Buy 120W Solar Grid Tie Micro Inverter DC16-26V to AC220V Pure

120W Solar Grid Tie Micro Inverter DC16-26V to AC220V Pure Sine Wave Inverter

₦ 963,497.60 ₦ 1,014,208.00 -5%

0 No Reviews

Product SKU: RENG324550

Brand: No Band

Quantity

In Stock

100% Secure Payments

TrustPay

Pay Online Delivered T&C^*

Delivery Information

Shipped from overseas and normally delivered between 20-35 days

Have one to sell? Sell on rehmie

Product Specifications
Description

Size (L x W x H cm)	20.37.63.5
Weight (kg)	0.4
Color	Green black

120W Solar Grid Tie Micro Inverter DC16-26V to AC220V Pure Sine Wave Inverter CE

120W Grid Tie inverter is a compact unit,which directly converts direct current into alternating current for powering appliances and/or office equipments and connecting to utility grid.The AC output from Smart Micro inverter is synchronized and in-phase with the utility grid.

Specifications:

Grid Tie Inverter Maximum Output Power:110W

Rated Output Power:100W

DC Input: 16V-30V

Startup Voltage:16V（The lowest working voltage after starting 10.8V）

Maximum Input Voltage:30V(Voc)

MPPT Voltage Range:16V - 25V.（Working voltage Vmp(of a solar panel) must be in the MPPT range to ensure the good output efficiency）

Maximum Input Current：7.5A

AC Output Voltage: 180-260V

Recommended Solar Panel Voltage: Vmp16-21V; Voc20-24V

Solar Panel Power: maximum 120W

Frequency Range：50/60HZ Auto

On Grid inverter Certification:CE

Dimensions (W x H x D):35mm x 76mm x 203mm

Weight:0.4kg

User notice：

• Use solar panel ONLY connect to this equipment.

• This equipment is ON-GRID Microinverter, To make it work properly, it must be connected to the power grid correctly,and the power grid is working properly, When the power grid stopped working, it will also stop generating.

• Do NOT exceed PV panel(s) voltage over the Solar Grid Tie Inverter max input voltage.（Voc＜30V）

• Do NOT exceed PV panel(s) power over the Grid Tie solar Inverter max input power.（120W）

• The positive and negative poles of the solar panel cannot be reversed. If you extend the solar panel cable. You need to be careful about this problem.

• Install away from direct sunlight and direct rain exposure.(Ventilated, dry, cool)

Regarding the heating problem of the inverter:

this is normal phenomenon. All electronic devices generate heat during operation. The inverter uses aluminum alloy material. Metal can conduct heat better. The inverter also has over-temperature protection if the temperature is high. Then the inverter will automatically reduce the working output efficiency. Or stop working. After cooling down, restart. It is recommended to install the inverter in a ventilated, dry and cool place.

About inverter repair：（This is a common problem of micro-inverters）

After a large amount of customer data feedback, the inverter cannot work because the DC or AC fuse is damaged. (The red light is on because the AC accessories are damaged, and if the light is off, the DC accessories are damaged)When you encounter this problem, we can send you accessories for free. And give you maintenance video instruction. You can easily replace it.

If you have any questions after receiving the product, please contact us in time, we will give you good after-sales service, so you don't have to open disputes at will.

Key Features

Grid Tie Inverter MPPT Range 15.5-25V
Working voltage Vmp (of a solar panel) must be in the MPPT range to ensure the good output efficiency
Grid Tie Solar Inverter PV Panel Voltage: Vmp:16-21V; Voc:20-24V
Solar panel power cannot exceed 120W
Micro Grid Tie Inverter Doesn't work with battery.Only use solar panels as a DC power source.

What's In the Box

Package Include:

1 x Grid Tie Inverter

1 x AC Cable 30CM
