10 Pairs/lot, solar connector waterproof IP67. Connector with TUV approved. Fast delivery.
Specification
Item no:
Rated voltage: 1000 V
Rated impulse voltage: 1000 V
Test voltage: 6 kV (50 Hz)
Suitable for cables: 10, 12, 14 AWG (2.5mm2/4mm2/6mm2;)
Rated current: 24A - 14 AWG (2.5mm2;), 30A - 12 & 10 AWG (4mm2; & 6mm2;)
Protection grade: IP67
Contact material: Copper, silver-plated
Insulation material: PC/PA
Operating temperature: -40°C ~ +90°C
Safety cla: II
Flame cla: UL94-V0
Contact resistance: ≤5mΩ
Insertion / Withdrawal force: ≤50N / ≥50N
Locking system: Snap-in
About shippingShipping and Packaging All it will be double checked and well packed before sending.It will be dispatched within 2 business days after buyers pay for the order. It usually takes about 14 to 18 working days for delivering the package to the destination(for remote areas,it may take a little longer).
Special Announcement:Please fill in the correct and detailed consignee, address and phone number in the order. For fast and correct delivery.If you do not receive order within 30 working days,please feel free to contact Customer Service before leaving Negative and Neutral Feedback, we will do our best to help you resolve the problem.TaxNo, you will only pay what is quoted as total cost at checkout, no more. You are not expected to pay any additional duties or taxes. If you are asked by Customs or our logistic partner to pay duties, please contact our Customer Service .
Your 100% satisfaction is very ant to usIf the product is not on good condition, You can return this product within 14 working days, please contact customer service center before returning.FeedbackYour satisfaction is our first priorityIf you receive the order and it is in good condition,we would be grateful if you would leave us 5 star Positive Feedback for the transaction.
Key Features
Origin:CN(Origin)
Certification:NONE
Model Number:connector 10 Pairs
Function 2:Solar Connector
Description 1:Female and male
Description 2:Pairs
Usage A:Solar Panel Connectors
Usage B:10 Pairs
Usage C:Connector
Usage D:TUV 1000Vdc
Feature 1:UL 600Vdc
Feature 2:Best discount
What's In the Box
1X EASUN POWER 10Pairs X Connector Male Female Solar Connector Solar Panel Branch Series Connect For Solar Power System
