with 2.5 mm, 3.25 mm, 4 mm, 6mm diameter rutile, basic and cellulosic electrodes, obtain excellent performance and smooth characteristic welding arc.
ability to gouging in and cut the workpiece by 6 mm 8 mm carbon electrodes.
high-strength energy supply cable provides a safe working environment.
full compliance with electric generators. it can be used in the construction site environment.
smart fan technology only activates when needed; reduces noise and dust accumulation inside the machine.
trouble-free welding under heavy working conditions.
suitable for multi-group work specific to shipyards.
thanks to its adjustable hot start feature, it provides easy ignition of the electrode, thus preventing it from sticking to the workpiece.
adjustable arc force feature allows the welding arc to be more stable by preventing the problem of arc cutting and sticking of the electrode to the workpiece during welding.
full compliance lvd (en 60974-1), emc (en 60974-1) and ce regulations.
parameter unit ma350
system voltage v ac 380 v, 3 phase, 50/60 hz
input power kva 12,6
output power kw 11,9
input current a 13
current adjustment range a 20-350a
open circuit voltage v 50
operating regimes (25 °c) %20 350 a
operating regimes (25 °c) %100 250 a
protection class ip23s
type of current a dc
welding wire diameter mm 2,5-3,25-4,00-6,00
machines dimensions mm l:430 x w:205 x h:320
weight kg 17,5
parameter unit ma350
welding cable m 3
welding cable with electrode holder m 2
