1. Can simultaneously read and write multiple tracks (track 1, 2, 3), convenient and fast operation.
2. The read-write status has an indicator light and a buzzer to let you know if the read-write is successful.
3. Manual card swiping, support high and low speed card swiping.
4. Read and write multi standard cards directly, support for IBM, ISO, ANSI, DIN and other magnetic card and passbook, each rail can automatically identify for IBM and ISO format, no command control, can be used to switch write card format and the second track record density.
5. Provide a variety of demo drivers and for Windows environment secondary development environment, according to user requirements to develop a variety of different types of instruction set.
Adopt special anti - interference measure, suitable for all kinds of environment.
Condition: 100% Brand New
Item Type: Card Reader
Model: MSR605X
Card Swiping Speed: 10 - 120cm/s
Reading and Writing Standards: ISO7810/7811
Read-Write Coerce Range: 300-4000 Oe Magnetic Card
Card Thickness: 0.76-1.2mm/0.03-0.05in
Record Density (Character) : Track 1:210BPI(76 Characters);Track 2:75BPI(Low Density 37 Characters)/210BPI(High Density 104 Characters);
Track 3:210BPI(104 Characters)
Output Port: USB
Power Supply: DC5V USB Power Supply
Magnetic Head Life: Greater than 800,000 Times
Power Supply: External Switching Power Supply, Input: 100-240 Volts Ac, Output :9 VDC 2a
Working Environment: Temperature -10Celsius - 60Celsius, Humidity 10% - 85%RH
Repetition Rate: Read Card Less than 1/1000, Write Card Less than 1/100
Data Standard: for IBM/ISO/ANSI or DIN Standard
Colour:black
Material: ABS
Package Contents:
1 x Magnetic Stripe Reader
10 x Magnetic Card
1 x Remove Card
1 x Software CD
Only the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
Key Features
USB magcard card reader
Magnetic stripe card reader
MSR605X
Magnetic Stripe Reader
MSR206
What's In the Box
1 x Magnetic Stripe Reader
10 x Magnetic Card
1 x Remove Card
1 x Software CD
