16

Product Description: The Himel HDB3WH Miniature Circuit Breaker (MCB) - 18mm AC - C - 1P - 6kA - 16A is an advanced and reliable solution for safeguarding electrical systems in both residential and commercial settings. This single-pole MCB, with its thermal-magnetic trip unit technology, ensures isolation control and offers protection against overloads and short circuits. With a robust build and high-quality materials, it is designed for longevity and efficiency. Product Features: Product Type: Himel HDB3WH Miniature Circuit Breaker (MCB) - 18mm AC Component Features: The device features a thermal-magnetic trip unit technology, providing reliable tripping characteristics with a C curve. It offers a mechanical durability of up to 20,000 cycles and an electrical durability of up to 7,000 cycles. Application: Ideal for isolation control, the MCB protects power systems from electrical short circuits and overload faults. Mechanical Characteristics: Single-pole (1P) configuration Mechanical durability: 20,000 cycles Electrical durability: 7,000 cycles Height: 80mm, Width: 17.7mm, Depth: 78.5mm, Embedding depth: 69.0mm Electrical Characteristics: Rated current: 16A Rated operational voltage: 240V AC, 50/60 Hz Magnetic tripping limit: 5 to 10 times the rated current (In) Breaking capacity: 6.0 kA Rated insulation voltage: 250V between phase and ground Rated impulse withstand voltage: 4.0 kV Protection Type: Provides overload protection, short-circuit protection, and overvoltage category II Connections and Installation: Cable entry at both top and bottom Mounts on a 35mm DIN rail Clamping connection capacity up to 25mm & sup2; Uses forked type tag connectors with a tightening torque of 2.5 N.m Environmental Specifications: Dielectric test voltage: 2.0 kV at 50/60 Hz for 1 minute Shock resistance: 30 gn for 11 ms (3 shocks) Conforms to standards: EN/IEC 60898-1 IP degree of protection: IP20 Pollution degree: 2

Himel Miniature Circuit Breaker - 18 Mm Ac - C - 1p - 6 Ka - 25a|| HDB3WHN1C25

Product Description: The Himel HDB3wH Miniature Circuit Breaker (MCB) is a robust and reliable device designed to provide superior electrical protection. With its 18mm width and single-pole (1P) configuration, this MCB is perfect for both commercial and residential applications. It features a C curve tripping characteristic and boasts a high breaking capacity of 6 kA, ensuring safety and performance during electrical faults such as overloads and short circuits. Engineered for easy installation on a 35 mm DIN rail, the Himel HDB3wH MCB is built to last with exceptional mechanical and electrical durability. Product Features: Main Characteristics Range of Product: HDB3wH Product or Component Type: Miniature Circuit Breaker Device Application: Isolation Control Trip Unit Technology: Thermal-magnetic Suitability for Isolation: Yes Mechanical Durability: 20,000 cycles Electrical Durability: 7,000 cycles Complementary Characteristics Poles Description: 1P (Single Pole) [In] Rated Current: 25 A [Ue] Rated Operational Voltage: 240 V AC, 50/60 Hz Curve Code: C Magnetic Tripping Limit: 5 to 10 times the rated current (In) Breaking Capacity: 6.0 kA [Ui] Rated Insulation Voltage: 250 V between phase and ground [Uimp] Rated Impulse Withstand Voltage: 4.0 kV Cable Entry: Top and Bottom Mounting Support: 35 mm DIN rail Protection Type: Overload and Short-circuit Protection Overvoltage Category: II Connections & ndash; Terminals: Forked type tag connectors Clamping Connection Capacity: Up to 25 mm & sup2; Tightening Torque: 2.5 N.m Dimensions (HxWxD): 80 mm x 17.7 mm x 78.5 mm Embedding Depth: 69.0 mm Environmental Characteristics Dielectric Test Voltage: 2.0 kV, 50/60 Hz, for 1 minute Shock Resistance: 30 gn (duration = 11.0 ms) for 3 shocks Standards Compliance: EN/IEC 60898-1 IP Degree of Protection: IP20 Pollution Degree: 2

Himel Miniature Circuit Breaker - 18 Mm Ac - C - 1p - 6 Ka - 63a|| HDB3WHN1C63

Product Description: The HDB3wH63A is a 18mm AC Miniature Circuit Breaker (MCB) designed for reliable isolation and control of electrical circuits. Part of the advanced Himel HDB3wH range, this circuit breaker ensures protection against electrical hazards such as short circuits and overload faults. With a robust construction and high mechanical durability of up to 20,000 cycles, it is suitable for both commercial and residential applications. The device features thermal-magnetic trip unit technology and provides superior electrical durability with 7,000 cycles. Product Features: Main Characteristics: Range of Product: HDB3wH Product Type: Miniature Circuit Breaker (MCB) Application: Isolation Control Trip Unit Technology: Thermal-magnetic Suitability for Isolation: Yes Mechanical Durability: 20,000 cycles Electrical Durability: 7,000 cycles Complementary Characteristics: Poles Description: 1P Rated Current [In]: 63A Rated Operational Voltage [Ue]: 240V AC 50/60 Hz Curve Code: C Magnetic Tripping Limit: 5 to 10 x In Breaking Capacity: 6 kA Rated Insulation Voltage [Ui]: 250V (between phase and ground) Rated Impulse Withstand Voltage [Uimp]: 4 kV Cable Entry: Top/Bottom Mounting Support: 35 mm DIN rail Protection Type: Overload and Short-circuit protection Overvoltage Category: II Connections - Terminals: Forked type tag connectors Clamping Connection Capacity: Up to 25 mm & sup2; Tightening Torque: 2.5 N.m Dimensions: Height: 80 mm Width: 17.7 mm Depth: 78.5 mm Embedding Depth: 69 mm Environmental Characteristics: Dielectric Test Voltage: 2 kV (50/60 Hz for 1 min) Shock Resistance: 30 gn (duration 11 ms for 3 shocks) Standards Compliance: EN/IEC 60898-1 IP Degree of Protection: IP20 Pollution Degree: 2

Himel Miniature Circuit Breaker, Hdb3w-125, 27mm, Ac, 10ka, 3p, C Curve, 63 A|| HDB3W125H3C63

Product Description: The HDB3w-125 is a 27mm AC MCB with a breaking capacity of 10kA and a C curve tripping characteristic. From the renowned Himel range, this circuit breaker is designed to ensure isolation and protect electrical systems from overload and short circuits. Built for durability, it features a robust construction suitable for both commercial and residential applications, and it can be used with top or bottom cable entry. Product Features: Product Type: HDB3w-125 is an AC Miniature Circuit Breaker (MCB) from the Himel range. Component Features: Equipped with thermal-magnetic trip unit technology and a C curve tripping characteristic. Application: Designed for isolation and protection against overloads and short circuits in electrical systems. Mechanical Characteristics: The device has a mechanical durability of 8500 cycles and an electrical durability of 1500 cycles. It also offers a shock resistance of 30g for 3 shocks, each lasting 11ms. Electrical Characteristics: Rated current: 63A Rated operational voltage: 230V AC at 50/60 Hz Rated insulation voltage: 250V between phase and ground Rated impulse withstand voltage: 4kV Magnetic tripping limit: 8.5 times the rated current Connections: Cable entry: Top and bottom Clamping connection capacity: Up to 50mm & sup2; Tightening torque: 3.5 N.m Dimensions: Height: 86.4 mm Width: 81.0 mm Depth: 74.5 mm Embedding depth: 44.0 mm Mounting Support: Suitable for 35 mm DIN rail. Environmental Characteristics Dielectric Test Voltage: 2.0 kV at 50/60 Hz for 1 minute Standards: Compliant with IEC 60947-2 Protection Class: IP20 Pollution Degree: 2 Operating Temperature Range: -20 to 60 & deg;C Storage Temperature Range: -40 to 70 & deg;C

Himel Miniature Circuit Breaker, Hdb3w-125, 27mm, Ac, 10ka, 3p, C Curve, 80 A|| HDB3W125H3C80

Product Description: The HDB3W-125 is a 27mm AC Miniature Circuit Breaker (MCB) from Himel's distinguished Series 3 range. Designed to offer reliable protection against electrical hazards such as overload and short circuit faults, this MCB is a critical component for ensuring the safety of electrical installations in both commercial and residential buildings. With a rated current of 80A and a breaking capacity of 10kA, it delivers superior performance and durability. Product Features: Product Type: HDB3W-125 is an AC Miniature Circuit Breaker (MCB) from the Himel Series 3 range. Component Features: The 27mm AC circuit breaker is equipped with thermal-magnetic trip unit technology and C curve tripping characteristics, ensuring precise and reliable operation. Red and green indication displays provide clear visibility of the tripping status. Application: Specifically designed for isolation purposes, this MCB protects power systems and individuals from electrical faults like short circuits and overloads. Mechanical Characteristics: Offers mechanical durability of up to 8500 cycles and electrical durability of up to 1500 cycles. Protection class IP20, with a mechanical shock resistance of 30g (3 shocks, lasting 11ms). Electrical Characteristics: Rated current: 80A Rated operational voltage: 230V AC, 50/60Hz Curve code: C Magnetic tripping limit: 8.5 x In Breaking capacity: 10kA Rated insulation voltage (Ui): 250V (between phase and ground) Rated impulse withstand voltage (Uimp): 4kV Installation and Mounting: Cable entry: Top and bottom Mounting support: 35mm DIN rail Connections: Forked type tag connectors Clamping connection capacity: up to 50mm & sup2; Tightening torque: 3.5 N.m Dimensions: Height - 86.4mm, Width - 81.0mm, Depth - 74.5mm, Embedding depth - 44.0mm Environmental Specifications: Dielectric test voltage: 2.0kV, 50/60Hz for 1 minute Shock resistance: 30g (duration 11ms) for 3 shocks Standards compliance: IEC 60947-2 IP degree of protection: IP20 Pollution degree: 2 Ambient air temperature for operation: -20 to 60 & deg;C Ambient air temperature for storage: -40 to 70 & deg;C

Himel Miniature Circuit Breaker, Hdb3w-125, 27mm, Ac, 10ka, 4p, C Curve, 125 A|| HDB3W125H4C125

Product Description: The Himel HDB3W-125 is a high-performance 27mm AC Miniature Circuit Breaker (MCB) designed for effective isolation and protection in various electrical systems. With a robust 4-pole configuration and C Curve characteristics, this circuit breaker is engineered to safeguard against overloads and short circuits. Built to meet rigorous standards, the HDB3W-125 offers reliable operation and durability in both commercial and residential environments. Product Features: Product Type: HDB3W-125 is an AC Miniature Circuit Breaker (MCB) from the Himel Series 3 range, designed for isolation and protection. Component Features: This 27mm MCB offers a C Curve trip characteristic, with a breaking capacity of 10kA to handle high fault currents. Application: Ideal for protecting electrical systems from overloads and short circuits, ensuring safety and reliability in various settings. Mechanical Characteristics: Features a 4-pole configuration, protection class IP20, and shock resistance rated at 30g for 11ms, making it durable for demanding environments. Electrical Characteristics: Rated for 125A current with an operational voltage of 230V AC (50/60 Hz). It has a magnetic tripping limit of 8.5 x In and meets the IEC 60947-2 standards for safety. Durability: Mechanical durability of up to 8500 cycles and electrical durability of 1500 cycles, designed for long-term performance. Connections: Equipped with forked type tag connectors, supports a clamping connection capacity of up to 50mm & sup2;, and requires a tightening torque of 3.5 N.m. Dimensions: Height of 86.4 mm, Width of 108.0 mm, Depth of 74.5 mm, and an embedding depth of 44.0 mm. Temperature Range: Operates effectively in temperatures ranging from -20 & deg;C to 60 & deg;C, with storage temperatures from -40 & deg;C to 70 & deg;C. Standards and Compliance: Standards: Complies with IEC 60947-2 for circuit breakers. IP Degree of Protection: IP20, suitable for indoor use. Pollution Degree: Rated at 2, indicating moderate levels of pollution in the environment.

200A High Quality Knife Switch- 3phase

Specifications 1.Single/Double row 2.CE certificated 3.Voltage.415V 200a blade knife switch Brand Name YF Model Number YF 3P 32A Place of Origin Fuzhou Fujian, China (Mainland) Max. Voltage 415V COLOR YELLOW Voltage 110~415v Max. Current 3 32A pole 2P,3P

FEEO 2p 16a Mcb Miniature Dc Circuit Breaker

DC circuit breaker Application: FPV-63 Solar system DC MCB , apply to rating current 63A or less, It is mainly used for the overloading and short circuit protection in DC distribution system equipment and electric equipment. It can be widely used in electric, post, traffic, mining enterprise and different kinds of fields. dc circuit breaker Features: 1. Thermoplastic shell, full inlet, impact resistant, recyclable, self extinguishing2. Super safety: classic U tunnel terminal, to ensure that the line connection is solid and reliable3. The original air flow, can effectively reduce the temperature between adjacent circuit breaker4. Safety handle, classic original design, ergonomic

Rccb - 4p - 40A - 30ma - Type Ac

range Acti 9 product name Acti9 iID product or component type Residual current circuit breaker (RCCB) device short name IID poles description 4P neutral position Left [In] rated current 40 A network type AC earth-leakage sensitivity 30 mA earth-leakage protection time delay Instantaneous earth-leakage protection class Type AC device location in system Outgoer network frequency 50/60 Hz [Ue] rated operational voltage 380...415 V AC 50/60 Hz residual current tripping technology Voltage independent rated breaking and making capacity Idm 1500 A Im 1500 A rated conditional short-circuit current 10 kA [Ui] rated insulation voltage 500 V AC 50/60 Hz [Uimp] rated impulse withstand voltage 6 kV surge current 250 A contact position indicator Yes control type Toggle mounting mode Clip-on mounting support DIN rail 9 mm pitches 8 height 91 mm width 72 mm depth 73.5 mm net weight 0.37 kg colour White mechanical durability 20000 cycles electrical durability AC-1: 15000 cycles locking options description Padlocking device connections - terminals Single terminal top or bottom 1 & hellip;35 mm & sup2; rigid Single terminal top or bottom 1 & hellip;25 mm & sup2; flexible Single terminal top or bottom 1 & hellip;25 mm & sup2; flexible with ferrule wire stripping length 14 mm for top or bottom connection tightening torque 3.5 N.m top or bottom Complementary standards EN/IEC 61008-1 IP degree of protection IP20 conforming to IEC 60529 IP40 (modular enclosure) conforming to IEC 60529 pollution degree 3 electromagnetic compatibility 8/20 & micro;s impulse withstand, 250 A conforming to EN/IEC 61008-1 ambient air temperature for operation -5 & hellip;60 & deg;C ambient air temperature for storage -40 & hellip;85 & deg;C Environment Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Weight 360 g Package 1 Height 7.6 cm Package 1 width 8.5 cm Package 1 Length 10 cm Unit Type of Package 2 S03 Number of Units in Package 2 27 Package 2 Weight 10.228 kg Package 2 Height 30 cm Package 2 width 30 cm Package 2 Length 40 cm Packing Units Sustainable offer status Green Premium product REACh Regulation EU RoHS Directive Compliant Mercury free Yes RoHS exemption information China RoHS Regulation Product out of China RoHS scope. Substance declaration for your information Environmental Disclosure WEEE The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins Halogen content performance Halogen free plastic parts product Offer Sustainability Warranty 18 months Contractual warranty

Mcb Breaker - Feeo 4p 63a

FPV-63 4P DC MCB apply to rating current 63A or less, It is mainly used for the overloading and short circuit protection in DC distribution system equipment and electric equipment. It can be widely used in electric, post, traffic, mining enterprise and different kinds of fields. Frame degree rated current 63a pole 4p rated operating voltage 1000 A circuit breaker refers to a switching device that can close, carry and break current under normal circuit conditions and can close, carry and break current under abnormal circuit conditions within a specified time. Circuit breakers are divided into high-voltage circuit breakers and low-voltage circuit breakers according to their scope of use. Circuit breakers can be used to distribute electric energy, start asynchronous motors infrequently, and protect power lines and motors. When they have serious overload or short-circuit and under-voltage faults, they can automatically cut off the circuit. Its function is equivalent to a fuse switch. Combination with overheating and underheating relay, etc. Moreover, it is generally not necessary to change the components after breaking the fault current. It has been widely used. Power distribution is an extremely important link in the generation, transmission and use of electricity. The power distribution system includes transformers and various high and low voltage electrical equipment, and the low voltage circuit breaker is a widely used electrical appliance. The main contacts of the low-voltage circuit breaker are closed manually or electrically. After the main contact is closed, the free trip mechanism locks the main contact in the closed position. The coil of the overcurrent release and the thermal element of the thermal release are connected in series with the main circuit, and the coil of the undervoltage release is connected in parallel with the power supply. When the circuit is short-circuited or severely overloaded, the armature of the overcurrent release is pulled in to make the free release mechanism act, and the main contact disconnects the main circuit. When the circuit is overloaded, the thermal element of the thermal release will heat up and bend the bimetal, pushing the free release mechanism to act. When the circuit is undervoltage, the armature of the undervoltage release is released. Also actuate the free trip mechanism. The shunt release is used for remote control. During normal operation, its coil is powered off. When distance control is required, press the start button to energize the coil.

4p 250a Mccb Dc Circuit Breaker

DC MCCB Parameters: FEEO FPVM series of DC Moulded Case Circuit Breaker(DC MCCB) is designed for solar system with bigger current and higher breaking capacity. Rated current of 4Poles contains 125A,250A,400A,630A,800A. Rated voltage of 4Poles is 1000VDC,even can be customized to 1200VDC Model FPVM-125 FPVM-250 FPVM-400 FPVM-630 FPVM-800 FPVM-1250 Rated Current ln (A) 16, 20, 25, 32, 40, 50, 63, 80, 100, 125 100, 125, 140, 160, 180, 200, 225, 250 250, 315, 350, 400 400, 500, 630 630, 700, 800 800, 1000, 1250 Rated Operating Voltage Ue (V) DC 500V, 550V, 750V, 1000V Rated Insulation Voltage Ui (V) 1000V 1000V 1500V 1500V 1500V 1500V Uimp (kV) 8kV Breaking Capacity (kA) Icu (1cs=75% Icu) 250V 35 50 50 50 65 65 500V 25 35 35 35 50 50 750V 15 25 25 25 35 35 1000V 10 15 15 15 20 20 Mechanical Life Times 7000 7000 4000 4000 2500 2000 Breaking Times (ms) 20

Smart Wifi Power Supply Protector With Backlight

We bring you the WiFi Remote Control Over-Voltage and Under-Voltage Current Limiting Protector. It combines cutting-edge technology with reliable manufacturing to deliver advanced electrical safety for your home or business. This intelligent device protects your electrical systems from voltage abnormalities, thermal excesses, and leakages while offering convenient, remote monitoring options. Key Features:Over-Voltage and Under-Voltage Protection: Automatically safeguards against voltage fluctuations. Adjustable settings:Overvoltage Protection Range: 240~300V (Default: 275V)Undervoltage Protection Range: 145~210V (Default: 175V)Over-Current Protection: Adjustable from 1A to 63A (Default: 63A).Over-Temperature Protection: Adjustable from 10~85 & deg;C (default works with WiFi-enabled models, fixed at 85 & deg;C for non-WiFi models).Leakage Protection: Configurable from 10-99mA (Default: 50mA).Power Display Range: Real-time measurement of energy consumption from 0-99999.9 kWh.Memory Function: Retains kilowatt-hours, overvoltage, and overcurrent data even after power outages.Reconnection Time Delay: Adjustable from 10 to 99 seconds (default: 30S).WiFi Remote Control and Monitoring: Accessibility via mobile app for remote management. Technical Specifications:Rated Voltage: 110V/220VFrequency: 50Hz/60HzRated Current: 63ADimensions: 85 * 35 * 66mmPacking Box Dimensions: 94 * 75 * 40mmWeight: 178g (including packaging)Certifications: CE CertifiedReconnection Operation Count: & gt;= 99999 cycles for protections except for leakage (auto-reconnect disabled after tripling due to leakage for safety). Applications:Perfect for residential homes, commercial installations, and industrial setups. Why Choose Smart WiFi Power Supply Protector with Backlight?1. Highest protection reliability with intelligent reconnection control.2. Memory function to ensure your settings are saved.3. Adaptable for high-risk voltage and current conditions.4. Certified CE quality assurance for peace of mind.5. Convenient remote management (WiFi-enabled models).6. Leakage protection switch Today, take control of your electrical safety with the advanced **SVP-688W-L WiFi Protector**. Place your order now on Alibaba and enjoy fast delivery, competitive pricing, and excellent service. Safeguard your appliances, reduce risks, and save energy all in one intelligent device. Packaging Information:1 x Smart WiFi Power Supply Protector with Backlight1 x manual

Circuit Breaker Mccb - Feeo 250a Dc

FEEO FPVM Moulded Case Circuit Breaker Switch 2P 550V 160/200/250A DC MCCBDC MCCB Application: FPVM series Moulded Case Circuit Breaker is designed to distribute power and protect the circuit and power equipment against overload in solar system. It is apply to rating current 1250A or less,direct current rating voltage 1500V or less.Products according IEC60947-2, GB14048.2 standard. A circuit breaker refers to a switching device that can close, carry and break current under normal circuit conditions and can close, carry and break current under abnormal circuit conditions within a specified time. Circuit breakers are divided into high-voltage circuit breakers and low-voltage circuit breakers according to their scope of use. Circuit breakers can be used to distribute electric energy, start asynchronous motors infrequently, and protect power lines and motors. When they have serious overload or short-circuit and under-voltage faults, they can automatically cut off the circuit. Its function is equivalent to a fuse switch. Combination with overheating and underheating relay, etc. Moreover, it is generally not necessary to change the components after breaking the fault current. It has been widely used. Power distribution is an extremely important link in the generation, transmission and use of electricity. The power distribution system includes transformers and various high and low voltage electrical equipment, and the low voltage circuit breaker is a widely used electrical appliance. The main contacts of the low-voltage circuit breaker are closed manually or electrically. After the main contact is closed, the free trip mechanism locks the main contact in the closed position. The coil of the overcurrent release and the thermal element of the thermal release are connected in series with the main circuit, and the coil of the undervoltage release is connected in parallel with the power supply. When the circuit is short-circuited or severely overloaded, the armature of the overcurrent release is pulled in to make the free release mechanism act, and the main contact disconnects the main circuit. When the circuit is overloaded, the thermal element of the thermal release will heat up and bend the bimetal, pushing the free release mechanism to act. When the circuit is undervoltage, the armature of the undervoltage release is released. Also actuate the free trip mechanism. The shunt release is used for remote control. During normal operation, its coil is powered off. When distance control is required, press the start button to energize the coil.

FEEO - Circuit Breaker - 2p 100a Mcb

FPV-125 2P DC MCB high breaking capacity circuit breaker is specially for solar PV system. The current is form 63A to 125A and voltage up to 1000VDC. Standard according to IEC/EN60947-2. SOlar 100a dc mcb fpv-125 high breaking capacity circuit breaker is specially for solar pv system. the current is 100afor 2p and voltage up to 500vdc. standard according to iec/en60947-2. brand feeo rated current 100a rated voltage 500vdc electrical life 6000 times mechanical life 20000 times(c.o.) no. of pole 2p weight(g) 360 ideal for solar or a battery system dc mcb. FPV-125 Series Circuit Breaker FPV-125 Rated Current 63,80,100,125A Rated Voltage 250VDC/550VDC/750VDC/1000VDC Electrical Life 6000 Times Mechanical Life 20000 times(C.O.) No. of Pole 1P, 2P, 3P, 4P Weight(G) 1P 2P 3P 4P 180 360 540 720

Feeo 1p 63a Mcb Miniature Dc Circuit Breaker

FPV-63 1P DC MCB supplementary protectors are designed to provide over current protection within appliances or electrical equipment, where a branch circuit protection is already protection or not required. Devices are designed for direct current (DC) control circuit applications. Features: 1.Thermostatic shell, full inlet, impact resistant, recyclable, self extinguishing2. Super safety: classic U tunnel terminal, to ensure that the line connection is solid and reliable3. The original air flow, can effectively reduce the temperature between adjacent circuit breaker4. Safety handle, classic original design, ergonomic FPV-63 Series Circuit Breaker FPV-63 Frame Degree Rated Current(A) 25 Pole 1P Rated Operating Voltage(VDC) DC12V-DC1200V Rated Current In (A) 1-16A Rated Insulation Voltage Ui (VDC) 1200VDC Rated Impact Voltage Uimp (KV) 4 Ultimate Breaking Capacity Icu (KA) 6 Run Breaking Capacity Ics (%Icu) 75% Curve Type C Trip Type Thermal-magnetic Mechanical Actual average value 20000 Standard 8500 Electric Actual average value 2500 Standard 1500 Safety handle, classic original design, ergonomic Super safety: classic U tunnel terminal, to ensure that the line connection is solid and reliable

30 Amp Havells Changeover Switch

Havells Changeover Switch Havell changeover is manufactured using the best grade heavy copper and brass parts with the help of advance technology. It is used for switch over from PHCN to generator, This electrical changeover switch provided are widely used in household, offices factories and commercial establishment. The changeover is fitted with metal clad box and are painted with superior quality power coating for anti rust and anti shock operations.Onload/Offload Changeover switch Features Rated Voltage: 415V Frequency: 50Hz Amp: 32A Also available in 63A and 100A

63amps 3pole Circuit Breaker

Schneider 3pole 63amps breaker Rated current 63amps Trip unit technology thermal-magnetic Control type toggle Mounting support din rail Pole description 3pole It's a low voltage miniature circuit breaker that provides safe and reliable electrical distribution as well as protects the electrical circuit against short circuit and overload Voltage 230-240v

Switch Disconnector 3p - 100 A - 400V

Main range Easy9 product or component type Switch device short name Easy9 switch switch application Distribution Poles 3P utilisation category AC-22A suitability for isolation Yes Complementary [Ie] rated operational current 100 A at 400 V 50/60 Hz [Ue] rated operational voltage 400 V AC 50/60 Hz [Icm] rated short-circuit making capacity 1.5 kA [Icw] rated short-time withstand current 1.2 kA during 1 s [Ui] rated insulation voltage 500 V AC 50/60 Hz [Uimp] rated impulse withstand voltage 4 kV control type Toggle local signalling ON/OFF indication contact position indicator Yes mounting mode Clip-on mounting support DIN rail 9 mm pitches 6 height 81 mm width 54 mm depth 66.5 mm colour Grey mechanical durability 8500 cycles electrical durability 1500 cycles connections - terminals Tunnel type terminal (top or bottom) 1 & hellip;50 mm & sup2; rigid Tunnel type terminal (top or bottom) 1 & hellip;35 mm & sup2; flexible tightening torque 3.5 N.m Environment standards IEC 60947-3 product certifications CE IP degree of protection IP20 conforming to IEC 60529 tropicalisation 2 ambient air temperature for operation -5 & hellip;55 & deg;C ambient air temperature for storage -5 & hellip;70 & deg;C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Weight 254 g Package 1 Height 7.8 cm Package 1 width 5.4 cm Package 1 Length 8.5 cm Unit Type of Package 2 BB1 Number of Units in Package 2 4 Package 2 Weight 1.077 kg Package 2 Height 9 cm Package 2 width 9 cm Package 2 Length 23 cm Unit Type of Package 3 S03 Number of Units in Package 3 48 Package 3 Weight 13.411 kg Package 3 Height 30 cm Package 3 width 30 cm Package 3 Length 40 cm

100amps 4pole Circuit Breaker

Schneider 4pole 100amps breaker Rated current amps 100a Trip unit technology thermal magnetic Control type toggle Mounting support din rail Curve code D

Feeo 1p 25a Mcb Miniature Dc Circuit Breaker

FPV-63 1P DC MCB supplementary protectors are designed to provide over current protection within appliances or electrical equipment, where a branch circuit protection is already protection or not required. Devices are designed for direct current (DC) control circuit applications. dc circuit breaker Features: 1. Thermoplastic shell, full inlet, impact resistant, recyclable, self extinguishing 2. Super safety: classic U tunnel terminal, to ensure that the line connection is solid and reliable 3. The original air flow, can effectively reduce the temperature between adjacent circuit breaker 4. Safety handle, classic original design, ergonomic FPV-63 Series Circuit Breaker FPV-63 Frame Degree Rated Current(A) 25 Pole 1P Rated Operating Voltage(VDC) DC12V-DC1200V Rated Current In (A) 1-16A Rated Insulation Voltage Ui (VDC) 1200VDC Rated Impact Voltage Uimp (KV) 4 Ultimate Breaking Capacity Icu (KA) 6 Run Breaking Capacity Ics (%Icu) 75% Curve Type C Trip Type Thermal-magnetic Mechanical Actual average value 20000 Standard 8500 Electric Actual average value 2500 Standard 1500

FEEO 16a 1p Mcb Dc Breaker

FPV-63 1P DC MCB supplementary protectors are designed to provide overcurrent protection within appliances or electrical equipment, where a branch circuit protection is already protection or not required. Devices are designed for direct current (DC) control circuit applications. FPV-63 Series Circuit Breaker FPV-63 Frame Degree Rated Current(A) 16 Pole 1P Rated Operating Voltage(VDC) DC12V-DC250V Rated Current In (A) 16A Rated Insulation Voltage Ui (VDC) 1200VDC Rated Impact Voltage Uimp (KV) 4 Ultimate Breaking Capacity Icu (KA) 6 Run Breaking Capacity Ics (%Icu) 75% Curve Type C Trip Type Thermal-magnetic Mechanical Actual average value 20000 Standard 8500 Electric Actual average value 2500 Standard 1500

32a Contactor + 32a Abb Mcb + Ammeter Led + Nc/no Button + Led Indicator

Schneider Electric is a European multinational company providing energy and automation digital solutions for efficiency and sustainability. Features: 1. 100%new and high quality. 2. This product is an industrial electric appliance that uses a coil to flow through the current to generate a magnetic field that closes the contact to achieve the control load of the electrical installation 3. The contactor is sensitive and has a greater carrying capacity. 4. Stable connection contact is of strong conductivity. 5. Usually used in power, distribution and power applications. Specification: Current: 32A Coil Voltage: AC 220V Ui: 690V Uimp: 6kV V/KW : (200-220)/2.2-3.7 max HP: 6HP Torque: 20ib Max. short circuit rms ratings: 5kv, 600v. with high response circuit breaker Operating Frequency: 1200 times/hour Wiring Mode: Plate Front Wiring Installation Method: Fixed Type, Rail Type Weight: Approx. 551g / 19.4oz Miniature circuit breakers protect installations against overload and short-circuit, warranting reliability and safety for operations. System pro M compact S 200 series are current limiting overcurrent protective devices. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the magnetic tripping mechanism for short circuit protection. Buttons Features: Product Name: Push Button Switch; Action Type: Latching Model : XB2BA42 X1 and XB2BA32 X1 Contact Type: ON (NO) + OFF (NC) Poles: SPST Max voltage : 660V Current : 10A Quantity: 1 OFF buttons + 1 ON buttons Terminal : 2 Pins Color: As Picture Shown; Package Content: 1 x ON Push Buttons Switch and 1 OFF Push Buttons Switch * Features: 2 terminals, 22mm mounting hole, 1NO with 1NC contact type, * Used widely to control the electromagnetic starter, contactor, relay and other automatic control electric circuits. Package List: 1 * AC 32a Contactor, 32a Abb Mcb, Ammeter Led, Nc/no Button, Led Indicator light

FEEO Fpvm 2p Mccb 125a Dc Breaker

FPVM 2P DC MCCB is designed to distribute power and protect the circuit and power equipment against overload in solar system. It is apply to rating current 1250A or less,direct current rating voltage 1500V or less.Products according IEC60947-2, GB14048.2 standard. A circuit breaker refers to a switching device that can close, carry and break current under normal circuit conditions and can close, carry and break current under abnormal circuit conditions within a specified time. Circuit breakers are divided into high-voltage circuit breakers and low-voltage circuit breakers according to their scope of use. Circuit breakers can be used to distribute electric energy, start asynchronous motors infrequently, and protect power lines and motors. When they have serious overload or short-circuit and under-voltage faults, they can automatically cut off the circuit. Its function is equivalent to a fuse switch. Combination with overheating and underheating relay, etc. Moreover, it is generally not necessary to change the components after breaking the fault current. It has been widely used. Power distribution is an extremely important link in the generation, transmission and use of electricity. The power distribution system includes transformers and various high and low voltage electrical equipment, and the low voltage circuit breaker is a widely used electrical appliance. The main contacts of the low-voltage circuit breaker are closed manually or electrically. After the main contact is closed, the free trip mechanism locks the main contact in the closed position. The coil of the overcurrent release and the thermal element of the thermal release are connected in series with the main circuit, and the coil of the undervoltage release is connected in parallel with the power supply. When the circuit is short-circuited or severely overloaded, the armature of the overcurrent release is pulled in to make the free release mechanism act, and the main contact disconnects the main circuit. When the circuit is overloaded, the thermal element of the thermal release will heat up and bend the bimetal, pushing the free release mechanism to act. When the circuit is undervoltage, the armature of the undervoltage release is released. Also actuate the free trip mechanism. The shunt release is used for remote control. During normal operation, its coil is powered off. When distance control is required, press the start button to energize the coil.

FEEO - Circuits Breaker - 2p 80a Mcb

80A dc mcb fpv-125 high breaking capacity circuit breaker is specially for solar pv system. the current is 100afor 2p and voltage up to 500vdc. standard according to iec/en60947-2. brand feeo rated current 100a rated voltage 500vdc electrical life 6000 times mechanical life 20000 times(c.o.) no. of pole 2p weight(g) 360 ideal for solar or a battery system dc mcb. FPV-125 2P DC MCB high breaking capacity circuit breaker is specially for solar PV system. The current is form 63A to 125A and voltage up to 1000VDC. Standard according to IEC/EN60947-2. FPV-125 Series Circuit Breaker FPV-125 Rated Current 63,80,100,125A Rated Voltage 250VDC/550VDC/750VDC/1000VDC Electrical Life 6000 Times Mechanical Life 20000 times(C.O.) No. of Pole 1P, 2P, 3P, 4P Weight(G) 1P 2P 3P 4P 180 360 540 720

2p 20a Ac Circuit Breaker

FE7-63 2P AC MCB supplementary protectors are designed to provide over current protection within appliances or electrical equipment, where a branch circuit protection is already protection or not required. Devices are designed for alternative current (AC) control circuit applications. Features: 1.Thermostatic shell, full inlet, impact resistant, recyclable, self extinguishing2. Super safety: classic U tunnel terminal, to ensure that the line connection is solid and reliable3. The original air flow, can effectively reduce the temperature between adjacent circuit breaker4. Safety handle, classic original design, ergonomic FPV-63 Series Circuit Breaker FPV-63 Frame Degree Rated Current(A) 25 Pole 2P Rated Operating Voltage(VDC) DC12V-DC1200V Rated Current In (A) 1-20A Rated Insulation Voltage Ui (VDC) 1200VDC Rated Impact Voltage Uimp (KV) 4 Ultimate Breaking Capacity Icu (KA) 6 Run Breaking Capacity Ics (%Icu) 75% Curve Type C Trip Type Thermal-magnetic Mechanical Actual average value 20000 Standard 8500 Electric Actual average value 2500 Standard 1500 Safety handle, classic original design, ergonomic Super safety: classic U tunnel terminal, to ensure that the line connection is solid and reliable

Mcb 63 Amps 2 Pole Circuit Breaker

Miniature circuit breakers (MCBs) ensure electrical safety in homes, offices and other buildings as well as for industrial applications by protecting electrical installations against overloads and short circuits. Once a fault is detected, the miniature circuit breaker automatically switches off the electrical circuit to prevent damage to wires and to avoid the risk of fire. Warranting reliability and safety for people and assets, MCBs are equipped with two tripping mechanisms: the delayed thermal tripping mechanism for overload protection and the magnetic tripping mechanism for short circuit protection. ABB System pro M compact S200M miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electro mechanic tripping mechanism for short circuit protection. All MCBs of the product range S200M comply with IEC/EN 60898-1 and IEC/EN 609 47-2, allowing the use for residential, commercial and industrial applications. Bottom-fitting auxiliary contact can be mounted on S200M to save 50% space Features and Benefits & bull;Extra-wide and complete range of MCBs to cover most applications and markets & bull;Space and time saving thanks to the unique bottom-fixing auxiliary contact & bull;Meeting worldwide standards & bull;For domestic or small commercial installations up to 6 kA breaking capacity & bull;IEC/EN 60898-1, IEC/EN 60947-2 & bull;A wide range of accessories is available! Specification Number of Poles: 2 pole Current Rating: 63A Rated AC Voltage: 400V Breaking Capacity at Maximum Voltage Rating: 6KA Circuit Breaker Type: MCB Mounting Style: Din Rail Mount

3p Abb Minature Circuit Breaker

A circuit breaker is an automatically operated electrical switch designed to protect an electrical circuit from damage caused by excess current from an overload or short circuit. Its basic function is to interrupt current flow after a fault is detected. Unlike a fuse, which operates once and then must be replaced, a circuit breaker can be reset (either manually or automatically) to resume normal operation.ABB offers Air Circuit Breakers, the best solution for restoring the service condition rapidly in case of fault, providing at the same time optimum protection of the electrical installation.

Himel Miniature Circuit Breaker - 18mm Ac - C - 3p - 6ka - 6A|| HDB3WHN3C6

Product Description: The Himel HDB3wH6C3P6KA6 is an 18mm AC Miniature Circuit Breaker (MCB) designed to provide isolation and control in electrical systems. It features thermal-magnetic tripping technology and is suitable for both overload and short-circuit protection. With a rated current of 6A and a breaking capacity of 6kA, this MCB is ideal for use in commercial and residential buildings. The device ensures reliable performance with a mechanical durability of 20,000 cycles and an electrical durability of 7,000 cycles. It can be mounted on a 35mm DIN rail and supports top and bottom cable entry with a maximum clamping connection capacity of 25mm & sup2;. Product Features: Main Characteristics: Range of Product: HDB3wH Product Type: Miniature Circuit Breaker Application: Isolation and control in electrical systems Trip Unit Technology: Thermal-magnetic Isolation Suitability: Yes Mechanical Durability: 20,000 cycles Electrical Durability: 7,000 cycles Electrical Characteristics: Poles Description: 3P Rated Current [In]: 6 A Rated Operational Voltage [Ue]: 415 V AC 50/60 Hz Curve Code: C Magnetic Tripping Limit: 5...10 x In Breaking Capacity: 6.0 kA Rated Insulation Voltage [Ui]: 250 V (phase to ground), 500 V (between phases) Rated Impulse Withstand Voltage [Uimp]: 4.0 kV Mechanical Characteristics: Cable Entry: Top and Bottom Mounting Support: 35 mm DIN rail Protection Type: Overload and short-circuit protection Overvoltage Category: II Connections & ndash; Terminals: Forked type tag connectors Clamping Connection Capacity: Up to 25 mm & sup2; Tightening Torque: 2.5 N.m Dimensions: Height: 80 mm Width: 53.09 mm Depth: 78.5 mm Embedding Depth: 69.0 mm Environmental Characteristics: Dielectric Test Voltage: 2.0 kV (50/60 Hz, 1 min) Shock Resistance: 30 gn (11 ms duration) for 3 shocks Standards: EN/IEC 60898-1 IP Degree of Protection: IP20 Pollution Degree: 2

Himel Miniature Circuit Breaker - 18mm Ac - C - 2p - 6ka - 40A|| HDB3WHN2C40

Product Description The Himel Miniature Circuit Breaker - 18mm AC - C - 2P - 6kA - 40A is a robust and reliable protection device designed to safeguard electrical systems from short circuits and overload faults. This circuit breaker, part of the HDB3wH range, offers enhanced protection and control, making it ideal for both commercial and residential applications. Its compact design allows for efficient installation and maintenance, ensuring the safety and reliability of your power systems. Product Features: Range of Product: HDB3wH Product or Component Type: Miniature Circuit Breaker (MCB) Device Application: Isolation and Control Trip Unit Technology: Thermal-magnetic Suitability for Isolation: Yes Mechanical Durability: 20,000 cycles Electrical Durability: 7,000 cycles Complementary Characteristics: Poles Description: 2P Rated Current [In]: 40 A Rated Operational Voltage [Ue]: 415 V AC 50/60 Hz Curve Code: C Magnetic Tripping Limit: 5...10 x In Breaking Capacity: 6.0 kA Rated Insulation Voltage [Ui]: 250.0 V between phase and ground 500.0 V between phases Rated Impulse Withstand Voltage [Uimp]: 4.0 kV Cable Entry: Top and Bottom Mounting Support: 35 mm DIN rail Protection Type: Overload protection Short-circuit protection Overvoltage Category: II Connections & ndash; Terminals: Forked type tag connectors Clamping Connection Capacity: 25 mm & sup2; Tightening Torque: 2.5 N.m Dimensions: Height: 80 mm Width: 35.4 mm Depth: 78.5 mm Embedding Depth: 69.0 mm Environmental Characteristics: Dielectric Test Voltage: 2.0 kV 50/60 Hz 1 min Shock Resistance: 30 gn (duration = 11.0 ms) for 3 shocks Standards: EN/IEC 60898-1 IP Degree of Protection: IP20 Pollution Degree: 2

Himel Miniature Circuit Breaker - 18mm Ac - C - 2p - 6ka - 32A|| HDB3WHN2C32

Product Description: The HDB3WHN2C32 is an 18mm AC Miniature Circuit Breaker (MCB) from the reliable Himel Series 3 range. This MCB is designed for isolation control and protection against electrical hazards such as short circuits and overload faults. Featuring a robust thermal-magnetic trip unit, it ensures safe and efficient operation in both commercial and residential applications. With a mechanical durability of up to 20,000 cycles and an electrical durability of 7,000 cycles, the HDB3WHN2C32 is built to last. It operates on a 415V AC supply, supporting a rated current of 32A, and offers a breaking capacity of 6.0 kA. The device's compact design allows for easy installation on a 35 mm DIN rail, making it an ideal choice for modern electrical systems. Product Features: Product Type: HDB3WHN2C32 is an 18mm AC Miniature Circuit Breaker (MCB) from the Himel Series 3 range. Component Features: Designed with a red and green indicator display to show the tripping status. Application: Provides protection for power systems and individuals against electrical short circuits and overload faults. Mechanical Characteristics: Protection class: IP20 Number of poles: 2P Mechanical durability: 20,000 cycles Mechanical shock resistance: 30g for 3 shocks lasting 11ms. Electrical Characteristics: Rated current: 32A Rated operational voltage: 415V AC 50/60 Hz Curve code: C Magnetic tripping limit: 5 to 10 times the rated current Breaking capacity: 6.0 kA Rated insulation voltage: 250V between phase and ground, 500V between phases Rated impulse withstand voltage: 4.0 kV Cable entry: Top and Bottom Clamping connection capacity: Up to 25 mm & sup2; Tightening torque: 2.5 N.m Dimensions: Height: 80 mm Width: 35.4 mm Depth: 78.5 mm Embedding depth: 69.0 mm Environment: Dielectric test voltage: 2.0 kV at 50/60 Hz for 1 minute Standards: Complies with EN/IEC 60898-1 Shock resistance: 30g (duration = 11ms) for 3 shocks Pollution degree: 2 Overvoltage category: II

Himel Miniature Circuit Breaker - 18mm Ac - C - 2p - 6ka - 20A||HDB3WHN2C20

Product Description: The Himel HDB3WHC2020 is a 18mm AC Miniature Circuit Breaker (MCB) featuring C curve tripping characteristics. This 2-pole circuit breaker from the reliable Himel Series 3 range is designed to provide isolation and control for electrical systems. It effectively safeguards against electrical hazards such as short circuits and overload faults, making it suitable for both commercial and residential applications. With a robust build and high-quality materials, it supports top or bottom cable entry and accommodates a maximum wiring capacity of 25mm & sup2;. Product Features: Product Type: The HDB3WHC2020 is an AC Miniature Circuit Breaker (MCB) from the Himel Series 3 range. Component Features: The 18mm AC circuit breaker provides reliable protection with a 2-pole design and a rated current of 20A. Application: Designed to protect power systems and people from electrical short circuits and overload faults. Mechanical Characteristics: Protection class: IP20 Number of poles: 2 Mechanical shock resistance: 30g, 3 shocks, lasting 11ms Mechanical durability: 20,000 cycles Electrical durability: 7,000 cycles Electrical Characteristics: Rated current: 20A Rated operational voltage: 415V AC, 50/60 Hz Curve code: C Magnetic tripping limit: 5 to 10 times the rated current Breaking capacity: 6kA Rated insulation voltage: 250V (between phase and ground), 500V (between phases) Rated impulse withstand voltage: 4kV Dielectric test voltage: 2kV, 50/60 Hz for 1 minute Connections and Installation: Cable entry: Top and bottom Mounting support: 35mm DIN rail Connection terminals: Forked type tag connectors Clamping connection capacity: Up to 25mm & sup2; Tightening torque: 2.5 N.m Physical Dimensions: Height: 80mm Width: 35.4mm Depth: 78.5mm Embedding depth: 69mm Environment: Shock resistance: 30g (duration: 11ms) for 3 shocks Standards compliance: EN/IEC 60898-1 Degree of protection: IP20 Pollution degree: 2

DC Circuit Breaker - 12v To 125v - 1p - 200a

The RKB1/DC type B Circuit Breaker is designed for use in DC circuits with rated voltages ranging from DC 12V to 125V and a rated current of 200A. Its main purpose is to provide protection against both overloads and short circuits in these DC circuits. In normal operating conditions, it can switch infrequently used electric equipment and lighting circuits. The "type B" designation indicates that this circuit breaker conforms to the trip curve characteristic of type B, which means it offers a medium magnetic trip point suitable for protecting circuits with moderate inrush currents, such as those found in electric motor vehicles, battery cars, solar battery storage systems, and other similar applications. This specific circuit breaker model complies with the standards of GB10963.1 and IEC60898-1, which are international standards for circuit breakers in low-voltage installations. These standards ensure that the circuit breaker meets the required safety and performance criteria for its intended use. Package Contains1 x 200A RKB1/DC Dc Circuit Breaker

1p Minature Circuit Breaker

A circuit breaker is an automatically operated electrical switch designed to protect an electrical circuit from damage caused by excess current from an overload or short circuit. Its basic function is to interrupt current flow after a fault is detected. Unlike a fuse, which operates once and then must be replaced, a circuit breaker can be reset (either manually or automatically) to resume normal operation.ABB offers Air Circuit Breakers, the best solution for restoring the service condition rapidly in case of fault, providing at the same time optimum protection of the electrical installation.

Himel Miniature Circuit Breaker Hdb9 - 18mm Ac 10ka - 1p C Curve - 20 A|| HDB9H63A1C20

Product Description: The Himel Hdb9 - 18mm AC 10ka - 1P C Curve - 20 A Miniature Circuit Breaker (MCB) is a high-performance electrical protection device designed to safeguard electrical circuits from overloads and short circuits. This single-pole MCB offers a current rating of 20A and features a C curve tripping characteristic, making it suitable for residential, commercial, and industrial applications. With a breaking capacity of 10kA, the Hdb9 ensures reliable operation and safety in various electrical systems. Its compact 18mm width allows for easy installation and integration into electrical panels. Product Features: Product Type & ndash; The Hdb9 is a 1-pole Miniature Circuit Breaker (MCB) from Himel, designed for effective circuit protection. Current Rating & ndash; This MCB has a current rating of 20A, providing reliable protection for your electrical systems. Tripping Curve & ndash; Features a C curve tripping characteristic, suitable for protecting circuits with moderate inrush currents such as those found in residential and commercial environments. Breaking Capacity & ndash; With a breaking capacity of 10kA, the Hdb9 ensures dependable protection against short circuits. Application & ndash; Ideal for use in residential, commercial, and industrial settings, this MCB is perfect for protecting lighting circuits, power outlets, and other electrical installations. Compact Design & ndash; The 18mm width allows for efficient use of space in electrical panels, making installation straightforward and hassle-free. Durability & Safety & ndash; Manufactured to international standards, the Hdb9 MCB ensures high durability and safety, offering long-term protection for your electrical circuits. Applications: The Himel Hdb9 MCB is designed for various applications, including residential homes, office buildings, commercial spaces, and industrial facilities. It is suitable for protecting electrical circuits powering lighting, power outlets, HVAC systems, and other electrical appliances. Advantages: Provides reliable protection against overloads and short circuits. Compact size allows for easy installation and integration. Suitable for a wide range of applications. Manufactured to high safety and durability standards. Characteristics: Main Range of product HDB9 Product or component type Miniature circuit-breaker Device application Isolation Control Poles description 1P Limitation class 3 conforming to EN 60898-1 Screw type M5 Complementary: [In] rated current 20 A [Ue] rated operational voltage 230 V AC Curve code C Magnetic tripping limit 5...10 x In Breaking capacity 10.0 kA [Ui] rated insulation voltage 500 V Mechanical durability 20000 cycles Electrical durability 10000 cycles Protection type Overload protection Short-circuit protection Mounting support 35 mm DIN rail 9 mm pitches 2.0 Clamping connection capacity = 25 mm & sup2; Tightening torque 2 & hellip;2.5 N.m Height 86 mm Width 18.0 mm Depth 73.5 mm Environment: Standards EN/IEC 60898-1 Product certifications KEMA CB CE Pollution degree 2 Ambient air temperature for operation -30 & hellip;70 & deg;C

Himel Miniature Circuit Breaker Hdb9 - 18mm Ac 10ka - 1p C Curve - 63 A|| HDB9H63A1C63

Product Description The HDB9 - 18mm AC 10kA - 1P C Curve - 63A is a top-tier AC Miniature Circuit Breaker (MCB) from the renowned Himel Series 9 range. This circuit breaker is specifically designed to ensure the safety and reliability of electrical circuits by interrupting the circuit during hazardous conditions such as short circuits and overload faults. With a compact 18mm width, it is optimized for use in both commercial and residential settings. The HDB9 MCB boasts a C Curve tripping characteristic and a single pole configuration, making it an ideal choice for a wide range of applications. It supports top or bottom line incoming connections and can handle a maximum wiring capacity of 25mm & sup2;. Built with high-quality, durable materials, this MCB promises long-lasting performance and safety. Product Features: Product Type & ndash; The HDB9 - 18mm AC 10kA - 1P C Curve - 63A is a Miniature Circuit Breaker (MCB) from the Himel Series 9 range. Component Features & ndash; This 18mm AC circuit breaker includes a clear indication display for easy status monitoring of tripping and operation. Application & ndash; Designed to protect electrical systems and ensure safety against short circuits and overload faults. Mechanical Characteristics & ndash; Protection class is IP20, featuring a single pole (1P) configuration and capable of withstanding mechanical shocks of 30g, 3 shocks, lasting 11ms. Electrical Characteristics & ndash; Rated current of 63A, with a rated ambient temperature of 30 & deg;C; 70 & deg;C. It offers a breaking capacity of 10kA, ensuring robust protection for various applications. Characteristics: Main Range of product HDB9 Product or component type Miniature circuit-breaker Device application Isolation Control Poles description 1P Limitation class 3 conforming to EN 60898-1 Screw type M5 Complementary: [In] rated current 63 A [Ue] rated operational voltage 230 V AC Curve code C Magnetic tripping limit 5...10 x In Breaking capacity 10.0 kA [Ui] rated insulation voltage 500 V Mechanical durability 20000 cycles Electrical durability 10000 cycles Protection type Overload protection Short-circuit protection Mounting support 35 mm DIN rail 9 mm pitches 2.0 Clamping connection capacity = 25 mm & sup2; Tightening torque 2 & hellip;2.5 N.m Height 86 mm Width 18.0 mm Depth 73.5 mm Environment: Standards EN/IEC 60898-1 Product certifications KEMA CB CE Pollution degree 2 Ambient air temperature for operation -30 & hellip;70 & deg;C

Himel Miniature Circuit Breaker - 18mm Ac - C - 4p - 6ka - 63 A - HDB3WHN4C63

Product Description: The Himel HDB3WH Series 3 Miniature Circuit Breaker (MCB) is a robust and reliable device designed to provide effective protection against electrical hazards such as short circuits and overload faults. This 18mm AC MCB features C-type tripping characteristics and is engineered for both isolation and control applications. With its capability to withstand high mechanical and electrical durability, it is an ideal choice for both commercial and residential buildings. Product Features: Product Type: Himel HDB3WH Series 3 Miniature Circuit Breaker (MCB) with C-type tripping characteristics. Component Features: Equipped with a thermal-magnetic trip unit, providing both overload and short-circuit protection. Application: Suitable for isolation and control in power systems, ensuring protection for electrical systems and human safety. Mechanical Characteristics: Number of Poles: 4P Mechanical Durability: 20,000 cycles Shock Resistance: 30g for 3 shocks, each lasting 11ms Protection Class: IP20 Electrical Characteristics: Rated Current ([In]): 63A Rated Operational Voltage ([Ue]): 415V AC 50/60Hz Rated Insulation Voltage ([Ui]): 250V (phase to ground), 500V (between phases) Rated Impulse Withstand Voltage ([Uimp]): 4kV Magnetic Tripping Limit: 5-10 times the rated current Breaking Capacity: 6kA Environmental Characteristics: Dielectric Test Voltage: 2kV for 1 minute Pollution Degree: 2 Compliance: EN/IEC 60898-1 Complementary Characteristics: Cable Entry: Top and bottom Mounting Support: 35mm DIN rail Connection Type: Forked type tag connectors Clamping Connection Capacity: Up to 25mm & sup2; Tightening Torque: 2.5 N.m Dimensions: Height: 80mm Width: 70.8mm Depth: 78.5mm Embedding Depth: 69mm This MCB is built with high-quality materials, ensuring durability and reliability in various environments. Its design and features make it a versatile and essential component for maintaining the safety and efficiency of electrical systems.

Himel Miniature Circuit Breaker, Hdb3w-125, 27mm, Ac, 10ka, 3p, C Curve, 125 A|| HDB3W125H3C125

Product Description: The HDB3W-125 is a 27mm AC Miniature Circuit Breaker (MCB) with a 10kA breaking capacity and C curve tripping characteristics. Designed for high durability and robust protection, this circuit breaker is part of the reliable Himel HDB3w series. With a rated current of 125A, it is suitable for both commercial and residential applications, providing effective isolation and protection against overload and short-circuit faults. Product Features Product Type: HDB3W-125 is an AC Miniature Circuit Breaker (MCB) from the Himel HDB3w series. Component Features: The 27mm AC circuit breaker provides efficient isolation with thermal-magnetic trip unit technology. Application: Designed to protect power systems and individuals from electrical short circuits and overload faults. Mechanical Characteristics: Protection Class: IP20 Number of Poles: 3P Mechanical Durability: 8500 cycles Shock Resistance: 30g, 3 shocks, lasting 11ms Electrical Characteristics: Rated Current: 125A Rated Operational Voltage: 230V AC 50/60 Hz Curve Code: C Magnetic Tripping Limit: 8.5 x In Breaking Capacity: 10kA Rated Insulation Voltage: 250V between phase and ground Rated Impulse Withstand Voltage: 4kV Additional Features: Cable Entry: Top and Bottom Mounting Support: 35mm DIN rail Protection Type: Overload and short-circuit protection Connections - Terminals: Forked type tag connectors Clamping Connection Capacity: 50mm & sup2; Tightening Torque: 3.5 N.m Dimensions Height: 86.4mm Width: 81.0mm Depth: 74.5mm Embedding Depth: 44.0mm Environmental Characteristics Dielectric Test Voltage: 2.0kV 50/60 Hz 1 min Standards: IEC 60947-2 IP Degree of Protection: IP20 Pollution Degree: 2 Ambient Air Temperature for Operation: -20 & hellip;60 & deg;C Ambient Air Temperature for Storage: -40 & hellip;70 & deg;C

Miniature Circuit Breaker - 63a - 3 Pole

An mcb is an automatically operated electrical switch. miniature circuit breakers are intended to prevent damage to an electrical circuit as a result of excess current. they are designed to trip during an overload or short circuit to protect against electrical faults and equipment failure.Miniature circuit breaker in CHINT provide the overload protection, short circuit protection and isolation. It is widely used in building power distribution, industrial power distribution, as well as control and protection for a variety of equipment with operating current not exceeding 125A Brand : & lrm;chintCurrent rating: & lrm;63 ampsVoltage: & lrm;500 voltsCircuit breaker type:standardMounting type: & lrm;din rail mountNumber of poles: 3

Schneider Contactor - 32A With Overload Relay

A contactor is an electrical device that is widely used for switching circuits on and off. As such, electrical contactors form a subcategory of electromagnetic switches known as relays. A relay is an electrically operated switching device that uses an electromagnetic coil to open and close a set of contacts.D contactor, 3 poles (3NO), for motor control applications up to 18A/690V AC-3/3e (7.5kW@400V).It provides a 24V 50/60Hz AC coil, 1NO+1NC built-in auxiliary contacts (NC mirror certified), connection by spring terminals.For operating rates until 3600 cycles/hour and environments until 60 & deg;C, it procures high reliability and durability. Schneider Electric is a European multinational company providing energy and automation digital solutions for efficiency and sustainability. Features:1. 100%new and high quality. 2. This product is an industrial electric appliance that uses a coil to flow through the current to generate a magnetic field that closes the contact to achieve the control load of the electrical installation 3. The contactor is sensitive and has a greater carrying capacity. 4. Stable connection contact is of strong conductivity. 5. Usually used in power, distribution and power applications. Specification: Current: 32A Coil Voltage: AC 220V Ui: 690V Uimp: 6kV V/KW : (200-220)/2.2-3.7

1p 25a Ac Mcb - Circuit Breaker

Circuit Breaker 1P 25A AC MCB230/400V10000AIEC/EN60989-1FE7-63

AC Miniature Circuit Breaker MCB - 4P 100a

4p 100A AC Mini lsolator Switch is specially for solar system and it can be rated voltage 1200 VDC, rated current 100AElectrical CharacteristicsCode FDH-63Standard EC60947-3/GB14048.3IPole 4p 100A AC 400v

Side Handle Fp Offload Changeover Switch - 800a

Havells is a trusted brand when it comes to electrical materials for safety and good operations. Havells Changeover Switch is manufactured using the best grade heavy copper and brass parts with the help of advance technology. It is used for switch over from PHCN to generator.This changeover can be installed in your house,office, school etc.It is known for it's durability and easy of use. This provides safety against opening of the enclosure door in ON condition. Sheet steel enclosure duly phosphatised and powder paintedProtects from rusting thereby lending longer life. Ease of Cable TerminationProvision of conduit knockouts and detachable gland plates help in easy termination. Double Break Switch MechanismOffers positive isolation hence renders safety. Positive Indication of Contact StatusProvision of ON / OFF flag indicator which provides positive indication. Allows flexibility of Cable Choice since suitable for both Cu & Al Cable An essential part of the electrical circuitry system at homes, offices or anywhere else, switchgear like circuit breakers, distribution boards, energy savers etc. are used for superior power distribution and power monitoring and control. The team of engineers at Havells have designed a premium range of switchgear which is an ideal example flawless machinery at affordable prices.
