Value Vacuum Pump - Vp1100
Description
1.5 CFM free air displacement. 220-volt, single-stage design. 1/4" flare & 1/2" ACME intake ports. "No-Hassle" over-the-counter replacement warranty. Length: 11.25 inches Width: 5.0 inches Height: 9.0 inches
Data
Model
VP1100
Flow Rate
50Hz
10 CFM , 283L/min
60Hz
12CFM , 340L/min
Ultimate Vacuum
5Pa , 150microns
Designed for deeper vacuum draw, this 1/2hp vacuum pump pulls vacuum down to 75 microns. Precision machined one-stage pump removes moisture from air conditioning systems to safely add refrigerant. This one stage vacuum pump is ideal for automotive air conditioning, HVAC work and other operations that require high vacuum pull from a compact pump.
One stage pump draws vacuum down to 75 micron
Durable die cast aluminum housing and convenient top handle for easy maneuvering
Dual ports for R134A and R12/R22 systems
Thermal and current overload protection
DIAPHRAGM PUMP 3"
DIAPHRAGM PUMP (ALSO KNOWN AS A MEMBRANE PUMP) IS A POSITIVE DISPLACEMENT PUMP THAT USES A COMBINATION OF THE RECIPROCATING ACTION OF A RUBBER, THERMOPLASTIC OR TEFLON DIAPHRAGM AND SUITABLE VALVES ON EITHER SIDE OF THE DIAPHRAGM (CHECK VALVE, BUTTERFLY VALVES, FLAP VALVES, OR ANY OTHER FORM OF SHUT-OFF VALVES) TO PUMP A FLUID.WILDEN T15(3") METAL PUMPWILDEN T15 PUMP. FAMOUS FOR ITS LONG LIFE AND EASY SERVICEABILITY, THE DURABLE WILDEN & reg; TURBO-FLO & trade; SERIES IS THE FIRST AIR DISTRIBUTION SYSTEM (ADS) THAT ORIGINATED IN THE AIR-OPERATED DOUBLE-DIAPHRAGM (AODD)PUMP INDUSTRY. THOUGH ENHANCEMENTS HAVE BEEN MADE, THESE PUMPS WORK WELL IN CERTAIN APPLICATIONS WHERE QUALITY OF THE COMPRESSED AIR IS A CONCERN. THESE PUMPS ARE EASY TO MAINTAIN. COST EFFECTIVE, AND ECONOMICAL. PORTABLE AND AVAILABLE IN A SINGLE-POINT EXHAUST OPTION FOR SUBMERSIBLE APPLICATIONS. THE TURBO-FLO EXCELS IN UTILITARIAN-TYPE APPLICATIONS. INCLUDING THE TRANSFER OF WATER, SLURRY AND MORE.PRODUCT SPECIFICATIONSSUCTION/DISCHARGE PORT SIZE76 MM(3") CAPACITY & bull; 0 TO 232 GALLONS PER MINUTE(0 TO 878 LITERS PER MINUTE) HEADS UP TO & bull;8.6 BAR (125 PSIG) SHIPPING WEIGHT & bull;ALUMINUM ALLOY & bull;316 SST & bull;CAST IRON SPECIFICATIONS: HEIGHT: 823 MM (32.4") WIDTH: 505 MM (19.9") DEPTH: 427 MM (16.8") AIR INLET: 19 MM (3/4" )FNPT LIQUID INLET: 76 MM (3") LIQUID OUTLET: 76 MM (3")WETTED MATERIAL: SHIP WEIGHT: ALUMINUM 53 KG (116 LBS) CAST IRON 92 KG (200 LBS) STAINLESS STEEL 81 KG (175 LBS) ALLOY C 110 KG (218 LBS PERFORMANCE: MAX. FLOW: RUBBER/TPE 878 LPM (232 GPM) TEFLON & reg; 704 LPM (186 GPM) MAX. PRESSURE: 8.6 BAR (125 PSIG) MAX. SOLIDS PASSAGE: 9.5 MM (3/8")MAX. SUCTION LIFT (WET): RUBBER/TPE 9.5 M (31.0')
Diaphragm Pump 3"Diaphragm Pump (Also Known As A Membrane Pump) Is A Positive Displacement Pump That Uses A Combination Of The Reciprocating Action Of A Rubber, Thermoplastic Or Teflon Diaphragm And Suitable Valves On Either Side Of The Diaphragm (Check Valve, Butterfly Valves, Flap Valves, Or Any Other Form Of Shut-Off Valves) To Pump A Fluid.Wilden T15(3") Metal Pumpwilden T15 Pump. Famous For Its Long Life And Easy Serviceability, The Durable Wilden & reg; Turbo-Flo & trade; Series Is The First Air Distribution System (Ads) That Originated In The Air-Operated Double-Diaphragm (Aodd)Pump Industry. Though Enhancements Have Been Made, These Pumps Work Well In Certain Applications Where Quality Of The Compressed Air Is A Concern. These Pumps Are Easy To Maintain. Cost Effective, And Economical. Portable And Available In A Single-Point Exhaust Option For Submersible Applications. The Turbo-Flo Excels In Utilitarian-Type Applications. Including The Transfer Of Water, Slurry And More.Product Specificationssuction/Discharge Port Size76 Mm(3")
Capacity & bull; 0 To 232 Gallons Per Minute(0 To 878 Liters Per Minute)
Heads Up To & bull;8.6 Bar (125 Psig)
Shipping Weight & bull;Aluminum Alloy & bull;316 Sst & bull;Cast Iron
specifications:Height: 823 Mm (32.4")Width: 505 Mm (19.9")Depth: 427 Mm (16.8")Air Inlet: 19 Mm (3/4" )Fnptliquid Inlet: 76 Mm (3")Liquid Outlet: 76 Mm (3")Wetted Material: Ship Weight:Aluminum 53 Kg (116 Lbs)Cast Iron 92 Kg (200 Lbs)Stainless Steel 81 Kg (175 Lbs)Alloy C 110 Kg (218 Lbsperformance:Max. Flow: Rubber/Tpe 878 Lpm (232 Gpm)Teflon & reg; 704 Lpm (186 Gpm)Max. Pressure: 8.6 Bar (125 Psig)Max. Solids Passage: 9.5 Mm (3/8")Max. Suction Lift (Wet): Rubber/Tpe 9.5 M (31.0')Teflon & reg; 8.5 M (28.0')(Dry): Rubber/Tpe 5.5 M (18.0')Teflon & reg; 3.9 M (13.0')
The electric pressure control switch is used in surface water pump systems, it examines the water automatically, stop the pump in the case of water shortage, protect the pump from damage caused by dry- running. Completely replaced traditional pump control system composed of pressure switch, pressure tank and check valve etc. We do not recommend this controller to be used with submersible pump.
Its major use is to boost pressure with maximium water output in surface water pumping systems.
SPECIFICATION
Maintains PressureMaintains FlowEasy To Operate , Touch ButtonsLights Indication for OperationsAutomatic Cut OffAutomatic Turns OnFrequency : 60 HzMax Current : 10 AmpMax. Working Bar Pressure : 10 Bar with GuageConnection : 1 Inch MaleInput Voltage 110V / 220VPressure Tank Not Required25 Mm ( 1 Inch Fitting )Comes With 2 Black Cables For Safe Hard Wiring . Hard Wiring Is The Safest WayProtection Grade : Highest IP65 for Outdoor Use.
Pressure Guage- YES
Used for Jet Pump - Garden Pump - Water Pump - Self - PrimingMaximum Operating Temperature 60 Degre
Diaphragm Rubber - P/n: 15-1010-52 - buna Diaphragm For 3" Pumps
Wilden Diaphragm Rubber - P/N: 15-1010-52 (Buna Diaphragm for 3" Pumps)
The Wilden Diaphragm Rubber P/N: 15-1010-52 is a high-performance Buna diaphragm specifically designed for 3" clamped or bolted Wilden pumps. Manufactured to Wilden's strict standards, this diaphragm ensures seamless and efficient operation across a variety of industrial applications. Made from durable Buna material, this diaphragm is ideal for industries requiring superior chemical resistance, flexibility, and operational reliability.
Lystus, the authorized representative of Wilden pumps in Nigeria, supplies this genuine Wilden spare part, ensuring top-quality products for the Nigerian market. This product is marketed and sold on the rehmie.com.ng online e-commerce marketplace by Lystus Technical, providing customers easy access to genuine Wilden pump spare parts.
Product Details
SKU: 3597725
Brand: Wilden
Unit: Pc(s)
Barcode Type: C128
Available in locations: Altools Services
Category: Industrial Pump
Subcategory: Wilden Pump
Manage Stock?: Yes
Reorder Quantity: 5.0000
Expires in: Not Applicable
Applicable Tax: None
Selling Price Tax Type: Exclusive
Product Type: Single
Key Features
Genuine Wilden Spare Part: Designed to meet Wilden & rsquo;s rigorous standards.
Primary Buna Diaphragm: Specifically designed for use in 3" Wilden clamped or bolted pumps.
Wetted Path Material Family: Undefined, adaptable based on your system needs.
Connection Inlet Size: 3" (76 mm) for compatibility with Wilden 3" pumps.
Lightweight and Durable: Weighs under 2 lbs (0.9 kg), ensuring easy installation.
Temperature Resistance: Operates between 10 & deg;F and 180 & deg;F, suitable for various industrial environments.
Clamped/Bolted Construction: Supports either clamped or bolted setups, allowing flexibility in use.
Technical Specifications
Part Number: 15-1010-52
Material: Buna
Pump Compatibility: 3" Wilden clamped/bolted metal and plastic pumps
Lower Temperature Limit: 10 & deg;F (-12 & deg;C)
Upper Temperature Limit: 180 & deg;F (82 & deg;C)
Product Weight: Under 2 lbs (0.9 kg)
Construction Type: Clamped/Bolted
Wetted Path Material Family: Undefined
Reorder Quantity: 5.0000
Applications
This Buna diaphragm (P/N: 15-1010-52) is suitable for use in 3" Wilden pumps and is commonly found in applications such as:
Chemical Processing
Food and Beverage
Pharmaceutical
Mining and Oil & Gas
Water Treatment
Wilden Pump Accessory
This diaphragm is an essential component for maintaining the performance of 3" Wilden pumps, providing reliable sealing and durability in high-pressure industrial applications. Its versatility makes it a key accessory for any operation using Wilden clamped or bolted metal and plastic pumps.
Lystus Technical & ndash; Authorized Representative of Wilden Pumps in Nigeria
Lystus, your trusted partner for Wilden pumps and spare parts, offers genuine Wilden products like the Wilden Diaphragm Rubber P/N: 15-1010-52. We ensure timely delivery and expert support to keep your operations running smoothly. This product is available for purchase through the rehmie.com.ng online marketplace, where Lystus ensures the highest quality of Wilden pump accessories.
4o
EASY TO PUMP10 GPM Manual Siphon Drum Barrel Pump
Transferring liquid out of a drum barrel can be a pain! Safely use this portable TERA PUMP TRWS25 Manual Siphon Pump to transfer or empty tanks, barrels, drums, carboys and IBCs
Easy and smooth action & goose-neck discharge spout
10 GPM ROTARY BARREL PUMPFEATURES2 inch NPT threaded adjustable bung adapter (To securely fasten pump onto Barrel) 40 inch long, 1 inch suction pipe, 50 inch height
Heavy-duty Cast Iron & Steel construction including the pump impellerUse on barrels, drums and small tanks10 GPM ROTARY BARREL PUMPPERFICT FIT FOR DRUMSSuction Type: Rotary operated liquid transfer pumpDimensions: 14.1 x 6.2 x 5.7 InchesItem Weight: 4lbs (1.8kgs)Applicable Liquids - Gasoline, kerosene, oil, diesel, hydraulic fluid, lubricating oil, antifreeze (ethylene glycerol), other non-corrosive liquids
NOT FOR USE WITH DRINKING WATER
10 GPM ROTARY BARREL PUMPEASY CRANKHand Operated - Simply begin cranking the handle and begin siphoning or transferring the liquid.
Durable - No need to worry about damaging this pump since it is cast from heavy-duty casting iron and steel
Features & details2" NPT threaded bung adapter / 40" long 1" suction pipe / 50" heightAdjustable Bung Adapter / Flow rates of up to 10 gallons per minute (gpm)Heavy-duty all steel and cast iron construction including the pump impellerEasy and smooth action / Gooseneck discharge spout / Use on barrels, drums and small tanksSmoothly pumps dispensing oils, fuels, gasoline, kerosene, diesel fuel and non-corrosive fluids (not for drinking water)
When the taps are opened it starts the electric pump automatically after a decrease in pressure. When the taps are closed, the fluid flow interrupts at the maximum pressure level and stops the electric pump. If the pump runs without water, the controller off the pump and prevents.
APPLICATIONSHouse wayering systemsBosster PumpsCar wash pumpsSubmersible/ Openwell pumpsRO plant
Maintains pressure and flow.Easy to operate with simple push button controls.Led lights indicate the functioning of the pump.Automatically stops if no water is in the pump.No pressure tank required.Automatic control for water pump.
1.5 BAR AUTOMATIC PUMP CONTROL
Voltage: 220-240V~50/60Hz
Max current: 10A
Starting pressure: 1.5bar
Max pressure: 10bar
Pipe diameter: 1 & Prime; x 1 & Prime;
Protection degree: IP65
HAND ROTARY PUMPS
HAND PUMPS ARE MANUALLY OPERATED PUMPS THAT USE HUMAN POWER AND MECHANICAL ADVANTAGE TO MOVE FLUIDS OR AIR FROM ONE
PLACE TO ANOTHER. THEY ARE WIDELY USED FOR A VARIETY OF INDUSTRIAL, MARINE, IRRIGATION AND LEISURE ACTIVITIES.A HAND ROTARY
PUMP IS A MANUAL PUMP WHICH DOESN'T REQUIRE ELECTRICITY OR ANY OTHER FORM OF POWER IN ORDER TO OPERATE, WHICH MAKES THEM
GOOD FOR BEING PORTABLE AND FOR USE IN REMOTE LOCATIONS, AS WELL AS BEING COST-EFFECTIVE.LOW RISK OF MEDIA ENTRAPMENT AND
COMPACTION,HIGH EFFICIENCY WITH LOW LIFE CYCLE COSTS AT THE SAME TIME WITH EASY MAINTENANCE AND COMPACT DESIGN. GENTLE, LOW-
PULSATION AND CONSTANT CONVEYING WITH HIGH DOSING PRECISION.
Product Description Portable Electric Air Pump powered by 230 Volt Ac Motor with Quick-fill Design with Three Nozzles -
Makes your inflating your inflatables easy! This Electric Air Pump uses 230-240 Volt AC house current and includes three interconnecting nozzles. It's perfect for large inflatables such as pools, boats and other large inflatable toys.
Made from Best quality Plastic. It is Reusable year after year. Require only a common household vacuum cleaner (electric pump or hand suction pump) to create a vacuum.
Application: Applicable to (for air inflation): airbed, air pool, air boat, air sofa, air bathtub, air-filled toys, swimming ring, balloons etc.
Applicable to (for air deflation): vacuum storage bags etc.
Inflation: Connect the pump to 220V power supply.
Connect the inflation fitting with the inflation mouth- turn on the switch and the inflation begins ("-" stands for "on" and "o" stands for "off").
Please make sure the valve for inflation is not blocked- otherwise the pump may be damaged due to overheat.
Please don't misuse the deflation opening as the inflation opening. Deflation: 1.Open the valve of the article.
Connects the fitting that is suitable in size to the deflation opening (if the size of deflation opening is right- no need of the other three fittings)- then turn on the switch and begin to suck the air out. ("-"stands for "on" and "o" stands for "off")
Please make sure the valve for inflation is not blocked, otherwise the pump may be damaged due to overheat.
Product Features:-
1.Power : 150W
Voltage: 220-230V Rated 2
Pressure: 5000pa-10000pa
The electric switch is used in water systems, start and stop the pump automatically. Examine the water automatically, stop the pump in the case of water shortage, protect the pump from damage caused by dry-running. Completely replaced traditional pump control system composed of pressure switch, pressure tank and check valve etc.
Features:
Automatic start and stop the pump when tap open/close.
Reduce water hammer effects.
Simple control to maintains constant pressure during operation.
Dry running protection to protect motor, extra pump life.
In order to avoid the pump on/off & pressure high/low problems.
Springdab automatic pump control -Pumping Pressure Enhancement
automatic pump control-220v - 240v - 50/60HzMax 1Mpa (10bar)Max 10A MAX 1.1kwmodel: EPC-3Water pumping pressure enhancement
Automatic pump controllers are built for a quiet running operation. Built-in non-return valve(NRV), pressure switch, and electronic control with dry running function integrated with manual reset button. It is assembled on a pump for automatic water supply.
When the taps are opened it starts the electric pump automatically after a decrease in pressure. When the taps are closed, the fluid flow interrupts at the maximum pressure level and stops the electric pump. If the pump runs without water, the controller off the pump and prevents.
APPLICATIONSHouse wayering systemsBosster PumpsCar wash pumpsSubmersible/ Openwell pumpsRO plant
Maintains pressure and flow.Maintains pressure and flow.
Easy to operate with simple push button controls.Led lights indicate the functioning of the pump.Automatically stops if no water is in the pump.No pressure tank required.Automatic control for water pump.Input Voltage:220V-240V.Frequency:50-60Hz.Maximum Current :10A.Maximum Power:1.1KW - 1.5KW.Max Working Pressure:10Bar.
