Model |
Energy KWh Meter |
Production Country |
China |
Size (L x W x H cm) |
9x7x4 |
Weight (kg) |
0.16 |
Color |
multicolor |
Features LCD display with Backlight Pulse LED indicates working of meter
35mm din rail installation The meter is multifunctional display Energy kWh temporary Energy kWh real Voltage real Current by manual pressing
Hold the on for 6 seconds to Reset the temporary kWh
Two wiring modes upper input lower outputlower input upper output
NOTE This Temporary kWh is available RESET to be Zero The kWh can not be Reset
Maximum current 80A
Pulse frequency 1000imp kwh
Voltage 120V
Material Plastic
colour Greywhite
Package Contents
1 x Energy KWh Meter
Only the above package content other products are not included
Note Light reflection and different displays may cause the color of the item in the picture a little different from the real thing The measurement allowed error is - 1-3cm
What's In the Box
1 x Energy KWh Meter
