Model |
SSB-160M |
Production Country |
India |
Size (L x W x H cm) |
42.0 × 15.5 × 32.0 |
Weight (kg) |
13.6 |
Color |
Black |
Main Material |
Metal |
From: Sole Authorised Distributor in NigeriaDimensions: W420 × H155 × D320 mmWeight: 13.6kgModel: SSB-160MColour: Black
About AHUJA: Ahuja started out from India in 1940 and has grown into several large well-equipped factories employing hundreds of engineers manufacturing the widest range of PA System Equipment to meet every PA need that can ever be imagined through constant product development, thereby guaranteeing absolute reliability on the products even in the most extreme operating and climatic conditions.
SSA-160®EM160 WATTSMEDIUM WATTAGE PA MIXER AMPLIFIE
- 5 Mic & 2 Aux Inputs.
- Preamplifier and Line Output for connecting to a Booster Amplifier and for recording the programme.
- Line Input for connecting the output from any external mixer or permitting SSA-160EM to be used as a Booster Power Amplifier.
- Resettable circuit breaker for protection against overload and short circuit.
- Instant transfer to DC power (Car Battery) if AC power fails.
- Box Speaker/Driver Unit selector switch. Bass boost defeated at Driver Unit position for safer operation of driver units.
SPECIFICATIONS:
Power Output: 220W Max., 160W RMS at 10% THD, 140W RMS at 5% THD, 120W RMS at 2% THDOutput Regulation: ≤ 2 dB, no load to full load at 1kHzInput Channels; 5 × Mic 0.65mV/4.7kΩ, 2 × Aux 100mV/470kΩ, 1 × Line 1V/50kΩFrequency Response: 50-15,000Hz ±3dBSignal to Noise Ratio: 60dBTone Controls: Bass: ±10dB at 100Hz, Treble: ±10dB at 10kHzOutput: Preamp 200mV/600Ω, Line 1V/1kΩSpeaker Output: 4Ω, 8Ω, 70V & 100VPower Supply: AC: 220-240V 50/60Hz DC: 24V (2×12V Car Battery)Power Consumption: AC: 300VA DC: 4ADimensions: W420 × H155 × D320 mmWeight: 13.6kg
Key Features
5 Mic & 2 Aux Inputs.
Preamplifier and Line Output for connecting to a Booster Amplifier and for recording the programme.
Line Input for connecting the output from any external mixer or permitting SSA-160EM to be used as a Booster Power Amplifier.
Resettable circuit breaker for protection against overload and short circuit.
Instant transfer to DC power (Car Battery) if AC power fails.
Box Speaker/Driver Unit selector switch. Bass boost defeated at Driver Unit position for safer operation of driver units.
