Feature: This 7 Pin Tester is designed to indicate a failure in the wiring on both towing vehicles and trailers/caravans etc.
Just plug the tester in the 7 pin socket or the 7 pin plug of the trailer or caravan and press the yellow button on the side of the tester.
With a 6 light LED system.
All the LEDs light up when the wiring is good.
Makes the checking of the wiring quick, easy and very simple.
Durable black plastic construction
Portable, easy to store hand held design
Function & guide:
Trailer (can also be a caravan or bicycle carrier)
Ⅰ. Put the plug in the connection of the tester.
Ⅱ. Press the yellow button on the side of the tester.
Ⅲ. If the wiring is good, all the LEDs light up. the function of each LED is (acc lso 1724):
1. left hand indicator (yellow);
2. foglight or 12V (blue);
3. mass (white);
4. right hand indicator (green);
5. right rearlight (brown);
6. left brake light (red);
7. left rearlight (black). Attention: The pin no 2 can be used either for a warning foglamp or a permanent 12V connection.
Ⅳ. If a LED doesn't light up, it is because the corresponding wire is defective. If all the LEDs don't light up, then the mass wire is damaged or all bulbs are defective.
Specifications:
Voltage 12V
With ROHS approved
Material: Copper+ABS
Battery Type: 6F22, 9V(Not Included)
Applicable scope:7 pins plug and socket connection
19.5x5x2.6cm/7.68x1.97x1.02"
Quantity: 1 Pc
Note:
Please allow 1-3mm error due to manual measurement. pls make sure you do not mind before you bid
Due to the difference between different monitors, the picture may not reflect the actual color of the item. Thank you!
Package include:
1 Pc x Plug Socket
1 x User Manual
Key Features
Model Name:Wiring Circuit Tester Plug Socket
Item Size:19.5x5x2.6cm/7.68x1.97x1.02"
Item Weight:172g
Material Type:Copper+ABS
Item Type:Cables, Adapters & Sockets
What's In the Box
1X Car Trailer Caravan 7 Pin Towing Tow Light Wiring Circuit Tester Plug Socket
