FEATURES:
1. High efficiency, long life and high reliability
2.Low dc ripple, high efficiency
3. Low operation temperature & long performance life
4. Excellent insulation property, high dielectric strength
5. 100% full-load burning test 6.
INPUT:
1. AC input voltage range(V):AC 220V-240V±15% (switch replacement)
2. Input current(A):6.5A /115V,4A /230V
3. Frequency (Hz):50/60Hz
4. Efficiency:91% Typ(230VAC Full Load)
5. Inrush current(A):25A/115V 50A/230V cold start
6. Leakage current(mA):<3.5mA/240VAC
OUTPUT:
1. Output Voltage(V):+12V DC
2. Voltage Regulation:±10%
3. Output Current(A):30A
4. Current Range (A):0-30A
5. Rated Power(W) :500W
6. Start time, hold-up time(ms):Ton≤200ms,Td≥30ms @230Vac Full Load
7. Rise time(ms):Typ:100ms @230Vac Full Load
8. Ripple/Noise(mVp-p):150mVp-p
PROTECTION:
1. Over voltage Protection:>115%-135% Rated output voltage
2. Over load Protection:>105%-150% Auto recovery
3. Short circuit Protection:Latched
