Buy 10 Pcs Micro-USB 5V 1A 18650 TP4056 Lithium Battery Charger

10 Pcs Micro-USB 5V 1A 18650 TP4056 Lithium Battery Charger Module Charging Board with Protection Dual Functions

₦ 16,776.71 ₦ 17,659.69 -5%

0 No Reviews

Product SKU: RENG194837

Brand: Generic

Quantity

In Stock

100% Secure Payments

TrustPay

Pay Online Delivered T&C^*

Delivery Information

Shipped from overseas and normally delivered between 20-35 days

Have one to sell? Sell on rehmie

Product Specifications
Description

Model	charging module
Production Country	China
Size (L x W x H cm)	8.2x5x3
Weight (kg)	0.045
Color	Blue
Main Material	PC+Metal

The TP4056 is a complete single-cell Li-Ion battery with a constant current/constant voltage linear charger. The SOP40 package with heatsink on the bottom of the TP4056 and fewer external components make the TP4056 perfect for portable applications. The TP4056 is suitable for USB power and adapter power supplies.
Due to the internal PMOSFET architecture and anti-reverse charging path, no external isolation diodes are required.
Thermal feedback automatically adjusts the charge current to limit chip temperature during high power operation or high ambient temperature conditions. The charging voltage is fixed at 4.2V, and the charging current can be externally set by a resistor. When the charging current drops to the set value of 1/10 after reaching the final float voltage, the TP4056 will automatically terminate the charging cycle.
When the input voltage (AC adapter or USB power) is removed, the TP4056 automatically enters a low current state, reducing the battery leakage current to less than 2uA. The TP4056 can also be placed in shutdown mode when there is a power supply, reducing the supply current to 55uA.
Other features of the TP4056 include battery temperature sensing, undervoltage lockout, automatic recharge, and two LED status pins for charging and termination.

100% brand new and high quality
Charge module: Linear charging.
Current: 1A adjustable.
Charge precision: 1.5%.
Input voltage: 4.5V-5.5V.
Full charge voltage: 4.2V.
Led indicator: red is charging Green is full charged.
Input interface: micro-USB.
Work temperature: -10degrees to +85degrees .
Inversed polarity: NO.
Size: small to 25X19X10mm
Colour:blue
Material:PC+Metal

Package Contents:
10 x 5V Micro-USB 1A 18650 Lithium Battery Charging Board Charger Module+Protection

Only the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.

Key Features

TP4056
18650
Lithium Battery Charger Module
Micro-USB Charger Module
18650 Lithium Battery Charging Board

What's In the Box

10 x 5V Micro-USB 1A 18650 Lithium Battery Charging Board Charger Module+Protection
