Recommended Daily Volume | Up to 3,000 pages per day |
Throughput Speeds* | Black-and-white/grayscale/color: up to 25 ppm/50 ipm at 200 and 300 dpi |
Scanning Technology | Dual CIS (CMOS); Grayscale output bit depth is 256 levels (8-bit); color output bit depth is 24 bits (8 x 3) |
Operator Control Panel | 1.5-inch 7 segment LED |
Optical Resolution | 600 dpi |
Illumination | Single RGB LEDs |
Output Resolution | 75 / 100 / 150 / 200 / 240 / 250 / 260 / 300 / 400 / 500 / 600 / 1200 dpi |
Max./Min. Document Size** | 216 mm x 356 mm (8.5 x 14 in.) / 52 mm x 52 mm (2.08 in. x 2.05 in.) Long document mode: 216 mm x 3,000 mm (8.5 in. x 118 in.) |
Paper Thickness & Weight | 34 - 413 g/m2 (9 - 110 lb.) paper; ID card thickness: up to 1.4mm (0.05 in.) |
Feeder | Up to 80 sheets of 80 g/m2 (20 lb.) paper Handles small documents such as A8, ID cards, embossed hard cards, and insurance cards (portrait and landscape orientations) |
Paper Feeding Detection | Multifeed with ultrasonic technology, Intelligent Document Protection |
Connectivity | USB 2.0 High Speed (cable included) - USB 3.0 compatible |
Software Support | Standard Software: Alaris Info Input Solution, Alaris Capture Pro Software and KODAK Asset Management Software. (WINDOWS only) WINDOWS Bundled software: TWAIN, ISIS, WIA Drivers; Alaris Smart Touch or Alaris Capture Pro Limited Edition (via web download) LINUX (TWAIN and SANE) drivers (through web download) KOFAX certified |
Imaging Features | Barcode reading; Perfect Page Scanning; iThresholding; adaptive threshold processing; deskew; autocrop; relative cropping; fixed crop; add/ remove border; electronic color dropout; dual stream scanning; enhanced color management; enhanced color adjustment; brightness and contrast adjustment; automatic orientation; automatic color detection; background color smoothing; intelligent image edge fill; image merge; content-based blank page detection; streak filtering; round/rectangular hole fill; sharpness filter; auto brightness; auto white balance; all-color dropout; multi-color dropout; long document scanning (up to 3000 mm/118 in.) |
File Format Outputs | Single and multi-page TIFF, JPEG, RTF, BMP, PDF, searchable PDF, TXT, PNG, CSV, Word and Excel |
Accessories (Optional) | Alaris E1000 Series Feed Roller Kit Alaris E1000 Series Stacking Deflector Accessory Alaris A4/Legal Flatbed Alaris Passport Flatbed |
Electrical Requirements | 100-240 V (International); 50-60 Hz |
Power Consumption | Off/Standby/Sleep mode: < 0.3 watts; Running: <25 watts |
Environmental Factors | EPEAT Registered ENERGY STAR Qualified Operating Temperature: 10-35° C (50-95° F) Operating Humidity: 15% to 80% RH |
Recommended PC Configuration | Minimum PC configuration with Smart Touch: Intel Core i3 processor or faster, at least 4 GB RAM (Microsoft Windows) Minimum Terminal PC / Citrix Receiver configuration for scanning only: Any 1 GHz processor or faster, at least 2 GB RAM |
Approval & Product Certifications | AS/NZS CISPR 32 (Class B RCM mark), CAN / CSA - C22.2 No 60950-1 (TUV C mark), Canada CSA-CISPR 32 / ICES-003 (Class B), China GB4943.1; GB9254 Class B (CCC S&E mark), EN55032 ITE Emissions (Class B), EN55024 ITE Immunity (CE mark), EN60950-1 (TUV GS mark), IEC60950-1:2005, IEC62368-1:2014, Taiwan CNS 13438 (Class B); CNS 14336-1 (BSMI mark), UL 60950-1 (TUV US mark), CFR 47 Part 15 (FCC Class B) |
Consumables Available | Alaris E1000 Feed Roller Kit, roller cleaning pads, STATICIDE Wipes, transport cleaning sheets, Brillianize Detailer Wipes |
Dimensions | Weight: 3.3 kg (7.2 lbs.) Depth: 204 mm (8.0 in.), not including input tray and output tray; Width: 312 mm (12.3 in.) Height: 182.5 mm (7.2 in.), not including input tray; Depth with Input Tray: 269 mm (10.6 in.); Height with Input Tray: 231.6 mm (9.1 in.); |
