Features
Throughput Speeds
Throughput Speeds at 200 dpi/300 dpi † (landscape, A4 size, black and white/grayscale/color) -
i3200, i3250 ADF: Up to 50 ppm
i3400, i3450 ADF: Up to 90 ppm
i3500 ADF: Up to 110 ppm
Recommended Daily Volume - i3200/i3250 ADF: Up to 15,000 pages per day
i3400/i3450 ADF: Up to 20,000 pages per day
i3250/i3450 integrated A4 size flatbed: 100 pages per day
i3500 ADF: Up to 25,000 pages per day
Scanning Technology - Dual CCD;
Grayscale output bit depth is 256 levels (8-bit); color capture bit depth is 48 bits (16 x 3); color output bit depth is 24 bits (8 x 3)
Optical Resolution - 600 dpi
Output resolution - 100 / 150 / 200 / 240 / 250 / 300 / 400 / 500 / 600 dpi
Illumination - Dual LED
Operator Control Panel - Graphical LCD display with four operator control buttons
Max. / Min. Document Width - Auto-feed: 305 mm (12 in.) / 63.5 mm (2.5 in.)
Hand-feed: 305 mm (12 in.) / 50 mm (2 in.)
Max. / Min. Document Length - Auto-feed: 863.6 mm (34 in.) / 63.5 mm (2.5 in.)
Hand-feed: 863.6 mm (34 in.) / 50 mm (2 in.) (rear exit only)
Long document mode: 4.1 meters (160 in.) maximum length
(The scanners support continuous scanning mode)
Paper Thickness and Weight - 34-413 g/m2 (9-110 lb.) paper
Feeder/Elevator - Up to 250 sheets of 80 g/m2 (20 lb.) paper; i3500: up to 300 sheets of 80 g/m2 paper
Paper Path Options - Documents can exit into the front output tray, or at the rear of the scanner if the straight-through paper path option is manually selected
Document Sensing - Ultrasonic multi-feed detection; Intelligent Document Protection
Connectivity - USB 2.0; USB 3.0 Compatible
Software Support - Fully supported by KODAK Capture Pro Software and KODAK Asset Management Software
WINDOWS Bundled software: TWAIN, ISIS, and WIA drivers; KODAK Capture Pro Software Limited Edition; Smart Touch (LINUX SANE and TWAIN drivers available from www.kodakalaris.com/go/scanonlinux*); KOFAX certified
Barcode Reading - One per page: Interleaved 2 of 5, Code 3 of 9, Code 128, Codabar, UPC-A, UPC-E, EAN-13, EAN-8, PDF417
Features in the Scanner -Bar Code Reading; Perfect Page Scanning; iThresholding; adaptive threshold processing; deskew; autocrop; relative cropping; aggressive cropping; electronic color dropout; dual stream scanning; interactive color, brightness and contrast adjustment; automatic orientation; automatic color detection; intelligent background color smoothing; intelligent image edge fill; image merge; content-based blank page detection; streak filtering; image hole fill; sharpness filter; auto brightness, special document mode; continuous scanning mode; toggle patch; auto photo cropping; segmented bitonal images
File Format Outputs - Single and multi-page TIFF, JPEG, RTF, BMP, PDF, searchable PDF
Warranty – 1 Year Warranty
Electrical Requirements - 100-240 V (International); 50-60 Hz
Power Consumption - Off mode: <0.5 watts; Running: <49 watts; Sleep mode: <2.8 watts
Environmental Factors - EPEAT Registered
ENERGY STAR qualified scanners
Operating temperature: 15-35° C (59-95° F)
Operating humidity: 15% to 80% RH
Acoustical Noise - (operator position sound pressure level)
Off or Ready mode: <30 dB(A)
Operating mode: <60 dB(A); <66dB(A) i3500 only
Recommended PC Configuration - INTEL CORE i7 processor, 3.4 GHz or higher, 4 GB RAM or more (WINDOWS and LINUX)
Consumables Available - Roller cleaning pads, STATICIDE Wipes, consumables kit (includes feed module, separation module, separation pad)
Accessories/Options - KODAK Legal Size Flatbed Accessory; KODAK A3 Size Flatbed Accessory; document imprinting accessory (rear-side, post-scan imprinting of up to 40 alphanumeric characters, with 11 imprinting positions)
Dimensions - i3200/i3400/i3500: Height: 9.4 in. / 23.8 cm; Width: 17 in. / 43.18 cm; Depth (with input tray closed): 14.6 in. / 37.1 cm
i3250 / i3450: Height: 10.2 in. / 25.7 cm; Width: 17 in. / 43.18 cm; Depth (with input tray closed): 14.6 in. / 37.1 cm
Weight - i3200/i3400/i3500: Weight: 35 lbs / 15.8 kg
i3250/i3450: Weight: 39 lbs / 17.7 kg
† Throughput speeds may vary depending on your choice of driver, application software, operating system and PC
*Smart Touch functionality is not supported on these Operating Systems
** Available for the i3200/i3250, i3400/i3450
Operating System Compatibility Definitions
Supported – Kodak Validated
Windows 10 (32-bit and 64-bit)
Windows 8.1 (32-bit and 64-bit)
Windows 8 (32-bit and 64-bit)
Windows 7 SP1 (32-bit and 64-bit)
Windows Vista SP2 (32-bit and 64-bit)
Linux Ubuntu 14.04 (LTS) (32-bit and 64-bit)*
*Smart Touch functionality is not supported on these Operating Systems
