Package included:
1X MPPT solar charge controller
Features:
1.Always keep the on full voltage condition.
2.Prevent from overcharging, overdischarging, charging to solar panels during night.
3. polarity protection for and solar panels.
4.When the voltage is low, the controller will automatically cut off the load from system. If the voltage of is back to normal and the load will restart working.
5.Thunder protection.
6.According to the voltage grade, the controller can automatically set charge-off voltage, load-off, load-restore.
7.The controller will automatically compensate the temperature of the charging voltage according to the changes of ambient temperature.
Specification:
1.Type: MPPT15
2.Rated voltage: 12V/24V
3. current: 15A
4.Length1m Charge loop drop: <250mV
5.Length1m discharge loop drop: <50mV
6.Input voltage: 12~20V/24~40V
7.Fully charge cut: 13.7V/27.4V
8.Low voltage cut: 10.5V~11V/21V~22V
9.Temperature compensation: -3mv/℃/cell
10.No load loss: 10mA
11.Efficiency: 95%~97%
12. wire area: 2.5㎡
13.Ambient temperature: -25℃~55℃
Note: this item cannot be applied to street lamp.
a a a a a
Key Features
current: 15A
Rated voltage: 12V/24V
Input voltage: 12~20V/24~40V
Fully charge cut: 13.7V/27.4V
No load loss: ≤10mA
Efficiency: 95%~97%
wire area: 2.5㎡
Ambient temperature: -25℃~55℃
Easy to use
Exquisite Workmanship
Well Made
Best Choice and best discounts
Customer Care is Our Top Priority
Offer is Subject to Availability
Big Sale
What's In the Box
1X MPPT solar charge controller
