The BOYA BY-WM8 is an UHF Dual-Channel wireless microphone system, designed
for ENG, EFP, DSLR video, and dual-Channel can work with two transmitters,
perfect for interviews as well.
The receiver and the transmitters are lightweight and simple menu to operate.
It can be worked in one to two way (one receiver to two transmitters), or one to one way
(one receiver to one transmitter).
Features
Ideal for interviews, ENG/EFP, DSLR Video etc.
Compander for High-quality and Clear sound
Dual-Channel Wireless Receiver
48 UHF Channels
Selectable STEREO/MONO Mode
Plug and Record Functionality
Programmable Mute function
Mic and Line-in
Camera-Mountable Receiver
Monitoring sound by headphone output (Receiver)
Includes Omni-Directional Lavalier Mic
Includes XLR output cable, Stereo mini plug cable
More than 6 Hours Continuous Operation
Operation range can reach up to 100m(300') (without obstacle)
Power Supply: Two ( x3 ) AA batteries
Specifications
System
Oscillator type: PLL Synthesized Control Oscillator
Carrier Frequency Range: 584 MHz-608 MHz (Transmitter A)
576 MHz-599 MHz (Transmitter B)
Channels: 48
Frequency response: 60Hz-15 KHz+/-3 dB
Operation range: 100m (300')(without obstacle)
Operating temperature: 14° F to 122° F (-10degree to +50degree)
Storage temperature: 14° F to 131° F (-10 degree to +55 degree)
Transmitter
RF output power: 20 mW
Antenna: Flexible
Spurious emission: 250 nW or less
Audio input connector: 3.5mm mini jack
Audio input level: 600 mV-2000 mV
Reference deviation: ±7KHz (-60 dBV, 1 KHz input)
Input frequency range: 20 Hz-20 KHz
Power supply: Two AA batteries
Operation time: 6 hours
Dimensions: (H x W x L) 7.0” x 2.6” x 1.1”(17.7 x 6.7 x 2.9 cm)
Weight: 95g (3.4 oz) without batteries
Receiver
Antenna: Flexible
Audio input connector: 3.5mm mini jack
Signal-to-noise ratio: 80 dB
Distortion: 0.8% (-60 dBV, 1 KHz input)
Earphone output level: 60 mW, 32 Ohms/1KHz
Audio output level: 120 mV
Power supply: Two AA batteries
Operation time: 6 hours
Dimensions: (H x W x L) 7.7” x 3.1” x 1.1”(19.6 x 8.0 x 2.9cm)
Weight: 130g (4.6 oz) without batteries
Lavalier Microphone
Transducer: Back electret Condenser
Polar pattern: Omni-directional
Frequency Range: 35Hz ~ 18 KHz
Signal / Noise:74dB SPL
Sensitivity: -30dB +/-3dB / 0dB=1V/Pa, 1 kHz
Connector: 3.5mm locking mini plug
Length: 1.2m (4’)
Package List
2 x Transmitters
1 x Receiver
2 x Omni-directional lavalier microphone
1 x Stereo 3.5mm mini plug cable
1 x XLR output cable
2 x Microphone Holder clip
2 x Wind screen
2 x Belt clip
1 x Shoe mount adapter
3 x Mini Tripod
2 x Portable Soft Bag
2 x Cleaning Cloth
