Buy Polycrystalline 80W Solar Panel in Nigeria

Polycrystalline 80W Solar Panel

₦ 38,675.00 ₦ 45,500.00 -15%

4 5 Reviews

Product SKU: RENG437095

Brand: Talkers

Quantity

In Stock

Product Highlights

High quality guarantee using 156 mm high conversion efficiency crystalline silicon solar cells.

High performance bypass diodes minimize the power drop caused by shade

100% Secure Payments

TrustPay

Pay Online Delivered T&C^*

Check your shipping location

Have one to sell? Sell on rehmie

Product Specifications
Description

Brand	Talkers

Yingli Polycrystalline high efficiency solar panel is Ideal for isolated solar power systems, these photovoltaic panels can be used individually or associated, serving energy systems of different sizes and providing electricity for all kinds of application.

FEATURES:

1. High quality guarantee using 156 mm high conversion efficiency crystalline silicon solar cells.

2. High performance bypass diodes minimize the power drop caused by shade

3. High transmittance, low iron tempered glass; High performance EVA; A weatherproof back sheet and sandblast electrophorus is aluminum frame extend the application of modules greatly

4. 25-year limited warranty on power output and performance

5. Sealed, waterproof, multi-functional junction box gives high level of safety.

APPLICATIONS:

1. Solar power stations;

2. Rural electrification, Small home power systems;

3. Power supply for traffic, security, gas industry;

4. 12V and 24V battery charging systems;

5. Other industrial and commercial applications.

ELECTRICAL PERFORMANCE

Electrical parameters at Standard Test Conditions (STC)

Module Name 80W Solar Panel

Module Type TK800P-17b

Power output Pmax W 80

Power output tolerances Pmax % ±5

Module efficiency ηm % 12.9

Voltage at Pmax Vmpp V 17.1

Current at Pmax Impp A 5.86

Open-circuit voltage Voc V 21.5

Short-circuit current Isc A 6.17

STC: 1000W/m2 irradiance, 25 centigrade cell temperature,AM1.5g spectrum according to EN 60904-3.Average relative efficiency reduction of 5% at 200W/m2 according to EN 60904-1.

Electrical parameters at Nominal Operating Cell Temperature (NOCT)

Power output Pmax W 80

Voltage at Pmax Vmpp V 18

Current at Pmax Impp A 4.65

Open-circuit Voltage Voc V 21.05

Short-circuit current Isc A 5.07

GENERAL CHARACTERISTICS

Dimensions (L/W/H) 1210*560*40MM

Weight 5.68kg

PACKING SPECIFICATIONS

Number of modules per box 1

Packaging box dimensions(L/W/H) 1210*560*40MM

Talkers Energy undertake strict quality control system and insist on perfect workmanship and the use of top quality materials.

And our products have been CE, CB and SASO certified. Our pursuit of first-rate quality, competitive prices and considerate after-sales services offers both potential and long-standing client confidence in our company.

Ratings & Reviews

4 5 Reviews

5 Excellent!

product is nice

By: godiya

At Jan 13 2017 , 05:19 pm
2 Bad!

Product packaging was poor, as it was not in a factory-packaging carton. Another deficiency was that it had no specification or rating lebell on it! A technical product usually has specification name-plate on it such that you can no its rating & capacity at a glance! In the case of this panel, no written rating or voltage output spec.was shown appropriately on it

By: Fred

At Sep 17 2016 , 06:37 am
5 Excellent!

Nice and Good

By: Umar

At Aug 12 2016 , 07:31 pm
3 Good!

Yea it's working fine delivery was OK keep it up

By: awotayo

At Jul 27 2016 , 06:47 pm
5 Excellent!

nice one good quality

By: Collins

At Mar 19 2016 , 11:25 pm
