Features:
Support PCI Expre Base 3.1a Specification
Compliant with Universal Serial Bus 3.1 specification Revision 1.0; 2.0; 1.0
Support PPS/PD3.0/PD2.0/QC4+/QC4/QC3.0/QC2.0/AFC/FCP/SCP/PE2.0/PE1.1/SFCP/VOOC
Compliant with xHCI (eXtensible Host Controller Interface) specifications Revision 1.1
A type c female, an external USB3.2 interface and internal SATA power
Support device remote wakeup function from USB keyboard or mouse
Support Control, Bulk, Stream, Interrupt, Isochronous transfer type
Specifications:
Type: PH68
Item: USB3A port +Type-C +Front Type-E +19Pin/20Pin Adapter
Input interface: PCI-E X4 (X2) compatible with X8/ X16
Compatible: USB1.1, USB2.0 USB3.0 USB3.1 USB3.2
Compliant with: PCI expre 3.0 basic specifications
Speed: Up to 20Gbps
Operation Humidity:5 to 95% RH
Power output :5V/3000mA for Type C port
Power Input: 15-pin SATA CD-ROM Type Power Connector
System Requirements: Windows OS; Linux 2.6.31 or later (Linux OS already implemented USB3.2 driver)
Note:
Due to the probl of lighting effects and shooting angles, there will be certain tolerances in the product, please understand.
Please allow 0-1cm error due to the manual measurment.
Package Includes:
1 PC × PCIe to USB3.2 Type-C Controller Card
1 PC × Low Profile Bracket
About shippingShipping and Packaging All it will be double checked and well packed before sending.It will be dispatched within 2 business days ar buyers pay for the order. It usually takes about 14 to 18 working days for delivering the package to the destination(for remote areas,it may take a little longer).
Special Announcement:Please fill in the correct and detailed consignee, address and phone number in the order. For fast and correct delivery.If you do not receive order within 30 working days,please feel free to contact Customer Service before leaving Negative and Neutral Feedback, we will do our best to help you resolve the problem.TaxNo, you will only pay what is quoted as total cost at checkout, no more. You are not expected to pay any additional duties ores. If you are asked by Customs or our logistic partner to pay duties, please contact our Customer Service .
Your 100% satisfaction is very ant to usIf the product is not on good condition, You can return this product within 14 working days, please contact customer service center before returning.FeedbackYour satisfaction is our first priorityIf you receive the order and it is in good condition,we would be grateful if you would leave us 5 star Positive Feedback for the transaction.
Key Features
Origin:Mainland China
Certification:NONE
Model Number:USB3A port +Type-C +Front Type-E +19Pin/20Pin Adapter
Interface Type:PCI Express
Package:Yes
Type:Add On Cards
Private Mold:NO
Products Status:Stock
Place of Origin:Guangdong, China
Input interface:: PCI-E X4 (X2) compatible with X8/ X16
Compatible:: USB1.1, USB2.0 USB3.0 USB3.1 USB3.2
Compliant with:: PCI express 3.0 basic specifications
Speed:: Up to 20Gbps
What's In the Box
1X PCIE 3.0 To USB 3.2 Gen2 Type-C 10Gbps Data Transfer Quick Charge USB-C Controller PCI-E Type E 19P20P Type E Card
