Model |
SSB-120M |
Production Country |
India |
Size (L x W x H cm) |
42.0 × 13.5 × 29.5 |
Weight (kg) |
11.3 |
Color |
Black |
Main Material |
Metal |
From: Sole Authorised Distributor in NigeriaDimensions: W420 × H135 × D295 mmWeight: 8.5kgModel: SSB-120Colour: Black
About AHUJA: Ahuja started out from India in 1940 and has grown into several large well-equipped factories employing hundreds of engineers manufacturing the widest range of PA System Equipment to meet every PA need that can ever be imagined through constant product development, thereby guaranteeing absolute reliability on the products even in the most extreme operating and climatic conditions.
MIXER AMPLIFIERS
MEDIUM WATTAGE PA MIXER AMPLIFIERS
SSA-120®M
120 WATTS
MEDIUM WATTAGE PA MIXER AMPLIFIER
- 5 Mic & 2 Aux Inputs.
- Preamplifier and Line Output for connecting to a Booster Amplifier and for recording the programme.
- Instant transfer to DC power (Car Battery) if AC power fails.
- Bass & Treble Tone Controls cut type.
SPECIFICATIONS:
Power Output: 160W Max., 120W RMS at 10% THD, 105W RMS at 5% THD, 95W RMS at 2% THDOutput Regulation≤ 2 dB, no load to full load at 1kHzInput Channels: 5 × Mic 0.65mV/4.7kΩ, 2 × Aux 100mV/470 kΩFrequency Response: 50-15,000Hz ±3dBSignal to Noise Ratio: 60dBTone Controls: Bass: -10dB at 100Hz, Treble: -10dB at 10kHzOutputs: Preamp 200mV/600Ω, Line 1V/1kΩSpeaker Outputs: 4Ω, 8Ω, 16Ω, 70V & 100VPower Supply: AC: 220-240V 50/60Hz DC: 12V (12V Car Battery)Power Consumption: AC: 250VA DC: 5.5ADimensions: W420 × H135 × D295 mmWeight: 11.3kg
Key Features
5 Mic & 2 Aux Inputs.
Preamplifier and Line Output for connecting to a Booster Amplifier and for recording the programme.
Instant transfer to DC power (Car Battery) if AC power fails.
Bass & Treble Tone Controls cut type.
