10000 Lumens LED Flashlight Powerful Lanterna X900 Portable Light 12x XML-T6 12T6 Torch Hunting Lantern for 18650 Battery
[product name] 12 lights T6 super bright flashlight
[Color] black, ochre shell, aluminum alloy head cover, green switch cap
[Light Beads] 12 CREE XML-T6 Lamp Beads
[IC gear] 5 files, weak-medium-strong-flash-SOS.
[Reflection Cup] High-precision lathe aluminum alloy light cup
[Super-shot area] 160 wide-angle illumination, wider vision.
[Light head size] 78.6*41.5*326mm (front cover diameter * back cover diameter * length)
[single lamp weight] 0.63kg
[set weight] 0.75kg
[Battery description] 3*18650 plus casing (or 3*26650)
[Battery weight] 45 grams
[Package] kraft paper box 280mm*86.7mm*86.7mm
First, the circuit description
1. The battery is positive (outside the lamp) and the negative is inward (tail);2. The switch is in the middle, the tap switch is the dimming function, and the dimming order is high, low, and off. Long press to flash;3. Special tips:
a. Do not use overpressure;
b. The battery is facing the front, do not reverse, otherwise it will burn the board;
c. Pay attention to controlling the temperature change of the flashlight to ensure heat dissipation;
d. Non-professionals should not open the circuit board.4, warranty description: open or processed circuit board no longer warranty.
Second, lithium battery instructions
1. The battery for this flashlight is mainly 18650/26650 lithium battery.2. Characteristics of lithium battery: The charging method of lithium battery and mobile phone battery is completely different; lithium battery has no memory and can be charged at any time.
Don't overcharge.3, the first charge for 6 hours at least, after the green light according to the charger can be on. Not necessarily overcharged.4. The natural discharge rate of lithium batteries will release about 1% or less of their charge every day when not in use, although slow,
But prevent it from being placed for too long.5, pay attention to the battery's waterproof, anti-fall and so on.6, special tips to use anti-overcharge, anti-reverse, anti-short circuit "three anti-" charger;7. If the battery is not used for a long time, the battery should be fully charged and recharged and discharged once every three months.8. Warranty description: The battery is no longer covered after delivery.Third, the use of flashlight instructions1. When the flashlight is in use, it should be selected according to the voltage and battery requirements of the flashlight. Do not use it indiscriminately to prevent the circuit board from being burned.
Do not use batteries of the same model and different voltages at the same time.2. In use, turn off the flashlight when the brightness of the flashlight changes significantly to prevent the battery from being over-discharged.3, cooling skills: flashlight in the process of use, to ensure heat. When the battery is strongly required to be fully charged, it is best to use low first.
Bright, this will allow the lamp holder and battery of the flashlight to extend the life of the product! Holding the flashlight with your hand is the best heat sink
Way; it is recommended to discharge or turn off according to the heating condition of the flashlight when lighting, and then light up after the temperature drops.
For heat dissipation.4. For the description of the flashlight on waterproofing and shockproof, strengthen the prevention.5, the inner wall of the lamp cup is kept clean, absolutely can not be wiped by hand or a hard object; the fingerprint on the lens can be used with a cotton swab.
Gently wipe the lens cleaner.6, can not direct the flashlight light to the human eye, super bright and glare, so as not to affect vision, especially children.7. If you do not use the flashlight for a long time, please take out the battery (one month or longer) to avoid chemical corrosion.Fourth, the protection instructions1. Do not touch the flashlight with sunlight, water, chemicals and corrosive gases for a long time to avoid damage to the protective layer of the flashlight.2. In order to keep the “0” ring and the thread from rotating smoothly, wipe the Vaseline oil on the surface 2-3 times a year.Five, troubleshooting1. Check the battery: Make sure the battery has electricity and install the battery in the correct direction. Do not use batteries of different brands. New and old batteries are not.
Can be mixed.2. Check the tail cover: Ensure that the tail cap screws are in good contact with the tail PCB.3. Pay attention to whether the lamp head is loose.
Key Features
high quality
Super bright
Adventure
self-defense
hunting
What's In the Box
A set of 12T6 flashlights
