Buy Smart Wifi 3-phase Power Meter + Chint Nm1-125s/3340 100a

Smart Wifi 3-phase Power Meter + Chint Nm1-125s/3340 100a Circuit Breaker Shunt Trip

₦ 197,399.00 ₦ 209,999.00 -6%

0 No Reviews

Product SKU: RENG443402

Quantity

In Stock

Product Highlights

The meter is used in 3-phase 4-wire power grid. The meter is designed to measure AC active energy and variable parameters. It has remote read by Wi-Fi (Smart life or Tuya smart APP). It is a long life meter with the advantage of high stability, high over load capability, low power loss and small volume.

100% Secure Payments

TrustPay

Pay Online Delivered T&C^*

Check your shipping location

Have one to sell? Sell on rehmie

Product Specifications
Description

Description:

Product details
The meter is used in three-phase four wire power grids. The meter is designed to measure AC active energy and variable parameter. It has remote read by Wi-Fi (Smart life or Tuya smart APP). It is a long life meter with the advantage of high stability, high over load capability, low power loss and small volume.

Basic Function

1.LCD with backlight, keypad for LCD step by step

2. Bidirectional total active energy measurement, reverse active/ energy measure in the total active/reactive energy

3. The meter LCD also display real voltage, current, active power, reactive power, power factor, frequency, import active energy, export active energy, reactive energy

4. Overvoltage protection, overload protection, voltage unbalance protection which can set by APP or by button

5.reverse phase sequence protection, which function can be on/off by button

6. Lose phase indication, and still measure lose one o two phase under three-phase four wire connection

7. Timing control by APP

8. Hour/Day/Month/Year history active energy consumption tracking by APP

9.check the real current, voltage, active power by APP

10. Wi-Fi communication, can read and remote control on/off by mobile phone APP

11. Prepayment function, if balance used up, it will cut off automatic. This function can be on/off by APP.

12. Manual Control by button with mode 4 under lose Wi-Fi

13. Voice control: once you have this switch, you can connect it with Amazon Alexa (Amazon Echo/dot/tap) or Google Assistant for voice control

14. Pulse LED indicates working of meter, Pulse output with optical coupling isolation

15. Energy data can store in memory chip more than 15 years after power off

16.35 mm din rail installation, bottom type wire connection

Note:This meter Only supports 2.4G Wireless Network, NOT for 5G

NEW function:

1. Import/export energy records on APP, PV difference power display
2. 30 days kWh records email export Excel function, APP display long time 60 days hour kWh records
3. Carbon emissions settings
4. Note that there is no temperature display, leakage protection, unbalance protection function, external power failure, the meter will not be switched off for protection
5. The function of comparing the power with the power of the total meter
6. Active Power curve display every 15 minutes for 24 hours of the day 1
7. Overvoltage and overcurrent protection settings
8. Operation records and failsafe records
9. Password protected settings

10. Three-phase voltage unbalance protection

11. for 5A/CT model outer CT connection, the APP can set the CT ratio, and the energy kWh will display primary data
