SYSTEM REQUIREMENTS
macOS 10.12, 10.13, 10.14 (latest update), Intel Core i5, 4 GB RAM
Windows 10 version 1803 or later (64 Bit), Intel Core i5 or equivalent CPU, 4 GB RAM
SUPPORTED AUDIO FORMATS
MP3, WAV, AIFF, Audio-CD, FLAC, Ogg Vorbis, non-DRM AAC
GENERAL
Monitor with 1280 x 800 screen resolution, USB 2.0, 1 GB free disc space. An internet connection and a graphics card which supports OpenGL 2.1 or higher are required to download and activate TRAKTOR software. Once installed and activated, all products can be used offline.
SUPPORTED DRIVERS
Core Audio, WASAPI, ASIO, DirectSound
DIMENSIONS
542 mm / 339 mm / 60.5 mm
21.34" / 13.35" / 2.38“
UDIO INPUTS (A/D)Channels:4 StereoSample Rate / Resolution96-kHz / 24-bitConverterCirrus Logic CS5368LINE INPUTSDNR (a-weighted)110 dBFrequency Response20 Hz - 20 kHz, +0.1/- 0.05 dBTHD+N0.002%MIC INPUTDNR (a-weighted) @ 1 kHz104 dBFrequency response20 Hz - 20 kHz, +0.04/- 2.7 dBPHONO INPUTSInput Impedance48.5kΩDNR (a-weighted) @ 1 kHz78 dBAUDIO OUTPUTS (D/A)Channels2 StereoSample Rate / Resolution96-kHz / 24-bitConverterCirrus Logic CS4385LINE OUTPUTS (XLR & 1/4" BOOTH)DNR (a-weighted)110 dBFrequency Response20 Hz - 20 kHz, +0.4/- 0.2 dBTHD+N0.001%LINE OUTPUTS (RCA)DNR (a-weighted)110 dBFrequency Response20 Hz - 20 kHz, +0.6/- 0.2dBTHD+N0.001%HEADPHONE OUTPUTLoad Impedance33ΩDNR (a-weighted)104 dBFrequency Response20 Hz - 20 kHz, +0.4/- 0.3 dB
