| Model |
KB32 - 16AX 250V 2GANG 2WAY Switch |
| Production Country |
France, China |
| Size (L x W x H cm) |
8.7 x 0.8 x 8.7 |
| Weight (kg) |
0.1 |
| Certifications |
Eco Friendly |
| Color |
White |
| Main Material |
Polycarbonate |
| From the Manufacturer |
NA |
| Care Label |
NA |
Vivace is a range of switches and sockets built for style and function for modern interior design. A switch and socket set with the style and modern simplicity of the Bauhaus movement.
Inspired by the influential Bauhaus movement, Vivace expresses a pleasing form follows function. With a slim and trim profile, the sleek clean lines and subtle curves manifest an art of simple, elegant minimalism. Every piece in this robustly constructed range sits perfectly within the context of any modern interior design. Vivace, a style of modern simplicity that is always within your reach.
A slim, trim profile, pleasing to the eye, clean and refined, the Vivace is a switch and socket set that perfectly complements the modern lifestyle.
Inspired by the simple, elegant minimalism of the supremely influential Bauhaus movement, every piece in this robustly constructed range expresses a pleasing form following function.
Unmarred by visible fastenings, the sleek clean lines of Vivace present a cool refined touch of style to almost any interior.
The Vivace switch and socket set is a robustly constructed range built to perfectly complement the modern lifestyle.
Key Features
Range - Vivace
product or component type - Switch
Device short name - KB32
Device application - Control
Device presentation - Complete Mechanism
Switch function - 2-way
Actuator - Rocker
Number of gangs - 2 gang
Colour tint - White
Material - Polycarbonate: grid plate, Polycarbonate: surround, Polycarbonate: base
projecting depth - 8 mm
Device mounting - Flush
Mounting support - Wall mounted
Fixing mode - By screw M3.5
Fixing center - 60.3 mm
Embedding depth - 35 mm
Rated current - 16 AX at 250 V AC, inductive - 16 AX at 250 V AC, fluorescent
[Ue] rated operational voltage - 250 V AC
Network frequency - 50 Hz
Contacts material - Brass and phosphor bronze
Connections - terminals - Pillar terminal
Terminal identifier - L2, L1, COM
Tightening torque - 0.4 N.m
clamping connection capacity - 2.5 mm²
Clean, geometrically balanced design
Thin: 8mm slim at the thickest point
16 AX Switches: handles additional loading and enables wider application
High fatigue resistance capacity
All sockets are inserted with shutter doors for a longer lifecycle
What's In the Box
1 Vivace 16AX 250V 2 Gang 2 Way Switch
