- Live/Location Recording & Podcasting
- Swappable Stereo Mic, Built-In Speaker
- Dual XLR-1/4" Mic/Line Inputs
- Fast, User-Friendly Operability
- Records in WAV up to 96 kHz
- 3.5mm Line & Headphone Outputs
- Onboard Compressor & Low-Cut Filter
- Powered via Batteries, AC, or USB
- Supports SDHC Cards up to 32GB
- Stereo Safety Track Recording
Ideal for documentaries, podcasting, audio for video, and professional sound design, the Zoom H5 portable handheld recorder lets you quickly record up to four input signals regardless of your audio experience. With a swappable stereo microphone capsule, versatile 2-channel inputs, and up to 4-track recording, the H5 is both user-
Portable Recorder
Form Factor |
Handheld Recorder
|
Primary Use Applications |
Audio-for-Video, Dictation & Transcription, Music Recording
|
Number of Tracks |
4
|
Number of Input Channels |
4
|
Maximum Sampling Rate |
96 kHz / 24-Bit
|
Microphone |
Interchangeable Cardioid Condenser Stereo Pair, X/Y Configuration
|
Number of Microphone Inputs |
2
|
Built-In Speaker |
Yes, 400 mW Mono
|
Display |
Monochrome LCD (Backlit)
|
Memory Card Support |
SD (16 MB to 2 GB) SDHC (4 to 32 GB)
|
Internal Storage |
No
|
Special Features |
Pre-Record Buffer, Remote Control Capable, Voice Activation
|
Recording
Audio File Formats |
BWF, MP3, WAV
|
Sample Rates |
WAV: 44.1 / 48 / 96 kHz (Stereo) MP3: 44.1 kHz
|
Bit Depth |
16 / 24-Bit
|
Bit Rates |
48 to 320 kb/s
|
Signal Processing & FX |
Compressor, Limiter, Low-Cut Filter, Pitch Control
|
Timecode Support |
No
|
Recording Time |
WAV 44.1 kHz/16-Bit: 1 Hr 30 Min per GB (Stereo) MP3 320 kb/s: 7 Hrs per GB (Stereo)
|
Included Software |
No
|
Connectivity
Analog I/O |
2x Combo XLR-1/4" TRS Female Balanced/Unbalanced Line/Mic Input 1x 1/8" / 3.5 mm TRS Female Unbalanced Line/Mic Input 1x 1/8" / 3.5 mm TRS Female Unbalanced Line Output 1x 1/8" / 3.5 mm TRS Female Unbalanced Headphone Output
|
Digital I/O |
No
|
Phantom Power |
+12 / 24 / 48 V (Selectable on Individual Inputs)
|
Plug-In Power |
Yes, 2.5 V
|
System Connection |
1x Mini-USB (2.0)
|
Audio Interface Capability |
Multi-Track
|
Wireless |
No
|
Mobile App Compatible |
No
|
Performance
Gain/Trim Range |
X/Y Mic Capsule: Up to +52 dB 1/8" Inputs: Up to +52 dB Mic/Line Inputs: Up to +55 dB
|
Max Input Level |
Mic/Line Inputs: +22 dBu (Pad On)
|
