Model |
P5000 |
Weight (kg) |
12 |
Color |
black SILVER |
Main Material |
metal |
XP is the Yamaha?s new 5-model power amplifier series for installation that
achieves high soundquality and high cost performance. The power amplifier
featuring high power, high quality, highreliability and high stability matches
various installation sound systems and provides superioracoustic features
even in live performance applications.
Features:
High sound quality equivalent to upper-class models with parts andemphasizing
on superior sound
While realizing a design that ensures high sound quality, efficiency hasbeen
planned down to the finest details for full achievement of bothhigh-definition sound
and superior value
Yamaha's exclusive state-of-the-art high-efficiency amplifier drivingtechnology EEEngine
installed
A gain switch that can be changed to +4dBu / 26dB / 32dB has beeninstalled on the
rear panel for compatibility with a wide variety of inputlevels
Light weight and compact design of 2U size for installation in anylocation
Monitor and remote terminals for monitoring and control from a remotelocation
High-accuracy 1dB-step detented attenuator
Various terminals and features suitable for professional use
Special high-pass filter that enables change of cut-off frequency
Equipped with various protection circuits, indicators and steplesslow-noise fans
Best matches with the digital mixing engine DME64N/24N and Installationseries
speakers
Key Features
Specifications:
Output Power: 250W + 250W (8 ohms, 20 Hz ? 20 kHz)
S/N Ratio: 100dB (20Hz-20kHz)
Idle Power consumption: 25W
1/8 Power Consumption: 320W
THD+N: 0.1%
Intermodulation Distortion: 0.1%
Residual Noise: -70dBu
Maximum Input Voltage: +22dBu
Dimensions (W x H x D): 480 x 88 x 456 mm (18-7/8" x 3-7/16" x17-15/16")
What's In the Box
power Amp
