Bite Type Fittings Consists of Three Parts: Joint Body, Card Sleeve and Nut. When the Card Sleeve and Nut Set Are Inserted Joint Body on the Steel Pipe, Tighten the Nut, the Outer Side of the Front End of the Card Sleeve Is Fitted with the Joint Body Conical Surface, and the Inner Blade Is Evenly Bit into the Seamless Steel Pipe to Form an Effective Seal. It Is Easy to Install and Has High Pressure Resistance, So It Is Widely Used.
Advantages
Ferrule Connector Has the Characteristics of Reliable Connection, High Pressure Resistance, Thermal Endurance, Good Sealing Performance and Repeatability, Convenient Installation and Maintenance, Safe and Reliable Work, Etc.
Working Principle
The Working Principle of Ferrule Connector Is to Insert the Steel Pipe into the Card Sleeve, Lock It with the Card Sleeve Nut, Resist the Card Sleeve, Cut It into the Pipe and Seal It. It Does Not Need Welding When Connecting with Steel Pipe, Which Is Beneficial to Fire Prevention, Explosion Prevention and Aerial Work, and Can Eliminate the Disadvantages Caused by Careless Welding. Therefore, It Is a Relatively Advanced Connector in the Pipeline of Automatic Control Devices of Oil Refining, Chemical Industry, Petroleum, Natural Gas, Food, Pharmacy, Instrumentation and Other Systems. It Is Suitable for Connecting Oil, Gas, Water and Other Medium Pipelines.
Indicators
Manufacturing Standard: Gb3733.1 ~ 3765-83
Nominal Pressure: 25mpa -- 40mpa
Applicable Tempure: ≤ 450 ℃
Applicable Medium: Oil, Water, Gas and Other Non-Corrosive Or Corrosive Medium
Manufacturing Material: 304 316 20#
Piping: Ordinary-Grade Precision Seamless Steel Pipe of 4~42
Taper Pipe Thread: ZG,G,NPT, Etc.
Key Features
Customized Processing: Yes
Installation Form: Card Sheath
Type: Straight
Brand: SNS
Material: 0~60
Model: Yz2
Scope of Application: Wide
Product Alias: Stainless Steel Card Sets Straight Connector
Nozzle Caliber: 3 4 6 8 10 12 14mm
Temperature Resistance: 0-60 ℃
Pressure Resistance: 0-0.9mpa
Specifications: YZ2-1-10-01,YZ2-1-10-02,YZ2-1-10-03,YZ2-1-10-04,YZ2-1-12-02,YZ2-1-12-03,YZ2-1-12-04,YZ2-1-12-06,YZ2-1-12-10,YZ2-1-14-04,YZ2-1-15-04,YZ2-1-16-03,YZ2-1-16-04,YZ2-1-4-01,YZ2-1-6-01,YZ2-1-6-02,YZ2-1-6-03,YZ2-1-6-04,YZ2-1-8-01,YZ2-1-8-02,YZ2-1-8-03,YZ2-1-8-04,YZ2-2-10-01,YZ2-2-10-02,YZ2-2-10-03,YZ2-2-10-04,YZ2-2-12-02,YZ2-2-12-03,YZ2-2-12-04,YZ2-2-14-02,YZ2-2-14-03,YZ2-2-14-04,YZ2-2-6-01,YZ2-2-6-02,YZ2-2-6-03,YZ2-2-6-04,YZ2-2-8-01,YZ2-2-8-02,YZ2-2-8-03,YZ2-2-8-04
