SNS Shenchi Pneumatic Factory Direct Sales Stainless Steel Double Card Sleeve Straight Terminal Connector External Thread Water Pipe Connector
Bite Type Fittings Consists of Three Parts: Joint Body, Card Sleeve and Nut. When the Card Sleeve and Nut Set Are Inserted Joint Body on the Steel Pipe, Tighten the Nut, the Outer Side of the Front End of the Card Sleeve Is Fitted with the Joint Body Conical Surface, and the Inner Blade Is Evenly Bit into the Seamless Steel Pipe to Form an Effective Seal. It Is Easy to Install and Has High Pressure Resistance, So It Is Widely Used.AdvantagesFerrule Connector Has the Characteristics of Reliable Connection, High Pressure Resistance, Thermal Endurance, Good Sealing Performance and Repeatability, Convenient Installation and Maintenance, Safe and Reliable Work, Etc.Working PrincipleThe Working Principle of Ferrule Connector Is to Insert the Steel Pipe into the Card Sleeve, Lock It with the Card Sleeve Nut, Resist the Card Sleeve, Cut It into the Pipe and Seal It. It Does Not Need Welding When Connecting with Steel Pipe, Which Is Beneficial to Fire Prevention, Explosion Prevention and Aerial Work, and Can Eliminate the Disadvantages Caused by Careless Welding. Therefore, It Is a Relatively Advanced Connector in the Pipeline of Automatic Control Devices of Oil Refining, Chemical Industry, Petroleum, Natural Gas, Food, Pharmacy, Instrumentation and Other Systems. It Is Suitable for Connecting Oil, Gas, Water and Other Medium Pipelines.IndicatorsManufacturing Standard: Gb3733.1 ~ 3765-83Nominal Pressure: 25mpa -- 40mpaApplicable Tempure: ≤ 450 ℃Applicable Medium: Oil, Water, Gas and Other Non-Corrosive Or Corrosive MediumManufacturing Material: 304 316 20#Piping: Ordinary-Grade Precision Seamless Steel Pipe of 4~42Taper Pipe Thread: ZG,G,NPT, Etc.Key FeaturesCustomized Processing: YesInstallation Form: Card SheathType: StraightBrand: SNSMaterial: 0~60Model: Yz2Scope of Application: WideProduct Alias: Stainless Steel Card Sets Straight ConnectorNozzle Caliber: 3 4 6 8 10 12 14mmTemperature Resistance: 0-60 ℃Pressure Resistance: 0-0.9mpaSpecifications: YZ2-1-10-01,YZ2-1-10-02,YZ2-1-10-03,YZ2-1-10-04,YZ2-1-12-02,YZ2-1-12-03,YZ2-1-12-04,YZ2-1-12-06,YZ2-1-12-10,YZ2-1-14-04,YZ2-1-15-04,YZ2-1-16-03,YZ2-1-16-04,YZ2-1-4-01,YZ2-1-6-01,YZ2-1-6-02,YZ2-1-6-03,YZ2-1-6-04,YZ2-1-8-01,YZ2-1-8-02,YZ2-1-8-03,YZ2-1-8-04,YZ2-2-10-01,YZ2-2-10-02,YZ2-2-10-03,YZ2-2-10-04,YZ2-2-12-02,YZ2-2-12-03,YZ2-2-12-04,YZ2-2-14-02,YZ2-2-14-03,YZ2-2-14-04,YZ2-2-6-01,YZ2-2-6-02,YZ2-2-6-03,YZ2-2-6-04,YZ2-2-8-01,YZ2-2-8-02,YZ2-2-8-03,YZ2-2-8-04
